USER MANUAL Grill & Prep Cart Model: TDT-GHS-XLCT CONTENTS What’s in the Box Assembly Instructions Modular Compatibility Specifications Parts Diagram & List Warranty... -
Page 2: What's In The Box
WHAT'S IN THE BOX Table Shelf Cutting Board Side Shelf Tabletop Chassis Cart Middle Shelf Tank Lock Cover Tank Hole Cover Cart Side Panel, Cart Base Cart Side Panel, Left Right 1 Wing Nut Screw (Not Pictured) GRILL & PREP CART USER MANUAL... -
Page 3: Assembly Instructions
ASSEMBLY INSTRUCTIONS STEP 1 Set the Grill & Prep Cart on its casters. Pull the captive pin on the left side of the cart, then pull front and rear panels apart. When the cart is expanded and the bottom shelf is flat and secure, the pin will lock into place. - Page 4 ASSEMBLY INSTRUCTIONS STEP 3 Repeat Step 2. Cart Side Panel, Right STEP 4 Place the tabletop chassis onto the cart, aligning the four plastic feet with the slots in the cart’s frame. Tabletop Chassis GRILL & PREP CART USER MANUAL...
- Page 5 Grill & Prep Cart. If you connect the Grill & Prep Cart to a TYTUS Anaheim 4-Burner Gas Grill, you can leave the tank hole cover and tank lock hole cover in place, as you will use the propane tank in the Anaheim 4-Burner Gas Grill to power your gas portable unit.
- Page 6 ASSEMBLY INSTRUCTIONS STEP 7 Install your center shelf in the Grill & Prep Cart by aligning the four holes with the four pins on the shelf support bar. The flat side of the shelf faces towards the ground. To use the Grill & Prep Cart with a portable gas unit, without attaching to the Anaheim 4-Burner Gas Grill, remove the center shelf from the cabinet, and store it on the rear of the cabinet, using the provided hooks.
- Page 7 STEP 9 Place your cutting boards into the cut-outs on the top of each side shelf. Cutting Board STEP 10 Place the prep table into the tabletop chassis to complete your Grill & Prep Cart. The bullnose aligns with the front of the unit. This must be removed to install a portable unit. Prep Table (855) 969-5185 | TYTUSGRILLS.COM...
- Page 8 ASSEMBLY INSTRUCTIONS STEP 11 Lock the casters on the rear of the Grill & Prep Cart to keep it in place. DISASSEMBLY INSTRUCTIONS STEP 1: Remove the portable unit or the prep table (whichever is currently installed) from the center of the top cap and set aside.
-
Page 9: Modular Compatibility
MODULAR COMPATIBILITY This Grill & Prep Cart is part of the TYTUS MODULAR COLLECTION. To connect your Wildwood Grill & Prep Cart to the TYTUS Modular Collection portable units and the Anaheim 4- Burner Gas Grill, follow the instructions below. - Page 10 MODULAR COMPATIBILITY With two people, line up the Grill & Prep Cart on the side of the Anaheim 4-Burner Gas Grill, ensuring the doors are facing the same side, and press the cart onto the brackets attached to the brackets on the burner box of the grill. NOTE: It is easiest to install a Grill &...
- Page 11 To connect a gas tabletop to the RIGHT Grill & Prep Cart, remove the center prep table. Place your portable unit on your Grill & Prep Cart, threading the gas hose through the center access hole. (855) 969-5185 | TYTUSGRILLS.COM...
- Page 12 MODULAR COMPATIBILITY Thread the gas hose through the side panels and connect to the “T” gas hose assembly inside the main cart of the Anaheim 4-Burner Gas Grill. GRILL & PREP CART USER MANUAL...
- Page 13 To connect an electric or charcoal tabletop to the left or right Grill & Prep Cart, remove the center prep table. Place the portable grill into the chassis. (855) 969-5185 | TYTUSGRILLS.COM...
- Page 14 MODULAR COMPATIBILITY 10. Completed Modular Grill. GRILL & PREP CART USER MANUAL...
-
Page 15: Specifications
SPECIFICATIONS DIMENSIONS SPECS Compatible with all Assembled Width 55.3 inches Fuel Type portable units Assembled Depth 20.7 inches Tool Hooks Assembled Height 36.3 inches Side Shelves Main Prep Area 462.3 sq. inches Casters (W & D) (23” by 20.1”) Secondary Prep Area 337.92 sq. -
Page 16: Parts Diagram & List
PARTS DIAGRAM & LIST PARTS DIAGRAM GRILL & PREP CART USER MANUAL... - Page 17 PARTS LIST Part # Description TYTUS Part # Part # Description TYTUS Part # Tabletop chassis DJ-50015-01 Door frame DJ-50015-18 TFR-LCT-086 Locking click Cart side panel L DJ-50015-19 Top cap feet TFR-LCT-085 Door pin TFR-MCT-042 Cutting board DJ-50015-04 Magnet DJ-50015-21...
-
Page 18: Warranty
(the “Products” or “Product” when referencing a singular product herein). Tytus Grills, LLC (“Tytus”) warrants the Products identified above to be free from defects in material and workmanship, for the relevant and specified Warranty Periods set forth below for specific parts or components of the Products, under proper use, maintenance, and care according to the owner’s manual, warnings, and instructions accompanying the Products:... - Page 19 United States and Canada, and only applies to products purchased and serviced in the United States and Canada. All replaced parts and Products, and Products on which a refund is made, become the property of Tytus. The addition of equipment or features to the Product that are not manufactured or recommended by Tytus could affect the intended function of the Product, and therefore may void the Warranty.
- Page 20 TYTUS and TYTUS Grills are trademarks of TYTUS Grills, LLC. © 2024 TYTUS Grills, LLC. Designed in the USA. Made in China. Distributed by TYTUS Grills, LLC, Edina, MN.
