REMACO TECHNOLOGIES PRO-1515 Installation Manual

C COPYRIGHTS 1998 REMACO TECHNOLOGIES PTE LTD
Installation Guide
Caution with main supply and live wires. Install with qualified technician or trained
Warning
personnel.
Universal Bracket can be used for any type of installation as shown below.
Wall Mount
10
cm
10cm
Ceiling
Recessed
Corner Mount
M6 Anchors
M5 Stopper
Screws
M6
Countersunk
Screws
5cm
All manuals and user guides at all-guides.com
Ceiling Mount
For Suspension from Ceiling
Insert these accessories in
between the indicated arrow.
M6 Long Nuts
(For PRO-1515 to PRO-2724)
Ceiling
Suspension
5" to 9" Adjustable Extension
Pelmet Mount
Bracket
Website: www.remacotech.com
V: 5.1
SS/ESC
Use these holes
Side
Pelmet
Mount
Mount (Optional)
5" to 9"
Extension Mount (Wall)
Brown (to Live)
Blue (to Neutral)
Green (to Earth)
3-Cores AC Cable
4-Cores
AC
Cable
Electronics
Screen
Control
(ESC)
STOP
DOWN UP
Remaco
5cm
A/V Control System
(Crestron, Panja)
