Nokia Mobile Phones Lumia 530 Service Schematics

Service schematics
Nokia Lumia 530
RM-1017 / RM-1018
Nokia Lumia 530
Dual SIM
RM-1019 / RM-1020
1 (13) | Front page
IMPORTANT
This document is intended for use by authorized
Nokia service centers only. Please use the document
together with other documents such as the Service
Manual and Service Bulletins.
ff
Version di erences
This document will cover following releases:
Nokia Lumia 530, RM-1017, Board: 4KT_SR (RoW)
Nokia Lumia 530, RM-1018, Board: 4LT_SA (America)
Nokia Lumia 530 Dual SIM, RM-1019, Board: 4LU_DR (RoW)
Nokia Lumia 530 Dual SIM, RM-1020, Board: 4LV_DB (Brazil)
Nokia Lumia 530 RM-1017&1018 / Nokia Lumia 530 Dual SIM RM-1019&1020 | Board: 4XX_XX | v1.0 | 25.07.2014 | Upknowled
Microsoft Internal Use only | Copyright © 2014 Microsoft, Only for training and service purposes
Version information
While every effort has been made to ensure that the document is
accurate, some errors may exist. Please always check for the latest
published version for this document.
v1.0 - 25.07.2014
-First approved version.
Contents
1 Front page
2 PM8110, MSM8212, Power, Side keys, USB
3 MSM8212, Memory, Accelerometer, SIM(s), Display, Camera
4 Audio, BT/WLAN/FM
5 RF Transceiver, GPS
6 Component finder Top (RM-1017)
7 Component finder Bottom (RM-1017)
8 Component finder Top (RM-1018)
9 Component finder Bottom (RM-1018)
10 Component finder Top (RM-1019)
11 Component finder Bottom (RM-1019)
12 Component finder Top (RM-1020)
13 Component finder Bottom (RM-1020)
Send feedback
• Recommend Change in KICS
• Rate this page in KICS
• e-mail careacademy@nokia.com
