Summary of Contents for MasterForce 24225
- Page 1 PRODUCT MANUAL Includes beam Smart Controller REV1220...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARNING: Carton Contents To reduce the risk of injury to persons ..........- FOR RESIDENTIAL USE ONLY Important Safety Instructions Prepare your Garage Door... -
Page 3: Carton Contents
CARTON CONTENTS Residential Jackshaft Remote Control Deluxe Door Manual Release Cable Tension Mounting Bracket Operator Photo Eyes Control Console Collar Cord Monitor DRILL 5/16” DRILL 3/4” DRILL 5/16” beam Smart Battery, Enclosure Door Lock Manual Template Controller & Hardware Wireless Keypad www.masterforceopeners.com 1-877-436-4402... -
Page 4: Prepare Your Garage Door
PREPARE YOUR GARAGE DOOR PREPARE for installation To test your garage door: This operator is compatible with the following doors: 1.Raise and lower the door to check it if there is any sticking or binding. - Sectional doors up to 14 feet (4.3 m) high. 2.Check for loose hinges, damaged rollers, frayed cables, and damaged or broken springs. -
Page 5: Safety Instructions/Tools Needed
TOOLS NEEDED SAFETY INSTRUCTIONS WARNING To reduce the risk of severe injury or death: 1. READ AND FOLLOW ALL INSTALLATION INSTRUCTIONS. Level 2. Install only on a properly balanced garage door. An improperly balanced door has the potential to Adjustable Wrench inflict severe injury. -
Page 6: Assembly
ASSEMBLY Look in the box for: 1. Attach collar to the drive shaft assembly, align one of the set screws to the drive shaft hole. Notice that the side of the collar with the larger hole must be placed on the drive shaft, seated all the way on drive shaft assembly. Residential Jackshaft Operator Securely tighten the 2 square head set screws closest to the motor shaft by turning the screws 1/4 - 1/2 turn after making contact with the motor shaft, use a 3/8”... - Page 7 ASSEMBLY Look in the box for: 1. Close the garage door completely. 2. Position power head on torsion bar and slide garage door opener, leaving a . ¼” (.6 cm) minimum gap between the collar and the side rail bolt. Use a level to align garage door opener. 3.
-
Page 8: Installing Door Lock
INSTALLING DOOR LOCK Look in the box for: The automatic door lock prevents manual operation of the door when fully closed. 1. The lock must be mounted on the same side as the opener and within 10 ft (3.05m) max of the operator. Measure 3 in. above the second roller from the bottom. -
Page 9: Installing Cable Tension Monitor
INSTALLING CABLE TENSION MONITOR Look in the box for: The cable tension monitor will detect slack in the garage door cables. Cable slack is an indication that the door is not closing. When slack is detected, the operator will stop, preventing cable throw. The cable tension monitor must be installed for the operator to function. -
Page 10: Connecting Photo Eye System
CONNECTING PHOTO EYE SAFETY SYSTEM Look in the box for: About Photo Eye Safety System The Photo Eye Safety System provides protection against entrapment while the door is closing. When properly connected and aligned, the emitter Photo Eye emits an invisible infrared light beam while the sensor Photo Eye monitors that beam. If the beam is obstructed during door-closing, the entrapment protection will be triggered and the door will stop and reverse to the open position. -
Page 11: Connectin Deluxe Door Control Console
CONNECTING DELUXE DOOR CONTROL CONSOLE Look in the box for: The Deluxe Door Control Console is a wired, illuminated door control placed inside your garage. To install the Deluxe Door Control Console: Deluxe Door Control Console 1. Find a position in the garage for the Deluxe Door Control Console. It should be mounted at minimum height of 5 feet (1.5m) above the floor to keep out of the reach of children, within sight of door and free from any moving parts on the door. -
Page 12: Motion Activated Securtiy Lighting
MOTION ACTIVATED SECURITY LIGHTING Using the Deluxe Door Control ONLY after Installation is completed. Including setting the limits, see pages 12-14. Buttons Operation Vacation Lock Operation Unlock - Door can be accesed by Door - Press and release to either Door button or controls. open/close the door. -
Page 13: Connecting Power
CONNECTING POWER DO NOT OPERATE OPENER AT THIS TIME To Connect Power: 1. Plug the Opener into a grounded outlet ONLY. If there is no grounded outlet present, call a qualified electrician to replace the outlet. Instructions for Permanent Wiring (If required by Local Code): 1. -
Page 14: Travel Limit Adjustment - Up Limit
TRAVEL LIMIT ADJUSTMENT UP Mark the center line above the door with a pencil. Open door to the highest point of travel. NOTICE: Travel limits and auto force setting must be set for the opener to work. NOTE: PHOTO EYES, CABLE TESNION MONITOR AND About Travel Limit Adjustment AUTOMATIC LOCK MUST BE PROPERLY CONNECTED BEFORE PROGRAMMING THE OPENER. -
Page 15: Travel Limit Adjustment - Down Limit
TRAVEL LIMIT ADJUSTMENT DOWN CAUTION: WHILE SETTING THE DOWN LIMIT, CAREFULLY WATCH DOOR TRAVEL DISTANCE. RELEASE BUTTON WHEN THE DOOR MAKES CONTACT WITH THE GROUND! Setting DOWN Limit 1. Press “LIMIT” button twice to enter DOWN-limit setting. “DOWN” indicator (red) will turn on. *NOTE: Once you have pressed and released the “LIMIT”... -
Page 16: Auto Force Adjustment
AUTO FORCE ADJUSTMENT Following the limit-setting, the unit is now ready to automatically adjust the forces for opening and closing the door. Proceed with the following steps to complete adjustment. 1. With both “UP” and “DOWN” indicators ON, after Travel Limit Adjustment, press the “FORCE” button once to enter Auto Force Adjustment. -
Page 17: Installing Battery Backup
INSTALLING BATTERY BACKUP Install the Battery Backup 1. Unplug the garage door opener. 2. Unscrew the #10-32” screws (2). 3. Fasten the battery bracket to the garage door opener using #10-32” screws (2). 4. Connect battery back up wire to the corresponding terminal on the garage door opener. 5. -
Page 18: Final Adjustments And Testing
FINAL ADJUSTMENT AND TESTING Testing the Safety Reverse System The Safety Reverse System prevents the door from closing when an obstruction is present. 1. Open the door by using the Door Control Console. 2. Place a 1-1/2” (3.8cm) thick solid object (or 2x4 laid flat) on floor under the center of garage door. 3. -
Page 19: Programming Remote Controls
PROGRAMMING REMOTE CONTROLS Look in the box for: To Program Remote Control (s): 1. Press & release the “LEARN” button once on the control panel, “OK” LED will glow and beep. The unit is now ready to accept a remote control in the next 30 seconds. 2. -
Page 20: Programming Wireless Keypad
PROGRAMMING WIRELESS KEYPAD Look in the box for: Press & release the “Learn” button. 2. The “OK” LED will illuminate indicating ready for programming. 3. Garage door opener is ready to accept PIN within the next 30 seconds. Wireless keypad 2 x Lag Screws 2 x Anchors 4. -
Page 21: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of severe injury or death: 1. READ AND FOLLOW ALL INSTRUCTIONS. 2. Never let children operate or play with door controls. Keep the remote control away from children. 3. Always keep the moving door in sight and away from people and objects until it is completely closed. NO ONE SHOULD CROSS THE PATH OF THE MOVING DOOR. 4. -
Page 22: Operating The Opener
OPERATING THE OPENER Battery Backup WARNING Deluxe Door To Prevent SERIOUS INJURY or DEATH: Control - READ AND FOLLOW ALL INSTRUCTIONS AND WARNINGS IN THE OWNER’S MANUAL AND LABELS. - Keep Remote Control and battery out of reach of children. - NEVER permit children to access the Door Control Console, Push Button or Remote Controls. - Page 23 OPERATING THE OPENER Activating the Opener Controls Operation Press and release the large “ACTUATOR” button on the door control, the door will begin to move the door as follows: • Open from closed position or close from opened. • Stops the door while it is closing. •...
- Page 24 OPERATING THE OPENER Courtesy Light / Buzzer Responses Operation / Condition Courtesy Light / Buzzer Responses Opener is initially plugged-in (no travel limits stored see page 14-16) UP and DOWN indicators blink 5 times Reconnecting power (with travel limits stored) Light On for 4.5 minutes “LEARN”...
-
Page 25: Beam Smart Controller Instalation
PAIRING YOUR beam SMART CONTROLLER TO YOUR SMARTHPHONE Look in the box for: beam Smart Controller Note: Smart controller is pre-installed on the garage door opener. beam only connects to 2.4GHz networks. Please perform an actual setup while walking through these steps beam Smart Controller 1. -
Page 26: Maintenance
MAINTENANCE Schedule Maintenance Once a month Door balance test, refer to page 2. Twice a year Safety reversal test, refer to page 15. Once a year • Limit and Force adjustment may be necessary due to weather conditions. Refer to pages 12-14 for adjustment. Conduct Safety Reversal Test after ANY adjustments. -
Page 27: Warranty
WARRANTY Manufacturer hereby warrants to the original purchaser, for initial residence in which it (ii) To any additional damage or deterioration arising from attributable to the operation is installed: of the Operator after it is known to be defective. 1. For residential applications only. Garage Door Operators to be free from defects 7. - Page 28 WARRANTY 9. Subject only to the provisions of the Trade Practices Act and any legislation of the Masterforce Service State or Territory wherein the operators of the Manufacturer have been sold or installed Helpuful product and troubleshooting information may be found online at (which may confer certain rights on consumers of goods and those rights by such www.masterforceopeners.com...
-
Page 29: Replacement Parts
REPLACEMENT PARTS Name/Description Part number 25007 12V, 5Ah Battery, Enclosure & Hardware 24913 Photo Eyes 25003 Remote Control 25004 Deluxe Door Control Console 25008 Collar 25009 Mounting Bracket 25010 Cable Tension Monitor 25011 Door Lock 25012 Emergency Release Cord with Knob 10 25005 Wireless Keypad 25013... -
Page 30: Opener Assembly Parts
OPENER ASSEMBLY PARTS Part number Name/ Description 25017 Control Panel Cover 25018 Light Lens GUDT-368 25019 Chassis Cover GUDT-369 25020 Chassis GUDT-373 25021 Motor Mounting Bracket GUDT-374 25022 Drive Shaft Assembly GUDT-375 Motor & Clutch Assembly 25023 GUDT-376 25024 Transformer GUDT-377 25025 LED Lamp Plate...
