LS4
Quick Start Guide
The Leak Sensor detects water, sends audible alerts, and provides cloud-
managed notifications. The Leak Sensor operates on the NextCentury
Connect™ network and is compatible with all NextCentury wireless devices.
A monthly fee applies when the leak monitoring service is activated.
Installation Components
A
Leak Sensor
D
G
A) LS4 Leak Sensor
D) Targeted Cable
G) Mini Turbine Clip
Additional Resources
B
E
B) Mounting Plate
E) Rope Cable
For full installation guide, spec sheets,
and additional resources, please visit:
products.nextcenturymeters.com/ls4
Contact Information
Phone: (844) 538-8203
Email: support@nextmeters.com
C
F
C) Mounting Hardware
F) Mini Turbine (7/8")
Advertisement
Summary of Contents for Next LS4
- Page 1 A monthly fee applies when the leak monitoring service is activated. Installation Components Leak Sensor B) Mounting Plate C) Mounting Hardware A) LS4 Leak Sensor D) Targeted Cable E) Rope Cable F) Mini Turbine (7/8”) G) Mini Turbine Clip Additional Resources...
-
Page 2: Installation
Installation Common Leak Locations The Leak Sensor provides alerts when water is detected in any leak-prone location. General Mounting Guidelines Install the Leak Sensor near the desired detection area in a dry, accessible location. If using adhesive, clean the wall surface first. Leak Sensor Leak Sensor Remove the Leak... - Page 3 Water Detection Cables Install water-sensing Rope or Targeted Cables where detection is needed. Up to three cables can be linked to expand coverage using either or both types. Targeted Cable The Targeted Cable detects water at a single point and can be placed on the floor or at a wall base.
- Page 4 Toilet Leak Sensor Toilet Leak Sensor The Toilet Leak Sensor detects running toilets within properties, helping operators reduce water waste and lower utility costs. Prepare 1) Turn the toilet supply line valve off 2) Flush the toilet until tank is empty 3) Remove supply line from toilet Install 1) Attach Mini Turbine to toilet...
- Page 5 Toilet Leak Sensor Connect Connect the cable from the Flush the toilet and confirm Mini Turbine to the Leak Sensor blue pulse on the Leak Sensor Water Sensing Modes Hold the red button for 5 seconds to toggle leak detection modes, then tap to switch.
-
Page 6: Cloud Connected
Tap the red Test Connect button to check connectivity. The Leak Sensor’s RF LED blinks green when it communicates with the property Gateway. LS4 Ver 1.1 Programming Use the NextCentury Web or NCSS Mobile App to program Leak Sensors before or during installation. Ensure the Gateway is connected to the Cloud for immediate Test Connect feedback.
