Bolderton SPORTSMAN'S GUIDE 716241 Manual

2man 500lb bear
Hide thumbs

Advertisement

Quick Links

Download this manual
Congratulations on your Bolderton purchase.
You demand the best in outdoor gear, and Bolderton delivers with professional-grade
quality and performance that keep you at the top of your game.
BOLDERTON 2MAN 500LB BEAR
Item #716241
For assistance with your product, please contact Sportsman's Guide customer
service at 1-800-888-3006 Mon.-Fri. 7:00am to 9:00pm, Sat.-Sun. 8:00am to 8:00pm
CST or go to sportsmansguide.com/customerservice/contactus
sportsmansguide.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the SPORTSMAN'S GUIDE 716241 and is the answer not in the manual?

Questions and answers

Related Manuals for Bolderton SPORTSMAN'S GUIDE 716241

Summary of Contents for Bolderton SPORTSMAN'S GUIDE 716241

  • Page 1 Congratulations on your Bolderton purchase. You demand the best in outdoor gear, and Bolderton delivers with professional-grade quality and performance that keep you at the top of your game. BOLDERTON 2MAN 500LB BEAR Item #716241 For assistance with your product, please contact Sportsman’s Guide customer service at 1-800-888-3006 Mon.-Fri.

  • Page 2: Carrying Capacity

    A “Treestand Safety: It’s Up To You” DVD has been included with this serious injury or death! treestand. Please view it in its entirety prior to using this or any other Bolderton product(s). Failure to follow these instructions may result in serious injury or death!
  • Page 3 Failure to follow these instructions may result in serious injury or death! These include, but are not limited to, weather or other environmental factors that can negatively a ect its performance. Animals can also cause damage to your Bolderton jump or bounce on the treestand platform and/or the seat...
  • Page 4 WARNING! THE SAFE USE AND OPERATION OF THIS BOLDERTON PRODUCT IS THE harness and its components (i.e., lanyard/tether, tree belt, suspension relief device, SOLE RESPONSIBILITY OF THE USER. IT IS ALSO THE SOLE RESPONSIBILITY OF THE climbing belt/lineman’s belt [as applicable]) at ground-level prior to attempting to use...
  • Page 5 ATTENTION!! WHEN YOU SEE A “ WARNING!” BE SURE TO HEED THE MESSAGE! THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!! NOTE: STEP 4. Once you have reached your desired height, insert the tree belt through If leg straps are too long, feed right leg strap with buckle through bottom of the the loop of the tether (Fig.
  • Page 6 Should you have any questions about the assembly, installation or use of this Bolderton product, or any other Bolderton products, please do not hesitate to call one of our customer service representatives at 800-888-3006 and they will answer all questions you may have about any of the complete line of Bolderton products.
  • Page 7 ATTENTION!! WHEN YOU SEE A “ WARNING!” BE SURE TO HEED THE MESSAGE! THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!! GGL61-B • PARTS LIST Part # Description Part # Description GG20-0447 Seat Assembly XP19-0040 Ladder Section A XP19-0446 Seat Tension Bar XP15-0506...
  • Page 8 ATTENTION!! WHEN YOU SEE A “ WARNING!” BE SURE TO HEED THE MESSAGE! THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!! GGL61-B • HARDWARE PACK Part # Description Part # Description UP77-0001 1/4” Nylock Nut UP77-0008 1/4“ Nylon Spacer UP77-0029 5/16”...
  • Page 9 NOTE: Step 1-15 require that you temporarily nger tighten all nuts and bolts until instructed to tighten. This will ensure proper alignment during assembly. ASSEMBLY INSTRUCTIONS - GGL61-B • BOLDERTON 2MAN 500LB BEAR FIGURE 1 Mainframe Extension Rear Frame...
  • Page 10 WARNING!” BE SURE TO HEED THE MESSAGE! THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!! - GGL61-B • BOLDERTON 2MAN 500LB BEAR STEP 4. Connect the front and rear foot platforms together using two (2) 1/4"x 1 3/4" hex bolts [C], four (4) nylon washers, and two (2) 1/4"nylock nuts.
  • Page 11 ATTENTION!! WHEN YOU SEE A “ WARNING!” BE SURE TO HEED THE MESSAGE! THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!! - GGL61-B • BOLDERTON 2MAN 500LB BEAR FIGURE 3 Rear Support Hoop Right Side Seat Support Back Tension...
  • Page 12 ATTENTION!! WHEN YOU SEE A “ WARNING!” BE SURE TO HEED THE MESSAGE! THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!! - GGL61-B • BOLDERTON 2MAN 500LB BEAR 1/4“ Nylon FIGURE 4 Spacer 1/4“ Nylon FIGURE 4A Spacers...
  • Page 13 ATTENTION!! WHEN YOU SEE A “ WARNING!” BE SURE TO HEED THE MESSAGE! THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!! FIGURE 5A FIGURE 5 Side Shooting Armrest Cover Rail Piece Shooting Shooting Shooting Armrest Foam Rail Foam Rail Cover Rail Rest Shooting...
  • Page 14 WHEN YOU SEE A “ WARNING!” BE SURE TO HEED THE MESSAGE! THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!! - GGL61-B • BOLDERTON 2MAN 500LB BEAR FIGURE 6 STEP 14. Attach jaws to rear frame support installing one jaw on top of rear frame sup- port and one jaw on bottom of rear frame support (as shown in Fig.
  • Page 15 THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!! FIELD INSTRUCTIONS - GGL61-B • BOLDERTON 2MAN 500LB BEAR STEP 1. Select a straight, healthy tree; one devoid of dead branches and loose bark. DO NOT attempt to install this proudct on a tree is not healthy.
  • Page 16 ATTENTION!! WHEN YOU SEE A “ WARNING!” BE SURE TO HEED THE MESSAGE! THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!! - GGL61-B • BOLDERTON 2MAN 500LB BEAR FIGURE 3 Jaw tightening Cable Jaw tightening Cable NOTE: Con rm the two (2) jaws are in the fully open position and jaw tightening cables are run properly through the cable guide eye bolts.
  • Page 17 ATTENTION!! WHEN YOU SEE A “ WARNING!” BE SURE TO HEED THE MESSAGE! THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!! - GGL61-B • BOLDERTON 2MAN 500LB BEAR FIGURE 4 Three (3) inches Three (3) Feet NOTE: The bottom ladder section is specially designed to allow the bottom to drive into the ground.
  • Page 18 ATTENTION!! WHEN YOU SEE A “ WARNING!” BE SURE TO HEED THE MESSAGE! THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!! - GGL61-B • BOLDERTON 2MAN 500LB BEAR FIGURE 5 Lower Bark Biter Tree Piece Lower Bark Biter...
  • Page 19 WHEN YOU SEE A “ WARNING!” BE SURE TO HEED THE MESSAGE! THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!! - GGL61-B • BOLDERTON 2MAN 500LB BEAR FIGURE 7 STEP 8a. When the lower bark biters are secured using the ratch-...
  • Page 20 ATTENTION!! WHEN YOU SEE A “ WARNING!” BE SURE TO HEED THE MESSAGE! THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!! - GGL61-B • BOLDERTON 2MAN 500LB BEAR FIGURE 9 NOTE: Your lower bark biters should be firmly gripping the tree at this time, and the Jaws should be firmly gripping the tree.
  • Page 21 ATTENTION!! WHEN YOU SEE A “ WARNING!” BE SURE TO HEED THE MESSAGE! THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!! FIGURE 10 Ratchet Strap C Ratchet Strap C Jaw Tension Cables Ratchet Strap A Ratchet Strap B Assembly GURE 2 STEP 10.
  • Page 22 Instruction Manual may result in serious injury or death! WARNING! This Bolderton product is designed for adult use only! No one under the age of 16 should attempt to use this or any Bolderton products without direct adult supervision. Failure to follow these instructions may result in serious injury or death! READ THIS MANUAL IN ITS ENTIRETY PRIOR TO USING THIS PRODUCT.

  • Page 23: Standard Limited Warranty

    ATTENTION!! WHEN YOU SEE A “ WARNING!” BE SURE TO HEED THE MESSAGE! THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!! STANDARD LIMITED WARRANTY Warranty: WW Industrial Corp warrants all WW Industrial Corp climbing system products and hunting acces- sories to be free from defects in material and workmanship for a period of twelve months from the original date of retail purchase.
  • Page 24 This Bolderton product(s) has been tested to rigid industry standards. Safe operation and use of this Bolderton product(s) is the responsibility of the user(s). Please read and follow all safe use instructions and warnings. Failure to follow these may result in serious injury or death! First Edition, May 2020.
