INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS
I.
INTRODUCTION
The AMI Model 15l is designed to operate with an AMI liquid helium (LHe) level sensor
up to 60 inch (152.4 cm) in length for 4.2K operation only.
The Model 151 includes an optional 0-100 mV input from an external source for
displaying a corresponding 0-100% LHe level.
The Model 151 also includes a optional gauge pressure port for 0-5 psig display.
The Model 151 includes a replaceable COTS lithium battery pack with an external
charge port. Battery status is conveniently displayed to the nearest 10% of remaining
capacity.
The display is an e-ink style which maintains the last measurement display after the
power is removed.
Present LHe
LEVEL
Pressure Port
Value
A USB connector is provided that functions as a Virtual COM Port (VCP) when
connected to a computer. The USB interface is interactive in a standard serial terminal
emulating app. USB features include the ability to perform user calibrations for sensor
lengths other than the default 60 inches, calibrate the digital voltmeter input, and set
the local time.
EXCELLENCE IN MAGNETICS AND CRYOGENICS
Fax: (865) 482-5472
AMI MODEL 151
LIQUID HELIUM LEVEL METER
L H e L E V E L ( % )
80.0
P R E S S U R E 3 . 5 P S I G
2 4 A P R 2 0 2 3
Rev. 6, 17 Mar 2025
I N P U T :
L H e S e n s o r
B AT T E R Y :
7 0 %
1 5 : 3 0
Active INPUT
Selection
BATTERY
Status
Date/Time of
Last Reading
