Installation Instructions
Lagoon | Anthem
Back-to-wall Toilets
ARMERA Limited | info@armera.co.uk | www.armera.co.uk
Please note
Please follow all instructions carefully. Failure to do so could invalidate your guarantee. As with
the installation of any water bearing product, you must make sure that any laws prevalent to
your area are followed. Such laws may include Local & National Water Supply Authority
Regulations or Byelaws and Building and Plumbing Regulations. We recommend that a qualified
registered plumber is used to install your product. Please ensure that when fitted, the product
is easily accessed for service and maintenance requirements. Armera cannot be held liable for
costs associated with accessing the product after it is fitted.
Before starting installation
These products are made from vitreous china, so please take every care when handling them
to avoid surface damage.
Please remove all packaging and make sure no components are missing.
components should be present:
Item
Description
1
Fixing brackets x2
2
Floor fixing screws x2
3
Pan fixing screws x2
4
Rawl plugs x2
5
Washers x2
6
Cover caps x2
Installation
1.
Follow the instructions for installation of concealed cistern (Armera part code CI.735).
You will be left with the following parts protruding from the wall:
The following
Advertisement
Summary of Contents for Armera Lagoon
- Page 1 Regulations or Byelaws and Building and Plumbing Regulations. We recommend that a qualified registered plumber is used to install your product. Please ensure that when fitted, the product is easily accessed for service and maintenance requirements. Armera cannot be held liable for costs associated with accessing the product after it is fitted.
- Page 2 Mark the correct lengths for the flush pipe (supplied with concealed cistern) and pan Without the flush pipe and pan connector attached, position the pan against the wall connector (not supplied). and mark on the floor the location of the holes for the fixing brackets. Next, pull the pan away from the wall and secure the fixing brackets to the floor using the floor fixing screws and rawl plugs provided.
- Page 3 This Armera product is guaranteed against manufacturing defects. The cover period is from date of supply to the Armera customer and will last for 2 years for parts and labour. The parts guarantee can be extended to 25 years by registering your guarantee. To register your guarantee and review all guarantee conditions, please go to www.armera.co.uk...
