- Page 2 Thank you for choosing Shark 08 helmet Bluetooth group intercom headset, This is particularly designed for motorcycle riders to meet their needs where motorcycle riders want to fulfil group intercom, answer phone calls, listen to music, listen to FM radio and receive GPS navigation with voice prompts and other functions, They can have a clear, safe and comfortable experience of the helmet Bluetooth group intercom headset.
- Page 3 Multi-language prompt sound voices. Smart Bluetooth is able to connect to other two devices (eg. mobile phones, MP3, GPS). allows you to enjoy Hi-Fi music. waterproof level. hours phone 33 hours listening to music, 500 hours standby. Be able to pair with other brand intercoms (Universal Pairing). Motorcycle and bicycle riders;...
-
Page 4: Restore Factory Settings
Power On / Off press on hold for 2 seconds, hear the power on tone, alternately flashing red and blue lights (if Power on: on/off connected to Bluetooth will be blue slow flashing). 【 】 Press on hold for 4 seconds, hear the powered off tone, the red light flashes twice, powered off is Power Off: on/off... - Page 5 when you hear an incoming call ring to reject the call. : During a call, short press key to end the call. End call multi-function In standby mode, quickly double-click to automatically dial one of the last numbers dialed. Last code redial: on/off 【...
-
Page 6: Turn Off The Radio
in standby mode, double-click key to start the FM radio. Turn on the radio: ① After turning on the FM radio, each time you press the volume multi-function up or decrease key, you can tune the station to select the station ②... - Page 7 Place the device and the phone within a distance of 1 meter in between. Pairing phone method one: Turn on Bluetooth: In the off state, long press 2 seconds, until the red and blue lights alternately flash, enter on/off the Bluetooth waiting connection state; if other devices have 【...
- Page 8 seconds, until the red and blue lights alternately blink, enter the Bluetooth waiting pairing state, the phone search for the device Bluetooth name " ", click connect to complete the Shark Pro pairing This Bluetooth connection method is practical for a) 120 seconds without Bluetooth pairing operation want to connect again;...
- Page 9 becomes blue light slow flashing; and B green light fast flashing green light long light, B into the search for the third state, to B green light becomes blue light slow flashing, and then press A or B the [on/off ]to start intercom. (When the B green light is always on, you can press force stop B to continue the search and enter the intercom in on/off...
- Page 10 each other. 1) All Bluetooth intercom (1234) on at the same time, red and Pairing steps ( to 4 groups of intercom for example): blue lights alternately flashing (Note: connected phones, navigation equipment Bluetooth will enter the blue light slow flashing, does not affect the later intercom operation).
- Page 11 double click [M] key, it will be reported "This equipment is * ". Random pairing exists for one-step pairing, and manual multi-population networking is available if manual sorting is required. 1) to four people pairing, for example, all intercoms in the boot, into the Bluetooth pairing state, red and blue lights alternately flashing (Note: connected to the phone Bluetooth will enter the blue light slow flashing, does not affect the later...
- Page 12 "This equipment is * ". 【 】 (d) Shark 08 models support up to 8 people connected, One-step pairing can automatically connect 6 devices, if you need to add 7&8 , you need to manually operate 6 even 7, 7 even 8, the method refers to the manual network.
- Page 13 from the use of various interference inevitably increased, will affect the sense of customer experience. When three or more people talk to each other in a Note: group, listening to songs/FM radio operation is not available, but answering incoming calls or end-code callback function exists.
- Page 14 1 meter from each other. a) Power on: long press the Shark 08 intercom for 2 Matching steps: seconds to hear the power on tone, red and blue lights on/off alternately flashing, enter the Bluetooth search mode.
- Page 15 3, after successful pairing, long press key for 4 seconds to enter the music sharing pairing, the green light is multi-function always on; the host hears the music sharing tone, sharing success. During the music sharing process, press and hold the Share Close：...
- Page 16 and restore the factory settings after the shutdown is complete and clear the memory. Level 1: Phone Level 2: Bluetooth Intercom Level 3: Music/FM radio ①Use the included screwdriver to loosen the screws on the back clip and allow the clip to open to the proper level for easy insertion into the lower edge of the helmet.
- Page 17 proper position on the left side of the helmet and tighten the screw (too tight can also damage the clip or the helmet) ③Slide the Bluetooth intercom into the headset clip slot and make sure it locks securely. ④Open the helmet liner (ear position), clean the helmet EPS surface, and paste a piece of speaker Velcro on each side (need to install close to the helmet ear position to achieve the best volume and sound).
- Page 18 Velcro gross side of the sticker and make sure it is firmly attached. ③Slide the intercom into the slot of the Velcro clip, snap it in place and lock it. ④Open the helmet liner (ear position), clean the helmet EPS surface, and paste a piece of horn Velcro on each side (please install close to the ear position to achieve the best volume sound).
- Page 19 First unplug the headset cable, and then a finger press the middle of the back clip fixed snap (push to the side of the helmet), so that the back clip snap hook and Bluetooth intercom disengage, while pushing up the intercom, so that it smoothly slide out of the back clip, complete the disassembly.
- Page 20 Before using the Bluetooth intercom, please use the original 1） Battery and charging instructions charging cable to charge the intercom, the small TYPE-C connector on the charging cable connects to the USB charging port of the Bluetooth intercom, and the large USB on the charging cable connects to the following charging port for power supply ：...
- Page 21 Working frequency: 2402-2480MHz Support Bluetooth protocol: A2DP and AVRCP Operating range: up to 10 meters for cell phones Battery type: 900mAh rechargeable lithium polymer Standby time: up to 500 hours Talk time: up to 28 hours for cell phone calls/intercom; up to 33 hours for music Charging time: about 2 hours Power adapter: DC 5V 1A (optional)
- Page 22 FCC Compliance Notice This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio ...
