Scan the QR code to access our assembly video.
CCS ASSEMBLY MANUAL
!
Disclaimer:
Hue-mongous Palette & Xtender
Assembly Manual
Caution: Spring-Loaded Mechanism - Always keep one hand on the
Upper Tube (P) when releasing the lever or adjusting the height of your
system to control the spring release.
Warning: This product contains a spring-loaded mechanism that can
generate significant force. Improper handling may result in injury.
Please read through all the steps prior to assembling your system, as
the Xtender will be assembled before connecting it to the Cross Base
(A) in Step 04.
Advertisement
Summary of Contents for OXON Hue-mongous Palette
- Page 1 Scan the QR code to access our assembly video. CCS ASSEMBLY MANUAL Disclaimer: Hue-mongous Palette & Xtender Assembly Manual Caution: Spring-Loaded Mechanism - Always keep one hand on the Upper Tube (P) when releasing the lever or adjusting the height of your system to control the spring release.
-
Page 2: Installation Process
Step 02: Insert Spring Stem INSTALLATION PROCESS TOOLS REQUIRED: Hex Wrench (2) from Bag Two Step 01: Attach Wheels to Cross Base (A) - Spring Stem (Q) TOOLS REQUIRED: Open-end Wrench (1) from Bag One - Upper Tube (P) - Cross Base (A) - Collar (T) - Wheels (B) x4 - Zip Tie (J) - Page 3 Step 03: Attaching Xtender Collar Stand Tube (D) NOTE: If you do not have an Xtender, you can skip this step 03. Collar (T ) TOOLS REQUIRED: Hex Wrench (3) located in Hue~ monstrous palette tools. Upper Tube (P) - Screw (Z) - Arm Sleeve (E) Spring Stem (Q) - Plastic Ring (K)
- Page 4 Step 04: “Connecting Wheels Base to Bottom of Stand” Step 05: “Connecting Ball and Socket Stem to the Pole” TOOLS REQUIRED: Use Tools in Bag Three - Hex Wrench (3). TOOLS REQUIRED: Use Tools in Bag Four-- Hex Wrench (4). 4.1 Take Screw (G) from the toolkit.
- Page 5 Step 06: “Attaching Mounting Plate” Step 07 “Attaching Xtender to Stem Pole” TOOLS REQUIRED: Use bag 3 -Hex Wrench (3), Use bag 5-2x screws. NOTE: If you do not have an Xtender, you can skip this step 07. - Upper Tube (P) TOOLS REQUIRED: None - 2x Screws - Short Arm (Y)
- Page 6 Step 08 “Adding Xtender Arm into Square Tube” Step 09 “Attaching Xtender Square Plate to Arm of Xtender” NOTE: If you do not have an Xtender, you can skip this step 08. NOTE: If you do not have an Xtender, you can skip this step 09. TOOLS REQUIRED: None TOOLS REQUIRED: Xtender Bag- Open-end Wrench (1) - Xtended Arm (N)
- Page 7 Step 10 “Attach Tray to Mounting Plate” Step 11 “Final Assembly Steps” TOOLS REQUIRED: None TOOLS REQUIRED: Tool Bag: (Bag #6) - Socket Wrench (U) – Hex Wrench (2). 11.1 Use the Socket Wrench to tighten the first screw on the Collar (T) again and then use the Hex Wrench (2) to tighten the bottom screw on the collar again.
-
Page 8: Very Important
The perfect tension allows you to push down on any of the four corners to adjust the angle without unlocking and locking each time. Functionality When Using Your Hue-mongous Palette as a Color Cart or Table VERY IMPORTANT! 1. Lock your wheels. - Page 9 Alcohol will crack and cloud your acrylic. This applies to all acrylic connection, as the magnets are very strong. materials. When Removing Your Hue-mongous Palette: What Not to Do: Avoid grabbing the left and right sides of your palette and pulling up.
- Page 10 Zip Tie (J) Stand Tube (D) Collar (T ) Sprig Stem (Q) Tray(X) Screw (Z) Arm Sleeve (E) Plastic RIng (K) T bolt(W), Plastic Gasket (F) Screw (Z) Stand Tube (P) Arm's plate (R) Xtended Arm (N) 3X Nut Collar (T ) Short Arm (Y) Plastic Gasket (F) Screw (G)
