- Page 1 OUR EXPERTISE & PROJECTS soprasolar.com Installation guide SOPRASOLAR FIX EVO TILT ® ALUMINUM & POLYAMIDE raisers SOLAR ENERGY MANAGEMENT...
- Page 2 Who are we? INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT Overview Who are we? OUR EXPERTISE & PROJECTS soprasolar.com...
- Page 3 The company installs millions of square meters of energy-generating capabilities into their flat roofs. waterproofing, roofing, insulation, and protection systems across the globe. SOPREMA® plays a key role in many large-scale projects, such as the European Parliament in Strasbourg, Wembley Stadium, Ferrari World, and the Both in France and internationally, SOPRASOLAR®’s...
-
Page 4: Specifications
Introduction INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT Introduction Note The recommended systems shown here are examples. Each case is unique, so it is essential to consult SOPRASOLAR® for every project to validate the solution that best meets the building’s needs. The installation of waterproofing membranes must be carried out according to industry best practices and, where applicable, in accordance with... - Page 5 Introduction INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT SOPRASOLAR FIX EVO TILT Systems ® Example: On concrete deck SOPRADÈRE® or AQUADÈRE® ÉLASTOVAP PIR Insulation adhered with SOPRACOLLE® 300 N SOPRASTICK® SI SOPRALÈNE® FLAM 180 AR or ALU SOPRASOLAR® FIX EVO Pedestals SOPRASOLAR®...
- Page 6 Preparation Étape 1 : Préparation INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT You are at stage Preparation List of recommended documents This installation manual for SOPRASOLAR® FIX EVO TILT The Execution Drawing (EXE) issued by SOPRASOLAR® List of tools required for implementation Standard roofer’s tools (gas, torch, gloves, etc.)
- Page 7 Preparation INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT Description of the various components benefits FIX EVO 250 Pedestal FIX EVO 300 Pedestal No waterproofing Adjustable polyamide pedestal Adjustable polyamide pedestal penetration reinforced with fiberglass, reinforced with fiberglass, featuring a bituminous plate. featuring a bituminous plate.
- Page 8 Stage 2: Installation of the pedestals INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT You are at stage Installation of the pedestals It is essential to check all dimensions of the flat roof before proceeding with any marking. Marking the location of the pedestals Before proceeding further on worksite, it is important to print the execution drawing (EXE) in the appropriate format (as indicated on the plan;...
- Page 9 Stage 2: Installation of the pedestals INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT → Verify the roof dimensions and the location of → Position the SOPRASOLAR® FIX EVO pedestals. hindrances in relation to the EXECUTION DRAWING The center of each pedestal is marked by before any marking.
- Page 10 Stage 2: Installation of the pedestals INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT You are at stage Welding of the SOPRASOLAR FIX EVO flange ® → → Ensure the positioning of the SOPRASOLAR® FIX EVO Degrease the visible Slate chippings on the pedestals.
- Page 11 Stage 2: Installation of the pedestals INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT → → Heat the underside of the flange once again. Confirm the welding of the flange edges using a spatula. → Apply the pedestal to the membrane and press down to confirm the weld.
- Page 12 Waterproofing membrane protection INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT You are at stage Waterproofing membrane protection ALUMINIZED MEMBRANES The occurrence of damage due to foot traffic and equipment movement is a concern for all types of membranes. Membranes with aliminum facing are finish are particularly sensitive, and aesthetic damage is exacerbated in high temperatures.
- Page 13 Stage 2: Installation of the Pedestals INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT Welding the flange of the pedestals onto SOPRALÈNE FLAM 180 ALU (Aluminum facing) → → Cut the foil sheet using a box cutter, considering a 1-cm- Finish removing the cutout. The bitumen should be wide setback from the markings you had cautiously exposed.
- Page 14 Stage 3: Raisers (ALUMINUM Version) INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT You are at stage Raisers version ALUMINUM The raisers connect the pedestals to the photovoltaic modules, creating a 10° inclination relative to the roof. The ALUMINUM raiser version must adhere to specific configurations (see diagram below). Installation of upper and lower raisers and the blocker →...
- Page 15 Stage 3: Raisers (POLYMER Version) INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT You are at stage Raisers version POLYAMIDE The raisers connect the pedestals to the photovoltaic modules, creating a 10° inclination relative to the roof. The POLYAMIDE raiser version must adhere to specific layout plans (see diagram below). Installation of upper and lower raisers and blockers →...
- Page 16 Stage 4: Installation of the PV Modules Étape 4 : Pose des modules INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT You are at stage Installation of photovoltaic modules Important → Two individuals are required to handle a module → The presence of an electrician on worksite is essential for the electrical connection of the modules...
- Page 17 Étape 4 : Pose des modules Stage 4: Installation of the PV Modules INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT Positioning of the modules Important: Do not secure the modules to the pedestals until the electrician has completed the connections with the adjacent Connection Loop modules.
- Page 18 Stage 5: Connection and grounding Étape 5 : Raccordement et mise à la terre INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT You are at stage Connection and grounding...
- Page 19 Étape 5 : Raccordement et mise à la terre Stage 5: Connection and grounding INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT Connection and grounding Principle of grounding photovoltaic Hook for touting cables through ↓ ↓ modules, raisers (ALUMINUM the roof version only), and cable trays To be performed by a qualified person.
-
Page 20: Self-Inspection
Who are we? Autocontrôle INSTALLATION MANUAL SOPRASOLAR® FIX EVO TILT Self-Inspection... - Page 21 Conduct a mechanical check using a tester. Installation of raisers (TILT version) and clamps → For the tilted version (SOPRASOLAR FIX EVO TILT), verify the installation of the raisers and the raiser blockers according to the execution drawing. → Check the tightening of the clamps, securing the photovoltaic modules.
- Page 22 OUR EXPERTISE & PROJECTS soprasolar.com Installation of SOPRASOLAR FIX EVO TILT ® SOPREMA Group, at your service Contact our Are you interested in Soprasolar® systems? sales team Do you have technical questions about the implementation of our systems? Would you like to stay updated on our latest news and be the first to know...
