  • Page 1 Instruction Manual Porcelain Firing Furnace AT-100...

  • Page 3: Table Of Contents

    PRG.EDIT Switch STEP Switch ENTER Switch Numerical Switches CLEAR Switch Over-Ride (VAC-Air) Switch LIGHT Switch DOWN Switch UP Switch DRY Switch IDLE Switch NIGHT Switch CALIB Switch C and F Switches START/STOP Switches Product Operating AT-100 Furnace Operating Program parameters...
  • Page 4 Contents Programming AT100 Furnace Programming Displaying and Revision of parametric Values during Thermal Cycle Execution Programming and Revision of other Programs during Main Program Execution IDLE Mode Programming and Functions (AUTO IDLES Mode (Automatic Idling) The NIGHT Program The DRY Program The Allowable Limits of Programmable Furnace Parameters The Door Test Program...

  • Page 5: Dear Customer

    Your furnace can be used for various operations in dentist- ry laboratories including degassing alloys, curing various kinds of porcelain, glazing, etc. The AT-100 Porcelain Firing Furnace is a fully automatic product equipped with a precise control system for high quality curing in the least possible time.

  • Page 6: Section 1- Introduction To Initial Start-Up

    AT-100 Introduction to initial start-up...

  • Page 7: Unboxing

    AT-100 Porcelain Firing Furnace (1-1) Unboxing The packaging of your furnace has been prepared with the proper design for physical protection and according to the corresponding standards. This packaging is waterproof and is resistant to mechanical pressures in the given standards range.

  • Page 8: Device Contents

    Introduction to initial start-up (1-2) Device contents 1.AT 100 Furnace 2.User Manual 3.Special Vacuum Hose 4.Furnace Cable 5.Base 6.Pins & Ceramic Tray 7.Vacuum Pump Manual Vacuum pump Pin and ceramic base Work base Electric Cable Vacuum Hose Table 1 Furnace box contents list...

  • Page 9: System Components

    AT-100 Porcelain Firing Furnace (1-3) System components Muffler and its protector gaurd Place of furnace door Lift details Work base Anodizer plate Panel Fig-2 Device front view (1-4) Device connections Fuse On/Off Vacuum hose Main electricity entrance entrance Vacuum Plaque...

  • Page 10: Device Technical Specification

    Introduction to initial start-up (1-5) Device technical specification Fuses At the back of the furnace, there are two fuses for the mains connection. The specifications of these fuses are printed on their external body. In case of discrepancies between these electrical specifications with those applying in your area, replace these fuses with proper ones.

  • Page 11: Practical Notes

    Porcelain Firing Furnace Furnace General Specifications: -The latest technology and a high-precision temperature controller are used so as to provide users of the AT-100 Furnace with opti- mum results. -Reduced operation time; New production technology -Full demonstration of furnace stages...
  • Page 12 Introduction to initial start-up Safety Precautions during Installation: -Pay close attention to the warnings printed on labels attached to the product -If the safety tips, as well as ambient conditions and operating precautions, are not adhered to while installing this product, certain parts might fail as a result, and the whole system might also be damaged.

  • Page 13: Safety Notes

    AT-100 Porcelain Firing Furnace (1-7) Safety notes (1-7) Safety notes Furnace Installation and Operation 1.Removing the surrounding plastofoams, carefully take the furnace out of its box and put it on a flat standard laboratory table. There must be a free distance of at least 25 cm on all...
  • Page 14 AT-100 Device application...

  • Page 15: Device Panel Description

    AT-100 Porcelain Firing Furnace (2-1) Device panel description Fig-6 Device control panel Mimic Display This is a diagram which demonstrates (through LEDs) the current posting of the furnace as well as the current programming and program execution stages and the execution of heating cycles.

  • Page 16: Step Switch

    display the 9 parameters on the screen and then, apply the re- quired change or programming. Pressing the STEP button, you can review the numerical values of the parameters (from LOW TEMP to VENT) and enter the correct values in their place. Upon completion, press ENTER to save the implemented changes in the system memory.

  • Page 17: Numerical Switches

    AT-100 Porcelain Firing Furnace CLEAR Switch CLEAR This key performs the following: 1.Erasing the numbers entered through the numerical keys and returning the display to viewing parameters (the reverse of what is done via STEP and ENTER). 2.Cutting off alarm sounds 3.Automatic testing of the furnace top door (See Testing the...
  • Page 18 Device application Select 0 to stop the program from going to OVERRIDE mode. -Mode 2: Press END and select “1” to enter the OVERRIDE mode. Thus, upon running each program in the firing cycle and upon expiring of HOLD TIME, the furnace gives the operator one minute to use the OVERRIDE capability.

  • Page 19: Light Switch

    AT-100 Porcelain Firing Furnace mode. The difference between END and STOP keys is that the former does not fully stop the running program and can be used at any time during OVERRIDE. Another application of END is programming the furnace in three modes, namely, Mode 0, Mode 1, and Mode 2 (as was explained above).

  • Page 20: Idle Switch

    Device application can press STOP (See the DRY Program for more details). IDLE Switch IDLE Use this key to run the IDLE program while the furnace is idling and to maintain furnace temperature at the minimum tempera- ture (LOW TEMP). This would decrease the time required for the furnace to reach its lowest temperature as well as increase the useful life and speed of operation.

  • Page 21: C And F Switches

    The STOP key is used for stopping all running programs. Furnace Operation AT-100 Furnace Operating Press the ON/OFF switch (at the back) to turn on the furnace. Wait till the top door fully opens. Furnace Programming Your furnace can run 100 programs for different heating cycles with a maximum temperature of 1200 C.

  • Page 22: Program Parameters

    Device application Program Parameters Note: Throughout the instructions given on furnace operation, the abbreviation TEMP shall be used to denote “temperature”. 1.LOW TEMP: The temperature at which the furnace door be- gins to close. As soon as the door is closed completely, the heating cycle shall start at this temperature.
  • Page 23 AT-100 Porcelain Firing Furnace and seconds for a complete opening of the furnace door. This parameter determined the time required upon expiring of HOLD TIME for the furnace door to open completely. 7.VACUUM LEVEL (VAC): This parameter is used for determin-...
  • Page 24 Device application If VENT is expressed in minutes and seconds in the program, then it is equal to the length of time required for maintaining the vacuum level constant during HOLD TIME. VENT <= HIGH TEMP If VENT is expressed in minutes and seconds in the program, then it shows the length of time required for maintaining the vacuum level constant during HOLD TIME.

  • Page 25: Programming

    AT-100 Porcelain Firing Furnace Programming AT-100 Furnace Programming All the 100 furnace programs have 9 programmable parame- ters which are individually explained in the section on operating the machine and are essential for obtaining the heating cycle performance diagrams (shown on the panel display).
  • Page 26 Device application 1.Put the main switch on “ON” position. The furnace door opens and the left and right displays show the internal muffle temperature and the word “IDLE” respectively. 2.Press the PRG.NO (program number) to view the number of the last reviewed or executed program. 3.Enter your desired program number (for example P .01) by us- ing the numerical keys 0 to 9.
  • Page 27 RATE and the EAT RATE light on the diagram starts blinking. 7.Enter your desired value for HEAT RATE (for example, 56 C per minute) and press ENTER. The digital display automatically moves forward on the parameter, and the TEMP indicator light beside it is turned on while the HIGH TEMP on the thermal di- agram starts blinking, indicating that the final temperature pa- rameter is ready for programming/reviewing.
  • Page 28 Side settings a vacuum. Note 2: Once the negative/vacuum pressure inside the chamber has reached the programmed value (for example, -60), the vacuum pump is automatically turned off. If the pump pressure drops, it is automatically turned on again to control the vacuum level.

  • Page 29: Displaying And Revision Of Parametric Values During Thermal Cycle Execution

    Display and Revision of Parametric Values during Thermal Cycle Execution The AUTO THERM 100 (AT-100) vacuum furnace has been de- signed in such a way that the operator can revise the thermal cycle parameters even during execution. To do this, press PROGRAM EDIT key upon starting the pro- gram.

  • Page 30: Programming And Revision Of Other Programs During Main Program Execution

    Side settings Programming and Revision of other Programs during the Main Program Execution During the running of one of the main programs or any of the DRY, IDLE, or NIGHT capabilities, you can change or revise the information for other main programs. To do this without interrupting the running program, follow the same steps mentioned above for programming.

  • Page 31: (Auto Idles Mode (Automatic Idling)

    AT-100 Porcelain Firing Furnace then automatically stop, and the furnace is allowed to cool. Dur- ing the running of IDLE, it is possible to revise or program other main programs (by pressing PRG NO and entering the main program number) without interrupting IDLE.

  • Page 32: The Dry Program

    5. Press STOP to end the execution of NIGHT. DRY Program The AT-100 muffle is made of the best insulating materials which are very light and resistant against absorption of moisture. If, upon the initial operation of the furnace, you observe leakage and vacuum loss, run the Dry program.

  • Page 33: The Allowable Limits Of Programmable Furnace Parameters

    The Allowable Limits of Programmable Furnace Parameters The following table shows the numerical values of the nine pa- rameters. When programming the heat treatment parameters, the max- imum and minimum allowable values must be observed. The system displays an error message if values other than those given in the table are entered.

  • Page 34: Service & Maintenance

    AT-100 Service and maintenance...

  • Page 35: Calibration

    AT-100 Porcelain Firing Furnace (4-1) Service and mainenance Calibration Calibration is the exact adjustment of the factors required for porcelain curing. These factors include heat and vacuum. Heat Calibration First press CALIB and wait for the left display to show “Calib”...

  • Page 36: Safety Principles

    Note 2: Remember to run the vacuum calibration program after installation and before operating the furnace for the first time. Safety Principles This section involves two sub-sections: 1.Mechanical safety principles 2.Electrical safety principles Mechanical safety principles 1.The lifting mechanism is so designed that it requires no lubri- cation whatsoever.
  • Page 37 -Unauthorized personnel must not be allowed to operate this product. In case of such operations, Polaris Company shall ac- cept no responsibility regarding the possible consequences. -After cleaning, never power on the product before it is com- pletely dried.

  • Page 38: Troubleshooting

    Alarm Problem Solution AL1- Temperature exceeding Turn off the furnace and 1200 C immediately call the After Sales Services Unit AL2- Fault in the lift operation -Probably there is a problem with the microswitch -Check the Up and Down micro switches and adjust or replace it if necessary -Alternatively, there...
  • Page 39 AT-100 Porcelain Firing Furnace AL8- Some problem with A/D Replace A/D AL9- Faulty solenoid valves -Calibration was probably done while the pump was off -The connections (hose and pump power cable) might have been cut -Replace or repair/ service the solenoid...

  • Page 40: Contact Us

    Calling the aftersales services Unit of Polaris Co. +49 (0) 21033373500 +49 (0) 21033373550 www.polarisgmbh.com Service@polarisgmbh.com Email...
