BG-1000 Revision 1
Optergy Air Transceiver (BG-1000)
Installation Guide
A how-to-guide on installing the Optergy Air transceiver.
When used together with the Optergy Air sensor range and
the Optergy P864 controller, these components can measure
and communicate an environment's metrics. The number and
type of these metrics depend upon which model of sensor is
used.
Advertisement
Table of Contents
Summary of Contents for Optergy Air BG-1000
- Page 1 Optergy Air Transceiver (BG-1000) Installation Guide A how-to-guide on installing the Optergy Air transceiver. When used together with the Optergy Air sensor range and the Optergy P864 controller, these components can measure and communicate an environment’s metrics. The number and type of these metrics depend upon which model of sensor is used.
-
Page 2: Table Of Contents
Contents Before Installation Wiring Pairing Mounting Installation Instructions Signals Troubleshooting optergy.com... -
Page 3: Before Installation
Before setting up the Optergy Air wireless sensor and transceiver, you must first have set up the Optergy P864 controller. Please follow the Optergy P864 installation guide prior to proceeding with this sensor and transceiver installation. -
Page 4: Wiring
The transceiver is used to facilitate communication between the Optergy P864 controller and the wireless sensor. Its appearance is similar to some of the Optergy Air wireless sensor range, however it can be easily differentiated once opening the back plate. The sensor requires batteries and the transceiver does not. -
Page 5: Pairing
Once in the paired state the Optergy Air wireless sensor will flash green once every thirty seconds, and it will display a card in the user interface. This card will show all of the sensor’s metrics, the ability to blink the sensor’s LED for identification, and an option to remove the sensor pairing from that slot. - Page 6 If a sensor is required to be removed for any reason, this can be completed in the user interface or physically using the sensor’s button. Simply click ‘Remove’ in the user interface to remove the pairing, or otherwise click and hold the pairing button for two seconds on the wireless sensor. optergy.com...
-
Page 7: Mounting
Optergy P864 controller, and distance from the wireless sensors. The transceiver can be run up to 30m from the Optergy P864 controller, and it is best practice to run this as close to the wireless sensors as possible to account for any attenuation caused by environmental obstacles. -
Page 8: Installation Instructions
Rotate housing Once fixed to the towards the wall wall, rotate the until it clicks with housing as required the wall plate. to achieve a vertical position. CLICK! optergy.com... -
Page 9: Signals
At various times of the setup of the device, or in the troubleshooting of the device, both the transceiver or sensor may flash their LEDs in varying frequencies and colours. If unsure as to the state of the device please refer to the following table: optergy.com... -
Page 10: Troubleshooting
Please ensure that the Optergy P864 is on version v6.0.5 or above in order to support the addition of the user interface with the transceiver. If the Optergy P864 is on the right version, then the problem will be due to an inability to communicate with the transceiver. Please ensure that the transceiver is correctly connected with the Optergy P864 controller as described in the ‘Wiring’...
