- Page 1 Instruction Manual Direct Drinking Water Puri er TWP-W1743STH(W) Please read the manual carefully before operating the water purifier. Retain it for future reference.
-
Page 2: Table Of Contents
DIRECTORY 1.Safety Instructions 1-1 Safety Instructions 1-2 Packing List 2. Your Direct Drinking Water Purifier 2-1 Part Name of Water Purifier 2-2.Model and Major Parameters 2-3 Product Features 2-4 Product Functions 2-5 Working principle 3.Use Guide and Maintenance 3-1. Guidance on Unpacking and Installation 3-2. -
Page 3: Safety Instructions
Safety Instruction 1-1 Safety Instructions To use Prior to use, the water puri er must be properly assembled and installed in accordance with this manual. It may damage to the water puri er and cause danger. Instruction Do not use the water puri er near a material with high gasoline volatility which is easily ignited or exploded. - Page 4 Do not immerse cord, plug, or any other part of the water puri er in water or other liquids. It may cause electric shock or re. Prohibit Do not p urify hot water without proper and direct supervision. Unplug unit to prevent unsupervised use by children. Away from children It may cause electrical shock, damage, or malfunction.
- Page 5 Do not connect to water which is not tap water. This product is the water puri er exclusive for tap water. Otherwise, it may damage health or cause trouble. Do not freeze. It may cause leakage or other malfunctions. Reverse osmosis membrane lters will be damaged below 0℃. Prohibit Do not use outdoors.
- Page 6 The water once take out should be used as soon as possible. It is easy to breeding miscellaneous bacteria. When stored water for a longtime. Since there no residual chlorine in water , be stored only 2 to 3 days in the refrigerator safely.
-
Page 7: Packing List
Do not use the water puri er other than indoor. Can cause a re or malfunction. Also it may cause the water puri ers color change, deformation, breeds moss Indoor and contaminated. WARNING: Do not operate the UV-C emitter when it is removed from the appliance enclosure. -
Page 8: Your Direct Drinking Water Purifier
2. Your Direct Drinking Water Purifier 2-1 Part Name of Water Purifier (REAR) (FRONT ) PART NAME PART NAME lter change lamp heating switch cooling switch heating pilot lamp cooling pilot lamp power cord ground wire UV pilot lamp dispenser controls panel outlet of hot water water button condenser... -
Page 9: 2-2.Model And Major Parameters
Control panel and Indication Cooling pilot lamp Heating pilot lamp Filter change lamp UV pilot lamp Filter reset button WIFI button Dispenser controls panel water button 2-2.Model and Major Parameters Model T WP-W1743STH(W) Applicable water pressure Rated Voltage 0.1-0.4MPa 220-240V~ Rated Frequency Stage 1 PP sediment lter-F1... -
Page 10: Product Functions
2-4 Product Functions High-precision filtration, pure water quality Through high-precision four stage ltration system, it lters granules, iron rust, colloids, bacteria, residential chlorine and impurities in water. Satisfy demand of drinking water and kitchen water It can make water in 24 hours continuously according to needs. Ample water satis es demand of drinking water and kitchen water. -
Page 11: Use Guide And Maintenance
Filter Function Introduction Stage Filter Function PP sediment Stage 1 lter-F1 C1 active carbon Stage 2 lter-F1 RO reverse Stage 3 osmosis lter-F1 C2 active Stage 4 carbon lter-F1 3.Use Guide and Maintenance Please cut off water source before replacing filters. Never plug filters in water running state. - Page 12 5. Use the accessory— lter ushing tip, the arrow direction is the water ow direction, insert the PE pipe in the inlet ball valve. filter flushing tip inlet ball valve Outlet inlet water flower 6. Insert the C1 active carbon lter into the lter ushing tip, tighten it by turning clockwise, and open the water tap to ush the lter till it doesn't discharge black water, for about 10min;...
-
Page 13: Machine Installation
8. For quick connector at back side of WP, Remove the snap ring and press lock ring of quick joint to take out the white plug. Insert PE pipe Attach the snap ring to lock ring firmly until it hits the gap of the lock ring Press Drain water... -
Page 14: Filter Replacement Cycle
C2 active C1 active carbon RO reverse Filter name lter-F1 carbon lter-F1 lter-F1 osmosis lter-F1 Filter model F-1643-RO F-1643-C2 F-1643-PP F-1643-C1 number How to get the replacement filter. Please call up 025117777 for your replacement lter inquiry or visit https://www.toshiba-lifestyle.com/th... -
Page 15: Maintenance
3) To replace the maturity lter by the new one. If C1 or C2 is needed to replace, go back page 9 of this manual and use “ lter ushing tip” to discharge black water. 4) After replacement, please touch the reset button” ”, until the “... -
Page 16: Troubleshooting
8. Never turn on (off ) the machine by inserting the plug into (pulling the plug out from) the socket. Never increase the length of the supply cord to avoid re. 9. If the supply cord is damaged, it must be replaced by the manufacturer or quali ed person so as to avoid a hazard. - Page 17 heating switch cooling switch Water Puri er bracket The hole for screw It is a normal state that the following circumstances occur when the water puri er is used. 1. During the heating , the heating tube may generate slight noises. This is a normal state.
- Page 18 Filter Replace Advise Table 24 months 6 months 12 months 6 months Replacement recommendatiopns Replacing date 3rd-RO 2nd-C1 4th-C2 1st-PP Fill in the rst using date on the right Advise to replace, 6 months later from the last time Advise to replace, 6 months later from the last time Advise to replace, 6 months later from the last time...
