X04136_EN_C LCT XL
Plockmatic LCT XL
Large Capacity Tray
Doc no: X04136_EN_C
Date: 13 March 2025
Read this manual carefully before you use this product and keep it handy for future
reference.
For safety, please follow the instructions in this manual.
Operating Instruction

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LCT XL and is the answer not in the manual?

Questions and answers

Summary of Contents for Plockmatic LCT XL

  • Page 1 X04136_EN_C LCT XL Plockmatic LCT XL Large Capacity Tray Operating Instruction Read this manual carefully before you use this product and keep it handy for future reference. For safety, please follow the instructions in this manual. Doc no: X04136_EN_C Date: 13 March 2025...
  • Page 2 X04136_EN_C LCT XL Scan the QR code to access translated versions of this manual in German, Italian, French, and Spanish. Visit https://plockmaticgroup.com/myfinisher/customer-portal-lct-xl-for- ricoh/ to view the manual in your preferred language.

  • Page 3: How To Read This Manual

    X04136_EN_C LCT XL Introduction This manual contains instructions on the operation and maintenance of this machine. To get maximum versatility from this machine all operators should carefully read and follow the instructions in this manual. Keep this manual in a handy place near the machine.
  • Page 4 X04136_EN_C LCT XL Safety Information When using this machine, safety precautions should always be followed. General Safety WARNING • This equipment is not suitable for use in locations where children are likely to be present. • Only connect the machine to a mains power supply of the correct voltage with a good earth- connection;...

  • Page 5: Electromagnetic Compliance

    X04136_EN_C LCT XL Safety during operation, continued • Turn off the power and disconnect the power plug (by pulling the plug, not the cable) if any of the following conditions exists: • Objects are dropped into the equipment. • Liquids are spilled inside the equipment.
  • Page 6 X04136_EN_C LCT XL Safety Information, continued English Description of Safety/Warning labels in the product Crushing Hazard Cutting Hazard Entanglement Hazard Risk for crushing or Sharp objects inside machine. Risk for loose hanging hair, squeezing body parts. jewelry, or clothes to get caught.

  • Page 7: Table Of Contents

    X04136_EN_C LCT XL TABLE OF CONTENTS What You Can Do With This Machine ..........9 Guide To Components ..................... 10 Exterior............................10 Vertical Paper Path and Exit ....................... 11 Tray Assembly ..........................12 Long Sheet Module (LSM), optional ................... 13 Humidity kits, optional .........................
  • Page 8 X04136_EN_C LCT XL 4. Library ....................49 Handling media library ..................... 49 Loading a Media ......................... 49 Saving a Media ........................... 49 Saving a New Media ........................50 Deleting a Media ......................... 50 5. Clearing Misfeed(s) ................. 51 Clearing Misfeed(s) ......................51 Misfeed / Jam in Feeder Tray .....................

  • Page 9: What You Can Do With This Machine

    The Plockmatic LCT XL effectively widens the range of media types/sizes that Ricoh sys- tems can handle. The LCT XL can reliably feed media all the way up to 400 gsm. The LCT XL integrates seamlessly with the Ricoh printing systems and is setup and con- trolled either from the Ricoh printer User Interface or from the Fiery controller if a Fiery is available in the configuration.

  • Page 10: Guide To Components

    X04136_EN_C LCT XL Guide To Components Exterior 1. Exit Area 2. Docking Pin 3. Top hatch 4. Long Sheet Module (LSM) 5. User Interface (UI) 6. Upper Tray / Tray 3 (Tray 5 tandem) 7. Lower Tray / Tray 4 (Tray 6 tandem) 8.

  • Page 11: Vertical Paper Path And Exit

    X04136_EN_C LCT XL Vertical Paper Path and Exit 1. Jam Clearance Baffles (8x blue handles) 2. Jam Clearance Knobs (4x) 3. Power Switch continued on next page...

  • Page 12: Tray Assembly

    X04136_EN_C LCT XL Tray Assembly 1. Paper Guide Lock Release 2. Paper Guide Fans (2x on each side) 3. Vacuum Feed Belts 4. Ultrasonic Double Sheet Detection (Q102/202) 5. Tray Empty Sensors (Q105/205) 6. Linear Position Sensors (width and length sensors) 7.

  • Page 13: Long Sheet Module (Lsm), Optional

    X04136_EN_C LCT XL Long Sheet Module (LSM), optional 1. Fans 2. Side guides, tray 3. Tray extension 4. Side guides, tray extension 5. Sensor, tray empty (Q505) 6. Sensor, paper path (Q521) 7. Sensor exit (Q522) 8. Paper path 9. Feed roller 10.

  • Page 14: Humidity Kits, Optional

    Environments where humidity is above 60% may start to show feeding problems especially if the media is stored in that same environment. This is most prominent on coated media. The optional Plockmatic Humidity kits will significantly reduce feeding problems in humid environments.
  • Page 15 X04136_EN_C LCT XL Humidity kits, optional, continues The Humidity kits will heat the air coming out of the air ducts in the Vacuum trays and the optional Long Sheet Module. The Upper paper support is needed to hold down the sheets in the LSM when the Humidity kit is engaged because of the then increased airflow.

  • Page 16: User Interface

    X04136_EN_C LCT XL User Interface The Plockmatic LCT XL has a User Interface (UI) / Control Panel which allows for viewing or adjusting local machine settings and properties, setting up a job will be handled via the UI of the downstream device.
  • Page 17 X04136_EN_C LCT XL User Interface, continued Library The Library sub-menu allows for programming of media independently for the two vacuum trays. See Section 4 for a detailed description of the Library sub-menu. Tools Pressing [Tools] from the Main Menu opens the Tools sub-menu.

  • Page 18: Status Leds

    X04136_EN_C LCT XL Status LEDs The LCT XL trays and the optional LSM module are equipped with status LEDs. Below is a short explanation of the state colors. Tray LED Blue LEDs: Yellow LEDs: Loaded paper Tray low on paper.

  • Page 19: Basics

    X04136_EN_C LCT XL 1. Basics Turning On / Off the Power Main Power Switch 1 1 Ensure that the main power cord is plugged into the wall and to the back of the LCT XL; 2 2 Make sure the two termination plugs are plugged in, as shown in the picture;...

  • Page 20: Optional Humidity Kit Power Switch

    X04136_EN_C LCT XL Optional Humidity KIT Power Switch 1 1 Ensure that the power cord is plugged into the wall and to the optional Humidity Kit Power Supply Unit [A]; 2 2 Toggle on/off the Humidity Kit Power Switch [B].

  • Page 21: Calibration

    Calibration Sensor Calibration The LCT XL vacuum trays and the optional LSM module are equipped with an ultrasonic double sheet detection sensor (USDSD) each. If feed errors begin occurring more fre- quently, these sensors may need to be calibrated. Refer to Section 6 for full calibration details and instructions.
  • Page 22 X04136_EN_C LCT XL Sensor Calibration (continued) The LCT XL vacuum trays are also equipped with two linear sensors which are used to detect the size of the type of paper loaded in the trays. Should these sensors need to be calibrated, refer to section 6.

  • Page 23: Job Preparation

    X04136_EN_C LCT XL Job Preparation Paper stack preparation 1 1 Hold the paper stack on a flat surface as shown 2 2 Bend the paper stack 3 3 Use your fingers and thumbs to pinch the paper stack 4 4...
  • Page 24 X04136_EN_C LCT XL Paper stack preparation (continued) 5 5 Flex the paper back and forth a couple of times to break surface tension and preseparate the sheets 6 6 Realign the sheets into a stack before putting them into the tray...

  • Page 25: Measuring The Paper Curl

    X04136_EN_C LCT XL Measuring the paper curl Take a sample of the stack (about 15 mm / 0.59” high) and place it on a flat surface 1 1 Take the midpoint as reference and do all the measurements within the...

  • Page 26: Loading Paper

    X04136_EN_C LCT XL Loading Paper Vacuum trays WARNING: Never open both trays at the same time: the machine might become 1 1 From the Main Menu, select the load unstable and tilt over. button for tray 3 (5 if tandem) or tray 4 (6 if tandem) depending on which tray you intend to open and load;...
  • Page 27 X04136_EN_C LCT XL Loading Paper (continued) 6 6 The Vacuum Size Valve controls the size of the vacuum suction area on the bottom of the vacuum chamber. The Vacuum Size Valve needs to be manually shifted to the correct position, which depends on paper width.
  • Page 28 X04136_EN_C LCT XL Loading Paper (continued) Tray A 1 1 Push [↕A] to move the tray A table down (pushing [↕A], will move the tray A table up or down, depending on its initial position). 2 2 Pull the paper guides [A] and [B] outwards to gain space to insert the stack of sheets;...
  • Page 29 X04136_EN_C LCT XL Loading Paper (continued) 65 mm limit NOTE: on the paper guides, there is a mark that indicates the paper loading limit (65 mm for all types of media). The paper stack height should not exceed these indications.

  • Page 30: Index Paper Kit

    X04136_EN_C LCT XL Index paper kit The Index paper kit is composed of two Small Magnetic Guides [A] and a Long Guide [B]. It allows for a more stable feed of index paper. NOTE: tray shown without the front cover for clarity purposes 1 1 Open the vacuum tray.
  • Page 31 X04136_EN_C LCT XL Index paper kit (continued) 4 4 Install the Long Guide [B] to the tray´s Rear paper guide by pulling on the latch [C]: this guide will prevent the paper from rotating due to uneven edges of index paper.
  • Page 32 X04136_EN_C LCT XL Page intentionally blank.

  • Page 33: Setting Up A Job

    XL UI. Note that the jobs will be programmed using the user interface of the downstream device. The only settings to be carried out from the LCT XL are: paper colour (black/ white) and heating (on/off/auto) - see the description of these functionalities in this section. For all the other parameters, Plockmatic always recommends to use all auto/default settings.

  • Page 34: Dsd Sensors

    X04136_EN_C LCT XL DSD Sensors The LCT XL is equipped with three (in the two vacuum trays and in the optional LSM) independent ultrasonic double sheet detection systems. These sensors are active by default. The DSD Sensor can be turned on / off by pushing on its icon.

  • Page 35: Advanced

    X04136_EN_C LCT XL Advanced Press on either of the three icons to reach the advanced settings: the advanced settings for the selected tray will be displayed. NOTE: Always push the green checkmark button to save changes. Switching to another menu without selecting this button first will discard all unsaved changes.

  • Page 36: Auto Fans / Manual Fans

    X04136_EN_C LCT XL Auto Fans / Manual Fans This button allows the user to switch between automatic or manual fan settings. Auto mode sets all the process parameters except for the paper color, which is set in the [Advanced] sub-menu, and the paper curl amount.

  • Page 37: Manual Fans Adjustment

    If automatic settings provide unsatisfactory results, fan settings may be adjusted manually. Plockmatic recommends adjusting only one setting at a time. If adjusting that setting does not provide satisfactory results, set it back to auto mode prior to adjusting another setting.
  • Page 38 X04136_EN_C LCT XL Manual Fans Adjustment (continued) Vacuum Air This parameter controls the vacuum fan, which pulls paper towards the transportation belt during feeding. Push the green check mark to confirm the changes or the red cross to discard them and to go back to the main menu.

  • Page 39: Process Position

    X04136_EN_C LCT XL Manual Fans Adjustment (continued) Rear Float Air This parameter controls the flow of the two rear fans. Float air blows into the paper stack from the sides to create separation between sheets. Push the green check mark to confirm the changes or the red cross to discard them and to go back to the main menu.

  • Page 40: Saving Changes

    Stack of unseparated paper Testing the changes Before starting a job, Plockmatic recommends testing the changes made in manual mode with the “test settings” button under the Tools Menu (see section 3 of this manual). This function activates all the fans and moves the elevator to process position according to your settings.

  • Page 41: Tray A Settings (Long Sheet Module - Lsm)

    Tray A settings (Long Sheet Module - LSM) DSD sensor Heating (optional) Tray A button If the optional Long Sheet Module is installed on the LCT XL, the [Tray A] button will appear on the User Interface. When [Tray A] is selected, the LSM sub- menu is shown.
  • Page 42 X04136_EN_C LCT XL Page intentionally blank.

  • Page 43: Tools

    If [Auto] is selected, the LCT XL will detect the type of paper loaded in the trays, thanks to the position of the side guides.
  • Page 44 X04136_EN_C LCT XL Test Settings (continued) Custom paper size: Selecting [Custom Size] will open a new screen that allows for inputting of custom values, plus it will recall the last custom size inputted. Push the green check mark to confirm...

  • Page 45: Calibration

    X04136_EN_C LCT XL Calibration The operator will be able to calibrate the USDSD (Ultrasonic Double Sheet Detection) sensors as well as the paper size sensors via this sub-menu. Refer to Section 6 for full calibration instructions. Counters The Counter sub-menu allows the user...

  • Page 46: Units

    X04136_EN_C LCT XL Units This sub-menu allows the user to: 1. Choose the measurement units (millimeters and inches); 2. Switch among the standard paper size lists. The user can choose among metric, inches and Japanese. Language Select the desired operating language for the machine by pressing the [Language] button.

  • Page 47: Service Mode

    X04136_EN_C LCT XL Service Mode This function is for authorized service personnel only and is password pro- tected.
  • Page 48 X04136_EN_C LCT XL Page intentionally blank.

  • Page 49: Library

    X04136_EN_C LCT XL 4. Library Handling media library Pressing [Library] opens the Media Library sub-menu. This sub-menu allows for programming of media independently for the two vacuum trays. From here you can open a saved media, which can be customized and/or deleted.

  • Page 50: Saving A New Media

    X04136_EN_C LCT XL Saving a New Media Push the [Save As] button from the Media sub-menu to save a new media and insert a new name. The new media will be based on the last media loaded. Deleting a Media...

  • Page 51: Clearing Misfeed(S)

    X04136_EN_C LCT XL 5. Clearing Misfeed(s) Clearing Misfeed(s) WARNING: Never open both trays at the same time: the machine might become unstable and tilt over. Misfeed / Jam in Feeder Tray The affected tray will unlock. 1 1 Pull out the tray;...
  • Page 52 X04136_EN_C LCT XL Misfeed / Jam in Long Sheet Module (LSM) Area (continued) 1 1 Release the Latch handle [A] and open the top hatch with the connected baffle; 2 2 Remove misfed sheet(s) and clear area of any debris or obstructions.

  • Page 53: Misfeed / Jam In Vacuum Trays When Feeding Thick Media

    X04136_EN_C LCT XL Misfeed / Jam in Vacuum Trays when feeding thick media WARNING: Never open both trays at the same time: the machine might become unstable and tilt over. If you experience frequent misfeeds when feeding thick media (thicker than 350 gsm) from the vacuum trays, consider using Tray A (the optional LSM tray) instead.
  • Page 54 X04136_EN_C LCT XL Misfeed / Jam in Vacuum Trays when feeding thick media, cont. 5 5 Locate the screws [C] (2x) in the tray: these screws hold the four separation pads; 6 6 Locate the separation pads [D] (4x) and the vacuum belts [E];...
  • Page 55 X04136_EN_C LCT XL Misfeed / Jam in Vacuum Trays when feeding thick media, cont. 9 9 Reinstall cover [B] and tighten screws [A] (x4). Run the job again and, if necessary, repeat steps 1 to 10 again to move the pads further downwards;...
  • Page 56 X04136_EN_C LCT XL Page intentionally blank.

  • Page 57: Troubleshooting

    Never open both trays at the same time: the machine might become unstable and tilt over. When there is a misfeed or fault condition in the LCT XL, a message and fault code will be displayed on the UI. Some fault codes may be rectified by the operator, but some fault codes may only be rectified by an authorized technician.
  • Page 58 X04136_EN_C LCT XL List of fault codes that can be rectified by the operator (continued) Fault Code Description LSM-461 "Paper flow error Q521 not activated LSM" LSM-462 "Paper flow error Q522 not activated LSM" LSM-471 "Paper flow error Q521 not deactivated - LCT"...

  • Page 59: Fault Codes

    X04136_EN_C LCT XL Fault Codes NOTE: For components locations, refer to the Guide to Components section. LCT-100/200 Misfeed Tray 3/4 Misfeed is a paper flow error detection. Misfeed checks if a sheet is moved correctly from paper pile to ultrasonic DSD sensor. Time is measured from the start of the drive roller (used to feed and separate a sheet from the paper pile) until the ultrasonic DSD sensor can see the leading paper edge.
  • Page 60 X04136_EN_C LCT XL Fault Codes (Continued) NOTE: For components locations, refer to the Guide to Components section. LCT-106/206 Too Thick US DSD, Tray 3/4 Too thick US DSD is a paper thickness error detection. Too thick US DSD checks if a sheet is too thick when it passes the ultrasonic DSD sensor Q102/202.
  • Page 61 X04136_EN_C LCT XL Fault Codes (Continued) NOTE: For components locations, refer to the Guide to Components section. LCT-150/250 LCT stopped by printer. Please clear paper The LCT was stopped because a jam condition was generated in the printer. Actions: • Remove any pre-fed paper •...
  • Page 62 X04136_EN_C LCT XL Fault Codes (Continued) NOTE: For components locations, refer to the Guide to Components section. LSM-301 Jam Tray A (LSM) Jam is a paper flow error detection. Jam checks if a sheet is moved past the DSD sensor correctly.
  • Page 63 X04136_EN_C LCT XL Fault Codes (Continued) NOTE: For components locations, refer to the Guide to Components section. LSM-307 Tray Empty, Tray A (LSM) Tray Empty is a paper present detection. Tray Empty checks if sheets are present in the activated tray during process. A Tray Empty condition is generated if sensor Q505 cannot see any paper.
  • Page 64 X04136_EN_C LCT XL Fault Codes (Continued) NOTE: For components locations, refer to the Guide to Components section. LSM-401 Jam in LSM paper path Jam in LSM paper path is a paper check error detection. Jam in LSM paper path checks if a sheet is in paper path on sensors Q521/Q522 at cycle down.
  • Page 65 X04136_EN_C LCT XL Fault Codes (Continued) NOTE: For components locations, refer to the Guide to Components section. LSM-471 Paper flow error Q521 not deactivated This jam code is generated during process if Q522 detects a trailing paper edge before Q521.
  • Page 66 Q327 is not covered in time. Note that when, this warning is triggered, the LCT XL will not always stop to feed sheets automatically, instead, the feeding procedure might continue depending on which settings the printing engine is running on.
  • Page 67 • Ensure that DSD sensors Q501/502 are clean and calibrated properly (see sensor cali- bration procedure in this section of the manual) • Ensure that sensors Q321/322 are clean (these sensors are located in the LCT XL, on the two jam clearance baffles closest to the LSM) •...
  • Page 68 • Ensure that sensors Q322/323/327 are clean (Q322 and Q323 are located in the LCT XL, on the biggest jam clearance baffle on the higher part of the machine. Q327 is mounted on the clearance baffle located on the exit side of the LCT XL, the closest one to the downstream device) •...
  • Page 69 Jam code is generated during process if Q323 detects a trailing paper edge before Q322. Actions: • Ensure that sensor Q322 is clean (this sensor is located in the LCT XL, on top of the biggest upper clearance baffle) • Check that there are no obstructions in the paper path LCT- 573 Paper flow error Q323 not deactivated Jam code is generated during process if Q327 detects a trailing paper edge before Q323.

  • Page 70: Jam Recovery Manual Setting

    Jam code is generated during process if Q327 detects a trailing paper edge before Q326. Actions: • Ensure that sensors Q326/327 are clean (Q326 is located in the LCT XL, on the jam clearance baffle on the lower part of the machine. Q327 is mounted on the clearance baffle located on the exit side of the LCT XL, the closest one to the downstream device) •...

  • Page 71: Miss Error

    Increase rear float air by 10% and check if sheets are floating correctly. Sheets are floating correctly Exit Repeat the procedure until sheets float correctly. If the LCT XL is set correctly, the sheets will be floating horizontally with equal amounts of separation between sheets. •...

  • Page 72: Jam, Too Long, Too Thick Errors

    Decrease rear float air by 10% and check if sheets are floating correctly. Sheets are floating correctly Exit Repeat the procedure until sheets float correctly. If the LCT XL is set correctly, the sheets will be floating horizontally with equal amounts of separation between sheets. •...

  • Page 73: Double Or Miss Condition In Lsm (Tray A)

    X04136_EN_C LCT XL Jam recovery manual setting (continued) Double or Miss condition in LSM (Tray A) Press to open: "Tray A settings" Press Press to open: to open: "Separation "Float Air" Pressure" Troubleshooting procedure for "double" If a high amount of double feeds is experienced, proceed as follows: 1.

  • Page 74: Ultrasonic Sensor Calibration

    Select Ultrasonic DSD tray A to calibrate the • LSM US sensor and open the LSM top cover; • Open the LCT XL door and fetch the Ultrasonic DSD Calibration Strip [A]; • Place the Calibration Strip as shown in the pictures below.

  • Page 75: Paper Size Sensors Calibration Tray 3/4 (5/6)

    Never open both trays at the same time: the machine might become unstable and tilt over. Sensors should be calibrated if the LCT XL does not recognise correctly the paper loaded into the trays. Calibration sub-menus may be selected from the Tools Menu.
  • Page 76 X04136_EN_C LCT XL Page intentionally blank.

  • Page 77: Remarks

    X04136_EN_C LCT XL 7. Remarks Do’s And Don’ts • Always follow all warnings marked on, or supplied with, the equipment. • Always exercise care in moving or relocating the equipment. Caution Unplug the power cord from the wall outlet and machine before you move or relocate the equipment.

  • Page 78: Where To Put Your Machine

    X04136_EN_C LCT XL Where to Put Your Machine Machine Environment • Always locate the equipment on a solid support surface with adequate strength for the weight of the machine • Always keep magnets and all devices with strong magnetic fields away from the...

  • Page 79: Access To Machine

    2. LCT XL and LSM length: 1300 mm / 51.18" 3. LSM tray extension length: 400 mm / 15,75" 4. LCT XL and LSM length with tray extended: 1700 mm / 66.93" 5. LCT XL width: 800 mm / 31.5"...

  • Page 80: Maintaining Your Machines

    Cleaning An increasing number of misfeeds may indicate a need to clean the LCT XL. Clean every 50 000 cycles or when the number of misfeeds increases. Use a vacuum cleaner, towels and brushes for general purpose cleaning of the paper path, trays, etc. In addition, follow the detailed cleaning instructions below: 1.
  • Page 81 X04136_EN_C LCT XL Cleaning, Continued 4. Open the front door. 5. Toggle the blue handles to the baffles and clean surfaces from toner smearings. 6. Clean, if needed, the feed rollers inside the baffles with rubber reactivator alcohol. Move rollers by using the blue knobs.
  • Page 82 X04136_EN_C LCT XL Cleaning, Continued The LSM Feed Rollers need to be cleaned regularly when in use or if the unit has not been used for a period of time. How often this has to be done, depends on the paper type and print quality.
  • Page 83 X04136_EN_C LCT XL Cleaning, Continued An increasing number of misfeeds may indicate a need to clean the LSM. Clean every 50 000 cycles or when the number of misfeeds increases. Use a vacuum cleaner, towels and brushes for general purpose cleaning of the paper path.

  • Page 84: Limitations

    200,000 sheets from each tray. • When loading paper in the trays of the LCT XL make sure that it has the same direction of pa- per curl: paper with different curl directions cannot be mixed, doing so would result in a misfeed or a jam.
  • Page 85 X04136_EN_C LCT XL Limitations, continued • LSM XL may show marks in the lead edge of the sheets from the separation process. Reducing separation pressure may improve. • LSM XL may have difficulties separating and feeding textured media, Textured media may feed better from vacuum trays.
  • Page 86 X04136_EN_C LCT XL Page intentionally blank.

  • Page 87: Specifications

    Safety Approvals Safety and EMC according to lat- est standard Plockmatic uses open source code in parts of this product. Plockmatic uses QT open source license (LGPL) to develop the software used in this machine (https:// www.qt.io/qt-licensing-terms).
  • Page 88 X04136_EN_C LCT XL Vacuum Trays Specifications Specifications Remarks Maximum loading capacity, 175 mm each tray 6.88 in Maximum loading weight, 66 kg each tray 145.5 lb Minimum - Maximum paper size 120 x 210 mm / 4.73 x 8.27 in...
  • Page 89 X04136_EN_C LCT XL LSM (Long Sheet Module - tray A) Specifications Specifications Remarks Loading Capacity LSM 65 mm / 2.55 in for all type of Note! Feeding performance on media thicker media (300-400gsm) might be limited in below length interval: •...
  • Page 90 X04136_EN_C LCT XL Humidity kit specifications Specifications Remarks Power Source 100-240 Vac / 50-60Hz +6% / -10%, Rating 12-5 A. Max current 10A in 100 Vac Max current 4.5A in 230 Vac Power Consumption 50W-1000W Min-Max when in use 1000 (3400 BTU/hr)

  • Page 91: Auto Paper Size Detection

    X04136_EN_C LCT XL Auto Paper Size Detection Although being able to process several types of standard paper formats, the LCT XL is able to de- tect only some of those standard paper formats. The detection of the paper formats is carried out by using several sensors, which include the sensors mounted on the side guides.

  • Page 92: Declaration Of Conformity Lct

    X04136_EN_C LCT XL EU & UK DECLARATION OF CONFORMITY ......N0007753 (A.1) Manufacturer ..Plockmatic International AB, Telefonvägen 30, S-126 26 Hägersten, Sweden This Declaration of Conformity is issued under the sole responsibility of the manufacturer Object of the Declaration Model/Type...
  • Page 93 X04136_EN_C LCT XL Page intentionally blank.
  • Page 94 X04136_EN_C LCT XL...
  • Page 95 X04136_EN_C LCT XL...
  • Page 96 X04136_EN_C LCT XL...
