WARNING!
Removing the product label, disassembling, altering or damaging heater (including dry/wet firing
heater) voids the product warranty
WARNING!
This electrical device should be installed by an electrician or qualified pool/spa technician. If you are
not qualified or do not have the knowledge to install this product correctly,
assistance
STEPS FOR A SUCCESFULL INSTALLATION
1. Using the Heater Cross Reference Matrix, confirm the number on the heater data label (HQ part #) is the correct
replacement for the heater being removed from the spa Do Not Replace heaters that are not correctly matched
HQ PART #
26-C3160-1S
26-C3160-2S
26-C3072-1
26-C3072-2
HEATER CROSS REFERENCE MATRIX
CAN REPLACE THESE HEATER MODELS
C3160-1, C3564-1, 73790 , 7211
C3160-2S, C3160-2, C3564-2
73791, 73039, 6758
76227, 302215, C3072-1
76228, 302216, C3072-2
SpaDepot.com
stop!
and contact your heater provider for
Label Data
6.0/1.5kW-240V/120v
4.0/1.0kW-240V/120v
6.0/1.5kW-240V/120v
4.0/1.0kW-240V/120v
Instructions continue on back page
Advertisement
Summary of Contents for HydroQuip 26-C3160-1S
- Page 1 Do Not Replace heaters that are not correctly matched HEATER CROSS REFERENCE MATRIX HQ PART # CAN REPLACE THESE HEATER MODELS Label Data 6.0/1.5kW-240V/120v C3160-1, C3564-1, 73790 , 7211 26-C3160-1S C3160-2S, C3160-2, C3564-2 4.0/1.0kW-240V/120v 26-C3160-2S 73791, 73039, 6758 76227, 302215, C3072-1 26-C3072-1 6.0/1.5kW-240V/120v...
- Page 2 2. Inspect heater for shipping or other damage. Do not attempt to install a heater that’s damaged, repaired or appears to be altered in any way. 3. Turn heater temperature to off, turn off circuit breaker to spa and be certain the electrical power has been disconnected before performing this service.
