  • Page 1 LCD Monitor User Manual 24B15H2 ® www.aoc.com ©2025 AOC. All Rights Reserved.

  • Page 2: Table Of Contents

    Safety ....................................1 National Conventions ..............................1 Power ..................................2 Installation ................................. 3 Cleaning ..................................4 Other ..................................5 Setup ....................................6 Contents in Box ................................. 6 Setup Stand & Base ..............................7 Adjusting Viewing Angle ............................8 Connecting the Monitor ............................. 9 Clear Vision ........

  • Page 3: Safety

    Safety National Conventions The following subsections describe notational conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system.

  • Page 4: Power

    Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. only into a grounded power outlet as a safety feature.

  • Page 5: Installation

    Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product.

  • Page 6: Cleaning

    Cleaning Clean the cabinet regularly with cloth. You can use soft-detergent to wipe out the stain, instead of strong-detergent which will cauterize the product cabinet. When cleaning, make sure no detergent is leaked into the product. The cleaning cloth should not be too rough as it will scratch the screen surface.

  • Page 7: Other

    Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the LCD monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation.

  • Page 8: Setup

    Setup Contents in Box Monitor Warranty card Stand Base Power Adapter HDMI Cable DP Cable Not all signal cables will be provided for all countries and regions. Please check with the local dealer or AOC branch...

  • Page 9: Setup Stand & Base

    Setup Stand & Base Please setup or remove the base following the steps as below. Setup: Remove:...

  • Page 10: Adjusting Viewing Angle

    Adjusting Viewing Angle For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference. Hold the stand so you will not topple the monitor when you change the monitor’s angle. You are able to adjust the monitor as below: NOTE: Do not touch the LCD screen when you change the angle.

  • Page 11: Connecting The Monitor

    Connecting the Monitor Cable Connections In Back of Monitor and Computer: HDMI D-SUB 3. Power Connect to PC Connect the power adaptor to the back of the display firmly. Turn off your computer and unplug its power cable. 3. Connect the display signal cable to the video connector on the back of your computer. 4.

  • Page 12: Clear Vision

    Clear Vision 1. When the OSD is not displayed, press the "<" button to activate Clear Vision. one 2. Use the "<" or ">" button to select settings such as weak, medium, strong, or off. The default setting is always' off ' 3.

  • Page 13: Adjusting

    Adjusting Hotkeys Source/Auto/Exit Clear Vision/< Image Ratio/> Menu/Enter Power Menu/Enter Power Press the Power button to turn on the monitor. Image ratio/> When the OSD menu is turned off, press the ">" key to enter the image scale switching function, and press the "<" or ">" key to switch between 4:3 or widescreen modes.

  • Page 14: Osd Setting

    OSD Setting Basic and simple instruction on the control keys. Luminance Image Setup Color Setup Picture Boost OSD Setup Game Setting Extra Exit Contrast Gamma Gamma 1 Brightness Eco mode Standard HDR Mode 1). Press the MENU-button to activate the OSD window. 2).

  • Page 15: Luminance

    Luminance Luminance Image Setup Color Setup Picture Boost OSD Setup Game Setting Extra Exit Contrast Gamma Gamma 1 Brightness Eco mode Standard HDR Mode Contrast 0-100 Contrast from Digital-register. Brightness 0-100 Backlight Adjustment. Standard Standard Mode. Text Text Mode. Internet Internet Mode.

  • Page 16: Image Setup

    Image Setup Color Setup Picture Boost OSD Setup Game Setting Extra Exit Luminance Image Setup Clock H. Position Phase V. Position Sharpness Adjust the image clock to reduce vertical line noise Clock 0-100 Adjust the image phase to reduce horizontal line noise Phase 0-100 Adjust the sharpness of the image.

  • Page 17: Color Setup

    Color Setup Color Setup Picture Boost OSD Setup Game Setting Extra Exit Luminance Image Setup Color Temp. Warm DCB Mode Green DCB Demo Blue Warm Warm Color Temperature Normal Normal Color Temperature Color Temp. Cool Cool Color Temperature User Color Temperature 0-100 Red gain from Digital-register.

  • Page 18: Picture Boost

    Picture Boost Picture Boost OSD Setup Game Setting Extra Exit Luminance Image Setup Color Setup Bright Frame Brightness H. Position Frame Size Contrast V. Position Bright Frame Disable or Enable Bright Frame. Frame Size 14-100 Adjust Frame Size. Brightness 0-100 Adjust Frame Brightness.

  • Page 19: Osd Setup

    OSD Setup Extra Exit Luminance Image Setup OSD Setup Game Setting Color Setup Picture Boost Language English H. Position Transparence V. Position Timeout Break Reminder Language Select the OSD language. Timeout 5-120 Adjust the OSD Timeout. H. Position 0-100 Adjust the horizontal position of OSD. V.

  • Page 20: Game Setting

    Game Setting Extra Exit Picture Boost OSD Setup Game Setting Luminance Image Setup Color Setup Game Mode LowBlue Mode DialPoint Shadow Control Game Color No optimization by Smart image game Improves dark theme black level details. For playing RTS (Real Time Strategy). Improves the image quality.

  • Page 21: Extra

    Extra Game Setting Extra Exit Luminance Image Setup Picture Boost OSD Setup Color Setup Input Select Auto Image Ratio Wide Resolution : 1920(H)X1080(V) Auto Config. DDC/CI H. Frequency : 68KHz Off Timer Reset V. Frequency : 60Hz Input Select Auto/HDMI/DP Select Input Signal Source.

  • Page 22: Exit

    Exit Exit Exit the main OSD...

  • Page 23: Led Indicator

    LED Indicator Status LED Color Full Power Mode White Orange...

  • Page 24: Troubleshoot

    Adjust the maximum resolution and frequency that the monitor can handle properly. Make sure the AOC Monitor Drivers are installed. Adjust the Contrast and Brightness Controls. Picture Is Fuzzy & Has Press to auto adjust.

  • Page 25: Specification

    Specification Model Name 24B15H2 Driving System TFT Color LCD Viewable Image Size 60.5 cm diagonal Panel Pixel Pitch 0.2745mm(H) x 0.2745mm(V) Video HDMI lnterface & R,G,B Separate Sync. H/V TTL Display Color 16.7M 30k-85kHz (D-SUB) Horizontal Scan Range 30k-115kHz (HDMI) Horizontal scan Size(Maximum) 527.04mm...

  • Page 26: Preset Display Modes

    Preset Display Modes HORIZONTAL VERTICAL STANDARD RESOLUTION FREQUENCY(KHz) FREQUENCY(Hz) 640x480@60Hz 31.469 59.94 640x480@72Hz 37.861 72.809 640x480@75Hz 37.500 75.000 MAC MODES VGA 640x480@67Hz 35.000 66.667 IBM MODE 720x400@70Hz 31.469 70.087 800x600@56Hz 35.156 56.25 800x600@60Hz 37.879 60.317 SVGA 800x600@72Hz 48.077 72.188 800x600@75Hz 46.875 75.000 MAC MIDE SVGA...

  • Page 27: Pin Assignments

    Pin Assignments Pin No. Signal Name Pin No. Signal Name Pin No. Signal Name TMDS Data 2+ TMDS Data 0- DDC/CEC Ground TMDS Data 2 Shield TMDS Clock + +5V Power TMDS Data 2- TMDS Clock Shield Hot Plug Detect TMDS Data 1+ TMDS Clock- TMDS Data 1Shield...

  • Page 28: Plug And Play

    Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.
  • Page 29 5614-24SD-2014 140*210mm 成品无白边...
