Banner SXI-CATM1VZW-001 Installation Manual

Install and Activate a Cellular Modem
Activating a Cellular Modem
Follow these basic steps, as detailed in this document, to activate the cellular capabilities of your DXM Controller.
1. Purchase a cellular modem kit from Banner Engineering Corp.
2. Install the cellular modem, connect the antenna cable, and connect the cellular antenna.
3. Activate a cellular plan to the SIM card, then insert the SIM card into the cellular modem.
4. Configure the DXM to use the cellular modem.
Purchase one of these cellular modem kit models
Cellular Kit Model
SXI-CATM1VZW-001
SXI-CATM1ATT-001
SXI-CATM1WW-001
SXI-LTE-001
For additional information, refer to the Banner Cloud Data Services support center (support.bannercds.com). The support center includes
video tutorials, product documentation, technical notes, and links to download configuration software.
IMPORTANT: Only the DXM100 and DXM150 models in conjunction with an SXI-LTE-001 (obsolete) cellular modem
can offer SMS/text messaging capabilities directly from the device. Contact a support specialist at Banner Engineering
for configuration instructions, or SMS/text messaging can be delivered using the Banner CDS web service from any
DXM model.
Install the Cellular Modem (DXM100, 150, 700, and 1000 Models)
Follow these steps to install the cellular modem and antenna cable.
IMPORTANT:
• Electrostatic discharge (ESD) sensitive device
• ESD can damage the device. Damage from inappropriate handling is not covered by warranty.
• Use proper handling procedures to prevent ESD damage. Proper handling procedures include leaving devices
in their anti-static packaging until ready for use; wearing anti-static wrist straps; and assembling units on a
grounded, static-dissipative surface.
Original Instructions
16-Oct-24
Kit Description
Verizon CAT M1 cellular modem using Telit ME910 modem kit
(Verizon part number SXIM1V). Includes a cellular modem, SIM
card, internal adhesive antenna, external SMA antenna, and
antenna cable. The SIM card is specific to the LTE-M technology
and cannot be used in other cellular modems. Requires a LTE
Verizon cellular wireless plan attached to the ICCID (SIM card)
number and IMEI (International Mobile Equipment Identity) number.
Cellular plans can be purchased through celldata.bannercds.com.
AT&T CAT M1 cellular modem using Telit ME910 modem kit (AT&T
part number SXIM1A). Includes a cellular modem, SIM card,
internal adhesive antenna, external SMA antenna, and antenna
cable. The SIM card is specific to the LTE-M technology and cannot
be used in other cellular modems. Requires a LTE AT&T cellular
wireless plan attached to the ICCID (SIM card) number and IMEI
(International Mobile Equipment Identity) number.
Cellular plans can be purchased through celldata.bannercds.com.
Worldwide CAT M1 cellular modem using Telit ME910 model kit.
Includes a cellular modem, SIM card, internal adhesive antenna,
external SMA antenna, and antenna cable. The SIM card is specific
to the LTE-M/NB-IoT technology and cannot be used in other
cellular modems. Requires an LTE cellular plan attached to the
ICCID (SIM card) number and IMEI (International Mobile Equipment
Identity) number.
Cellular plans can be purchased through
a local roaming SIM provider.
Verizon LTE cellular modem using Telit LE910 modem kit (Verizon
part number SENSX002). Includes a cellular modem, SIM card,
antenna, and antenna cable. The SIM card is specific to the LTE
technology and cannot be used in other cellular modems. Requires
a LTE Verizon cellular wireless plan attached to the ICCID (SIM
card) number and IMEI (International Mobile Equipment Identity)
number.
Cellular plans can be purchased through
a local roaming SIM provider.
© Banner Engineering Corp. All rights reserved.
This cellular modem kit is for use in applications that require
monthly data usage approaching 50 MB or 250 MB with push
intervals no more frequent than every 10 minutes. This modem
is only for use in the contiguous United States region.
Please visit our
and cellular plan pricing.
This cellular modem kit is for use in applications that require
monthly data usage approaching 50 MB or 250 MB with push
intervals no more frequent than every 10 minutes. This modem
is only for use in the North American region.
Please visit our
and cellular plan pricing.
This cellular modem kit is for use in applications that require
monthly data usage approaching 50 MB or 250 MB with push
intervals no more frequent than every 10 minutes. This modem
is only for use in the European region within those countries
that are members of the EU/EEA and adopt RED/CE compliant
products.
Please visit our
celldata.bannercds.com or
and cellular plan pricing.
This cellular modem is only used with the Wireless Network
Bridge Hub (NET-HUB).
Please visit our
and cellular plan pricing.
celldata.bannercds.com or
Important Notes
support site for more details on coverage areas
support site for more details on coverage areas
support site for more details on coverage areas
support site for more details on coverage areas
p/n: 205026 Rev. H
