Summary of Contents for Miele DAZ 1620
- Page 1 Operating and installation instructions Cooker hood To prevent the risk of accidents or damage to the appliance, it is essential to read these instructions before it is installed and used for the first time. en-GB M.-Nr. 12 814 390...
-
Page 2: Table Of Contents
Contents Warning and Safety instructions ................Caring for the environment ..................11 Guide to the appliance....................12 Modes of operation ...................... 14 Operation ........................15 Switching the fan on ...................... 15 Selecting the power level ....................15 Run-on ..........................15 Switching the fan off ...................... - Page 3 Contents Technical data ........................ 31 Special accessories for recirculation mode..............31...
-
Page 4: Warning And Safety Instructions
Miele cannot be held liable for injury or damage caused by non- compliance with these instructions. Keep these instructions in a safe place and pass them on to any future owner. -
Page 5: Safety With Children
Unauthorised installation, maintenance and repairs can cause considerable danger for the user. Installation, maintenance and repairs must only be carried out by a Miele authorised technician. A damaged appliance can be dangerous. Check it for visible signs of damage. Do not use a damaged appliance. - Page 6 by a Miele authorised technician to protect the user from danger. The lamps are a built-in component of the lighting. Replacement lamps may only be fitted by a Miele authorised technician or by the Miele Customer Service Department.
- Page 7 Warning and Safety instructions Using at the same time as another heating appliance that depends on the air from the room Danger of toxic fumes! Great care should be taken when using the cooker hood in the same room or the same area of the house at the same time as another heating appliance that depends on the air from the room.
-
Page 8: Correct Use
Warning and Safety instructions In order to ensure safe operation and to prevent gases given off by the heating appliance from being drawn back into the room, when the cooker hood and the heater are both operated simultaneously, an underpressure in the room of 0.04 mbar (4 Pa) is the maximum permissible. -
Page 9: Proper Installation
Wear gloves to protect your hands from being cut. Exhaust ducting must be of non-inflammable material. Suitable material is available from Miele specialist dealers or the Miele Spares Dept. The appliance must not be connected to a chimney or flue which is ... -
Page 10: Accessories And Spare Parts
Using accessories or spare parts from other manufacturers will invalidate the warranty and Miele cannot accept liability. Miele can only guarantee the safety of the appliance when genuine original Miele replacement parts are used. Faulty components must only be replaced by Miele spare parts. -
Page 11: Disposing Of The Packaging Material
Miele, free of charge. By law, you are solely responsible for deleting any personal data from the old appliance prior to disposal. You are legally obliged... -
Page 12: Guide To The Appliance
Guide to the appliance... - Page 13 Guide to the appliance a Recirculation grille b Exhaust connection c Adjustable bracket d Open-out vapour canopy to which a furniture panel is fitted e Charcoal filter Accessory required for recirculation mode f Hob lighting g Grease filters h Controls...
-
Page 14: Modes Of Operation
Modes of operation Depending on the model of the cooker Recirculation mode hood, the following options are Recirculation mode cooker hoods available: require charcoal filters. These are available to purchase: see “Technical Extraction mode Data”. The air is drawn in and cleaned by the The air is drawn in and cleaned first by grease filters and directed outside. -
Page 15: Operation
Operation Switching the fan on Run-on Switch the fan on as soon as you start It is advisable to run the fan for a few cooking. This is to ensure that vapours minutes after cooking has finished. are captured right from the start. This helps to remove any lingering ... -
Page 16: Energy Saving Tips
Energy saving tips This cooker hood operates very efficiently and economically. The following will help you to save even more energy when using it: - Ensure that there is sufficient ventilation in the kitchen when cooking. In extraction mode, if there is insufficient air flow the cooker hood cannot operate efficiently and this causes increased operating noise... -
Page 17: Cleaning And Care
Cleaning and care All external surfaces and control Before proceeding with any elements can be cleaned using hot maintenance or cleaning task, the water with a small amount of cooker hood must be disconnected washing-up liquid applied with a well from the power supply (see “Warning wrung-out soft sponge or cloth. - Page 18 Cleaning and care Cleaning interval Cleaning the grease filters in the dishwasher Accumulated grease solidifies over a longer period of time and makes cleaning Risk of damage due to more difficult. The grease filters should excessively high temperatures in the therefore be cleaned every 3 to 4 weeks.
-
Page 19: Replacing The Grease Filters
Miele Webshop, the Miele Spare Parts Department (see end of this booklet for contact details) or from your Miele dealer. The type of charcoal filter required is listed under “Technical data” Push the charcoal filters into the at the back of this booklet. -
Page 20: Installation
*INSTALLATION* Installation Before installation Appliance dimensions Before installation, it is important to read the information given on the following pages as well as the “Warning and Safety instructions” at the beginning of this booklet. Installation recommendations - To achieve optimum vapour extraction, the cooker hood must be positioned centrally over the hob, not to the side. -
Page 21: Safety Distance Between Hob And Cooker Hood (S)
*INSTALLATION* Installation Safety distance between hob and cooker hood (S) When planning the installation height of your cooker hood, the minimum safety distance between the top of a cooker or hob and the bottom of the cooker hood is as follows, unless a greater distance is specified by the manufacturer of your cooking appliance. -
Page 22: Fitting The Furniture Front
*INSTALLATION* Installation Fitting the furniture front Depth adjustment There are several holes on the There are two adjustable brackets at the appliance's vapour plate for securing top of the unit and an adjustable trim at the front panel. A drilling template is the bottom of the unit for setting the supplied for correct positioning. -
Page 23: Wall Installation
*INSTALLATION* Installation Wall installation The cooker hood is fitted to the wall inbetween two wall units. Screws and plugs are supplied for this. Cut the drilling template to size and position against the wall. The top edge of the template indicates the top edge of the cooker hood. -
Page 24: Height Adjustment
*INSTALLATION* Installation Height adjustment Adjusting screws in the brackets located at the top of the appliance are used for aligning the appliance with adjoining furniture units. Attach the vapour canopy with cabinet door fitted and then close it. It is possible to adjust the movement of the vapour canopy. -
Page 25: Connecting To Adjacent Furniture Units/Fitting Side Panels
*INSTALLATION* Installation Connecting to adjacent furniture units/fitting side panels The cooker hood is supplied with two screws on each side for securing it to adjacent furniture units or for fitting side panels. Remove the vapour canopy. Remove the grease filters. ... -
Page 26: For Extraction Mode
*INSTALLATION* Installation For extraction mode For recirculation mode Fit the charcoal filters (see “Cleaning and care”). Electrical connection Refer to the notes in “Electrical connection” and “Warning and Safety instructions” before connecting to the electricity supply. Connect the cooker hood to the electricity supply. -
Page 27: Electrical Connection
Risk of fire from overheating. domestic electrical installation and in Connecting the cooker hood to multi- this Miele product must also be socket adapters or extension cables maintained in isolated operation or in can overload the cables. -
Page 28: Connection For Air Extraction
(see If the exhaust is ducted through an “Appliance dimensions”). This applies outside wall, a Miele wall vent or roof in particular when using flat ducting. vent (available as an optional accessory) is recommended. Both of these have a - The exhaust ducting should be as built-in non-return flap. -
Page 29: Condensation
Connection for air extraction Condensation Miele shall not accept warranty claims for any functional defects or damage If the exhaust ducting is to run through caused by inadequate exhaust ducting. cool rooms or ceiling space, for example, the significant variations in... -
Page 30: After Sales Service And Warranty
In the UK, your appliance warranty is Information to help you rectify faults valid for 2 years from the date of yourself and about Miele spare parts purchase. However, you must activate can be found at www.miele.com/ your cover by calling 0330 160 6640 or service. -
Page 31: Technical Data
Technical data Fan motor 250 W Hob lighting 2 x 1 W Total rated load 252 W Mains voltage, frequency AC 230 V, 50 Hz Fuse rating 10 A Length of mains connection cable 1.2 m Weight 11.8 kg Special accessories for recirculation mode Charcoal filter set DKF 14-1. The set contains two active charcoal filters. -
Page 32: Data Sheet For Household Cooker Hoods
Technical data Data sheet for household cooker hoods In acc. with delegated regulation (EU) No. 65/2014 and regulation (EU) No. 66/2014 MIELE Model name/identifier DAZ 1620 Annual Energy Consumption (AEC 75,9 kWh/year hood Energy efficiency class Energy efficiency index (EEI... - Page 35 United Kingdom Miele Co. Ltd., Fairacres, Marcham Road, Abingdon, Oxon, OX14 1TW Tel: 0330 160 6600, Internet: www.miele.co.uk, E-mail: info@miele.co.uk Australia Ireland South Africa Miele Australia Pty. Ltd. Miele Ireland Ltd. Miele (Pty) Ltd. ACN 005 635 398 2024 Bianconi Avenue...
- Page 36 DAZ 1620 en-GB M.-Nr. 12 814 390 / 01...
