  • Page 1 800G OSFP & QSFP-DD Transceiver Module Installation Notes V1.0.2502A Innovation · Expertise · Agility...

  • Page 2: Table Of Contents

    Contents 1. Overview 1.1 Statement 1.2 Module Appearance Overview 2. Safety 2.1 Precautions 2.2 Operating temperature of the transceiver module 3. Installing QSFP-DD and OSFP Transceiver Modules 3.1 Installing/Replacing Transceiver Modules 3.2 Installing/Replacing Fiber Optic Patch Cords 4. Removing QSFP-DD and QSFP Transceiver Modules 5.
  • Page 3 Contents 6. Product Warranty 7. Security and Compliance 8. Handling of Common Problems 8.1 Plugging and Unplugging Transceiver Modules 8.2 Contamination of the Endface of Transceiver Modules (Fibers, Adapters) 8.3 Breakdown and Saturation of Transceiver Module Detectors 9. Appendix Innovation · Expertise · Agility...

  • Page 4: Overview

    1. Overview 1.1 Statement This guide describes general handling measures and precautions when handling OSFP/QSFP-DD transceiver module to ensure that the risk of damage is reduced during processing 1.2 Module Apperance Overview 1.2.1 OSFP Transceiver Module An optical OSFP transceiver module with MPO-16/APC connector is shown in Figure 1. Figure 1 Pull tab Dust cap...
  • Page 5 Figure 2 Pull tab Dust cap Module body Unlock structure Golden Fingers Flat Top Dual MPO-12/APC An optical OSFP transceiver module with Dual-duplex LC/UPC connector is shown in Figure 3. Figure 3 Pull tab Dust cap Dual-duplex LC/UPC Finned Top Unlock structure Golden Fingers Innovation ·...
  • Page 6 1.2.2 QSFP-DD Transceiver Module An optical QSFP-DD transceiver module with MPO-16/APC connector is shown in Figure 4. Figure 4 Pull tab Dust cap Unlock structure Golden Fingers MPO-16/APC An optical QSFP-DD transceiver module with Dual MPO-12/APC connector is shown in Figure 5. Figure 5 Innovation ·...
  • Page 7 Pull tab Dust cap Unlock structure Golden Fingers Dual MPO-12/APC An optical QSFP-DD transceiver module with Dual-duplex LC/UPC connector is shown in Figure 6. Figure 6 Pull tab Dust cap Unlock structure Golden Fingers Dual-duplex LC/UPC Innovation · Expertise · Agility...

  • Page 8: Safety

    2. Safety 2.1 Precautions Moisture-proof caution Do not disassemble or modify Wear anti-static gloves Avoid viewing fiber optic port Qualified personnel only for installation or replacement • The theoretical insertion and removal times of the transceiver modules are generally 500 to 2000 times. Removing and inserting the OSFP/QSFP-DD transceiver module will shorten its service life.

  • Page 9: Operating Temperature Of The Transceiver Module

    • After removing the optical fibers, protect them by inserting a clean dust cover on the pluggable module. Make sure to clean the optical surface of the cable before plugging it back into the optical port of the other OSFP/QSFP-DD transceiver module. Avoid dust and other contaminants entering the optical port of the OSFP/QSFP-DD transceiver module, as the optics will not function properly when obstructed by dust.
  • Page 10 Component aging: High temperatures will accelerate the aging of electronic components inside transceiver modules and shorten the service life of modules. Increased risk of failure: The transmitting and receiving parts of the transceiver module may fail or even be permanently damaged due to excessive temperatures. •...

  • Page 11: Installing Qsfp-Dd And Osfp Transceiver Modules 1

    OSFP/QSFP-DD cage (Caution: If the latch is not fully engaged, you may accidentally disconnect the OSFP/QSFP-DD transceiver module). Figure 7 Install 800G OSFP/QSFP-DD Transceiver Module Figure 8 Install 800G OSFP/QSFP-DD Transceiver Module Step 6 Do not remove the dust plug until you are ready to connect the fiber.

  • Page 12: Installing/Replacing Fiber Optic Patch Cords

    3.2 Installing/Replacing Fiber Optic Patch Cords Step 1 Check that the labels on the patch cords are correct, clear and tidy. If the label is not easily recognized, you will need to recreate and apply the label to avoid errors when connecting the cables. Step 2 Check the fiber connection status.

  • Page 13: Removing Qsfp-Dd And Qsfp Transceiver Modules

    4. Removing QSFP-DD and QSFP Transceiver Modules • Caution: The pluggable OSFP/QSFP-DD transceiver module is designed with a pull-tab release mechanism. To remove the transceiver module, use the pull tab and follow these steps: Step 1 Tie the ESD wrist strap to yourself and place the ESD wrist strap on the chassis or rack. Step 2 For transceiver modules, disconnect the optical connector from the module.

  • Page 14: Cleaning And Maintenance

    5. Cleaning and Maintenance 5.1 Endface Treatment and Cleaning [4] Transceiver modules can be damaged by exposure to electrical surges and overvoltage events. Please note the conditions that limit exposure to the absolute maximum rating. Follow the normal operation precautions of ESD sensitive equipment. The transceiver is equipped with dust caps on both the electrical and optical ports.

  • Page 15: Maintain Fiber Patch Cables

    5.2 Maintain Fiber Patch Cables [5] To maintain fiber patch cords: • When unplugging an optical fiber from an transceiver module, place rubber helmet at the end of the transceiver module and optical fiber. • Secure the fiber to avoid stress on the connector. When connecting the fiber to the transceiver module, be sure to secure the fiber so that the fiber does not support its weight when it hangs on the floor.

  • Page 16: Product Warranty

    6. Product Warranty FS guarantees to our customers that we will return the goods free of charge within 30 days from the date you receive them due to any damage or malfunction caused by our processes. For transceiver modules, if there is any quality problem within 1 year, we also provide replacement service (note that the above return service does not include customized products).

  • Page 17: Security And Compliance

    • Hereby, FS.COM declares that this product is in compliance with Directive 2014/30/EU. A copy of the EU declaration of conformity is available at the following internet address: www.fs.com/company/quality_control.html...

  • Page 18: Handling Of Common Problems

    8. Handling of Common Problems 8.1 Plugging and Unplugging Transceiver Modules 8.1.1 Transceiver Module Mount Mroblems The bayonet of the transceiver module may be improperly connected, mismatched, or improperly inserted and removed. To solve these problems, we need to consider hardware, connectors, protocols and other aspects.

  • Page 19: Contamination Of The Endface Of Transceiver Modules (Fibers, Adapters)

    • MTP fiber Installation Issues: Problem: The MTP patch cord is not properly inserted into the transceiver module, resulting in damage to the module port/MTP patch cord. Solution: Check whether the transceiver module and the patch cord can be matched before use, for example, the OSFP-SR8-800G transceiver module needs to be paired with the MTP12 Type B polarity OM4 APC patch cord, when installing the MTP patch cord, you need to use the index finger and thumb to fix the upper and lower sides of the MTP connector, the keys on the connector body correspond to the keyway on...

  • Page 20: Breakdown And Saturation Of Transceiver Module Detectors

    8.3 Breakdown and Saturation of Transceiver Module Detectors 8.3.1 Detector Breakdown Problems Detector breakdown: When the transceiver module detector is faced with too strong light signal, the breakdown phenomenon may occur, that is, the detector cannot work properly or the output signal becomes unstable.

  • Page 21: Appendix

    Appendix Form Factor and Product Number Form Factor Product Number OSFP-SR8-800G OSFP-DR8-8 OSFP-DR8L-800G OSFP-2FR4-8 OSFP800-2LR4-A OSFP-SR8-800G-FL OSFP OSFP-DR8-800G-FL OSFP-DR8L-800G-FL OSFP-DR4-800G OSFP-FR4-800G OSFP800-DR8-B1 OSFP800-PLR8-B1 OSFP800-PLR8-B2 Innovation · Expertise · Agility...
  • Page 22 Form Factor Product Number OSFP224-DR4-800G-FL OSFP OSFP-DR4-800G-FL OSFP800-XDR8-B2 QDD-SR8-800G QDD-DR8-800G QDD-2FR4-800G QSFP- QDD-XDR8-800G QDD-2LR4-800G QDD-PLR8-800G QDD800-PLR8-B1 References [1][2][3] Cisco Optical Transceiver Handling Guide （https://www.cisco.com/c/dam/en/us/td/docs/interfaces_modules/transceiver_modules/installation/g uide/optical-transceiver-handling-guide.pdf） [4] MMS4X00-NM 800Gbps Twin-port OSFP 2x400Gb/s InfiniBand and Ethernet Single Mode DR8 500m （https://docs.nvidia.com/networking/display/mms4x00nm800g500m/specifications） [5] Removing and Installing Transceivers and Fiber-Optic Cables （https://www.juniper.net/documentation/us/en/hardware/mx10008/topics/topic-map/mx10008- replace-tranceivers.html ）...
