Chiltern Invadex EasiDec Quick Start Manual

8
easy steps to fit a
1. Curtain/rail only 3. Fixing Jamb panel
EasiDec Wet Floor with EasiDec Wet Floor with fixed Jamb panel and pole
curtain rail & curtain Push panel into wall channel as Fig 1.1. Fasten loosely (on the inside) with self tapping screws, slot
only covers and shakeproof washers provided as Fig 1.2.
Go to step 7. Push pole section on to panel ensuring fixing plate is in position as Fig 2.2 (if required fit second jamb
panel and pole section, as Fig 4.1). Ensure holes on the fixing plate are on the outside of the
showering area as Fig 2.2. Check panel is level horizontally and vertically and ensure the bottom seal
2. Bolster
is in contact with the floor.
If applicable, bolster(s) and
If no other Jamb panels or doors are required - fully tighten all screws, slot covers and
wall channel(s) should
shakeproof washers. Drill floor/EasiDec and apply a bead of silicone sealant into the holes just made.
already be fixed in position,
Fix pole fixing plate to flooring/EasiDec with cheesehead screws provided. Drill pilot holes (2) and
as shown in the bolster
fasten final fixing screws (No 8 x 1/2"). Go to steps 7 and 8.
section fitting instructions
shown overleaf.
If additional Jamb panels or doors are required - do not fully tighten screws - go to steps 4&5.
Fig 1.1
Published by: Chiltern Invadex Ltd, 126 Churchill Road, Bicester, Oxon, OX26 4XD Registered in England No: 6050608
In Northern Ireland: Chiltern Invadex (NI) Ltd, 5 Balloo Way, Balloo Industrial Estate, Bangor, County Down, BT19 7QZ Registered No: NI 19958
...
EasiDec Wet Floor Enclosure
Fig 1.2
Fig 2.2
Fig 2.1
Fig 3.1
CINV 532.01 11/07
4. Position door(s)
Push hinged section of doors into the
appropriate channel to suit enclosure
option, e.g Fig 3.1. Fasten loosely with
self tapping screws, slot covers and
shakeproof washers.
Fig 4.1
