Specification
CC-3607WT-80
Model
Pick up Element
1/3" SONY Super HAD CCD
Effective Picture Elements
NTSC:976(H)×494(V)
(H×V)
720 TV Line
Horizontal Resolution
Minimum Illumination
0.001 Lux/F1.2
S/N Ratio
More than 52dB
2:1 interface
Scanning System
Synchronous System
Internal, Negative sync.
NTSC: 1/60s~1/100,000s
Auto Electronic Shutter
Gama Characteristic
0.45
262 Ft (with ￠42X4 PCS Infrared LED)
IR Distance
IR Status
Under 10Lux by CDS
CDS AUTO Control
IR Power On
Video Output
1Vpp, 75Ω
Auto
Auto Gain Control
24VAC/12VDC(+/-10%)/1500mA
Power/Current
6 22mm Manual Zoom Lens
Lens
Dimension (IN)
9.1(W)x7.1(H)x4.6(D)
4.63
Weight (lb)
Storage Temperature
-22°F~140°F RH95% MAX
-40°F~122°F RH95% MAX
Operating Temperature
（with heating system)
Packing List
No
Name
1.
Weatherproof IR Color Camera
CC-3607WT-80
2.
Wall Mount
CHM-3600
3.
User Guide
CC-3607WT-80
II
Model
Number
1
1
1
ALLIANCE DRIVE
GREENSBORO, NC
-
- -CREST/
-
-
FAX:
-
-
www.crestelectro ics.co
CC-3607WT-80
Color Camera
Weatherproof IR
Color Camera w/mount
EFFIO A
NOTE:
Please read this guide
BEFORE installing
Advertisement
Summary of Contents for Crest Electronics CC-3607WT-80
- Page 1 Specification CC-3607WT-80 CC-3607WT-80 Model Color Camera Pick up Element 1/3" SONY Super HAD CCD Effective Picture Elements NTSC:976(H)×494(V) (H×V) 720 TV Line Horizontal Resolution Minimum Illumination 0.001 Lux/F1.2 S/N Ratio More than 52dB 2:1 interface Weatherproof IR Scanning System Color Camera w/mount Synchronous System Internal, Negative sync.
- Page 2 ● This installation should be made by a qualified service person ◆ Check to make sure the CAMERA ID and conform to all local codes. Crest Electronics will not be ROLLING PICTURE coax shield responsible for damages or injuries as a result of improper...
