Arrow Storage Products SS404 Owner's Manual & Assembly Instructions

Shelf
Bracket
Kit
Model No.
SS404
O
ANY STANDARD
ARROW STORAGE BUILDING
Install
2 posts at
desired location in the building
by
removing
2
fasteners
in
the framework.
Interlock the
2
posts
and
telescope them
to
the proper length between
the upper
and mid wall frames, or mid
wall and floor
frames. Tabs
on ends
of posts go behind frames'
Reinsert
top and bottom fasteners. Fasten
posts to-
gether using
a
bolt
and
nut
at
the center of
posts.
Install
the next
2 posts at the other end
of
shelf location by
removing
2
fasteners as before. Install
shelf brackets
to
posts using 2 bolts and nuts. Use same set of holes
on each post so
that shelf is level' Fasten shelf to
bracket using
wood screws
(not included).
FOR BUILDINGS
WITH NO MID
WALL FRAME:
Install
posts
in
the same manner. Using hole in
bottom
tab on
post as
a
guide, drill 1/4" dia.
hole
through side
wall
paneland fasten with a bolt
and
nut.
o
65103
#8-32 Hex Nut (12)
I
65923
#8-32x318"
Bolt
(12)
REMOVE
I
/
-.,:l
&
REINSERT FASTENER
-ue!
VARIOUS LOCATIONS OF SHELVING
SYSTEMS
CAUTION: SOME PARTS HAVE
SHARP
EDGES.
CARE MUST
BE TAKEN WHEN HANDLING THE VARIOUS
PIECES TO AVOID
A MISHAP. FOR SAFETY
SAKE, WEAR GLOVES WHEN HANDLING METAL PARTS.
FASTEN SHELF
TO
BRACKET
COMPLETED SHELF
