Summary of Contents for EHRET MoveTronic
- Page 1 MoveTronic Electric folding sliding shutter Installation instructions InsTallaTIon by spEcIalIsT pErsonnEl Valid from 10.2022 E 672.1...
-
Page 2: Notes
EHrET MoveTronic. Insuffi- ly. For this reason, observe the following notes. cient knowledge at the time of commissioning and utilisation lead to the loss of any liability ... -
Page 3: Table Of Contents
Contents notes..........2 Explanation of signs and symbols . -
Page 4: Explanation Of Signs And Symbols
Important notes Explanation of signs and symbols Safety notes Warning notes Only qualified specialist personnel may carry out installation and commission- ing! DaNgEr WarNINg Designates an immediately pending dan- ger that could lead to death or severe in- Incorrect installation could lead to se- juries if the respective precautionary vere injuries and/or damage to prop-... - Page 5 M ake sure that the shutters are locked be- be observed, as otherwise damage to the fore any wind load occurs. motor could occur. EHrET GmbH assumes T he shutters may not be operated at wind no liability for damage resulting from incor- speeds from 62 km/h (stormy wind).
-
Page 6: Ec Declaration Of Conformity
EHrET GmbH aluminium shutters bahnhofstrasse 14 - 18 77972 Mahlberg, Germany declares that the product: Movetronic electric folding sliding shutter to which this guideline refers is in conformance with the stipulations of Directive 1999/05/EC radio equipment and telecommunications terminal equipment... -
Page 7: Product Description
1 product description 1 Product description Product properties technical data • D rive with integrated controller to activate Operating voltage 230 V - 50 Hc folding sliding shutters Dimensions 1150 to 3430 mm (l) • E lectric drive suitable for 230 V continuous 227 ×... -
Page 8: Scope Of Delivery
1 product description Scope of delivery Movetronic Drive schemes 2- to 6-sash, depending on the variant Type 1 Electric folding sliding shutter (left) complete with 230 V folding sliding shutter drive, sashes with fittings and accessories Type 2 (right) Type 3... -
Page 9: Tools Required
1 product description Sash with fitting tools required 2-, 4-, 6-sash, depending on the variant not included in the scope of delivery size 2.5 / 3 / 4 extended mouthpiece First sash sash packet last sash sash 1 (l/r) sash 2+3 / 4+5 sash 2 / 4 / 6 (l/r) Mast accessories... -
Page 10: Installation Instructions
2 Installation instructions 2 Installation instructions Preparation WARNING IMPOrtaNt Danger of injury/property damage caused Incorrect installation may lead to loss of func- by unsuitable fastening materials tion and warranty. select the fastening material in accordance • M ounting holes must not be drilled through with the load capacity of the installation sub- the drive. -
Page 11: Mounting Type 1: Header Installation
2 Installation instructions Header installation Façade mounting Mounting type 1 Mounting type 2 CautION CautION For variant b (drive placed on the outside), a For variant b (drive placed on the outside), a distance of at least 30 mm must be maintained distance of at least 30 mm must be maintained between the drive and the window! between the drive and the window! -
Page 12: Installation Of The Drive
2 Installation instructions Installation of the drive Mounting the guide rail NOtES aligning the bottom guide rail • T he selection of the fastening method is de- align the swivel bearing axis of the bottom pendent on the base and is therefore exclu- guide rail with the top drive axle sively your own responsibility. - Page 13 2 Installation instructions Fasten guide rail place the reflector mirror in the recess of the bottom guide rail. Fix the reflector mirror with the 2 M4 screws. reflector mirror Dismantle pivot bearing bottom rail M4 screws...
-
Page 14: Preparing The Sash
2 Installation instructions Preparing the sash Hook in the first sash Sash 1 (L/R) remove screws from pivot bearing. Insert sash into pivot bearing remove thrust piece from pivot bearing. Insert counter bearing and screw it on. pressure piece clamping plate pivot bearing... -
Page 15: Hooking In The Sash Package
2 Installation instructions Hooking in the sash package Sash 2+3 / 4+5 push thrust piece into pivot bearing Thread sash package into guide rail. attach clamping plate and screw on with M5 screws pressure piece clamping plate carriage ... -
Page 16: Hooking In The Last Sash
2 Installation instructions Hooking in the last sash Sash 2 / 4 / 6 (L/R) Thread last sash into guide rail push thrust piece into pivot bearing attach clamping plate and screw on with M5 screws pressure piece clamping plate ... -
Page 17: Inserting The Coupling Profile
2 Installation instructions Inserting the coupling profile Inserting the coupling profile Sash 1 and 2 Sash 3 and 4 Thread coupling profile into sash 1 and 2. Thread coupling profile into sash 3 and 4. Insert and clinch the rivets. ... -
Page 18: Operating Instructions
3 operating instructions 3 Operating instructions Connection diagram Smart Home Drive 1 Drive 2 or switch brown yellow-green brown yellow-green 3× 0,75 blue Phoenix Contact Mete Energy Mete Energy SACC-M12MS- 403278 403276 4QO-0,75 brown yellow-green blue black blue black brown yellow-green brown yellow-green... -
Page 19: Controls
3 operating instructions Controls teaching in end positions NICE wireless remote control NOtES by stopping briefly and continuing to move, it is signalled that no end position has yet been set in the corresponding direction of travel. remove the cover on the actuator with a screwdriver. - Page 20 © 01.2023 EHrET GmbH | E 672.1 | This technical document includes information that is protected by copyright. all rights are re- served. We reserve the right to make changes, including technical changes, in this document. This document has been prepared with...
