Vacuum cleaner
User manual
VS80F28***
•
Before operating this unit, please read the instructions carefully.
•
For indoor use only

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VS80F28 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung VS80F28 Series

Summary of Contents for Samsung VS80F28 Series

  • Page 1 Vacuum cleaner User manual VS80F28*** • Before operating this unit, please read the instructions carefully. • For indoor use only...

  • Page 2: Table Of Contents

    Contents Safety information Maintenance Important safety symbols Cleaning the Clean Station State of California Proposition 65 Warning Cleaning the vacuum cleaner General Regulatory Notice Appendix Vacuum cleaner SmartThings app Maintenance Notes and cautions Clean Station Troubleshooting Battery Product specification Preparation Warranty Accessories Warranty...

  • Page 3: Safety Information

    Safety information • Congratulations on your new Samsung appliances. This manual contains important information on the installation, use, and care of your appliances. Read this manual thoroughly before using the appliances to ensure that you know how to safely and efficiently operate the features and functions that your new appliances offers.

  • Page 4: State Of California Proposition 65 Warning

    Safety information State of California Proposition 65 Warning WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.gov. For battery recycling go to call2recycle.org or call 1-800-822-8837 WARNING To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: General 1.
  • Page 5 3. For use in UK: If your appliance is fitted with a nonrewireable BS 1363 plug it must not be used unless an appropriately rated (ASTA approved to BS 1362 ) fuse is fitted in the carrier contained in the plug. 4.

  • Page 6: Regulatory Notice

    Safety information Regulatory Notice 1. FCC Notice WARNING • Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. • This device complies with Part 15 of FCC Rules. Operation is Subject to following two conditions: 1.
  • Page 7 2. IC Notice • The term “IC” before the radio certification number only signifies that Industry Canada technical specifications were met. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

  • Page 8: Vacuum Cleaner

    – An explosion or fire may occur. • If the product makes a strange sound or emits a smell or smoke, turn off the product immediately, and then contact a Samsung service center. – Electric shock or fire may occur.
  • Page 9 – If there is foreign matter on the wheel of the brush which cannot be removed easily, contact a Samsung service center. • When the spin brush inside a brush is working, do not touch the brush.

  • Page 10: Maintenance

    – If water gets into the product and an error occurs, turn off the product and contact a Samsung service center. • When cleaning the washable parts, do not use alkaline detergent, acid, industrial detergent, air freshener, acetic acid, etc.

  • Page 11: Clean Station

    Dustbin , Washable Micro Filter , Fine Dust Filter , Metal Mesh Washable Parts Grille Filter , dry cloth Non-washable parts Premotor Filter and Fine Dust Filter of the Clean Station Acceptable Neutral Dish washing detergent detergent Alkaline Lox, mold cleaner, etc. Acid Paraffin oil, an emulsifier, etc.
  • Page 12 – Product malfunction or electric shock may occur. • As the Clean Station is designed for the use of Samsung Jet cordless vacuum cleaner only, do not use the Clean Station for other electronic appliances and other purposes.

  • Page 13: Battery

    • When you purchase a new battery, make sure to check the model name (VCA-SBTD95) and the genuine logo. – Contact your nearest Samsung Electronics retailer or Samsung service center to purchase any consumable accessories. English 13...
  • Page 14 Safety information • Leaks from battery cells can occur under extreme usage or temperature conditions. If the liquid gets on your skin, wash the affected area quickly with water. If the liquid gets into your eyes, flush them immediately with clean water for a minimum of 10 minutes. Seek medical attention.
  • Page 15 WARNING To remove the battery contact an authorised service centre. To obtain battery removal instructions please visit samsung.com/global/ecodesign_energy You must not remove (or attempt to remove) the battery incorporated in this product on your own. FOR YOUR OWN SAFETY, DO NOT ATTEMPT TO REMOVE THE BATTERY ON YOUR OWN OR DISPOSE OF IT IN FIRE.

  • Page 16: Preparation

    Preparation Accessories The accessories with the ' * ' mark may differ depending on the models. Telescopic pipe Pet Tool + Combination Tool Extension Crevice Tool Dust bags (1 installed, 2 extra) User manual * Flexible Tool * Accessory Cradle Clean Station * Battery charger * Jet Dual Brush+...

  • Page 17: Parts Overview

    Parts overview 01 Power ( ) button 12 Battery release button 02 Suction power control buttons 13 Pipe release button 03 Washable Micro Filter 14 Pipe length adjustment button 04 Metal Mesh Grille Filter 15 Brush release button 05 Display 16 Dustbin joint 06 Dustbin release button 17 Clean Station START/STOP button...

  • Page 18: Operation

    Operation For detailed information, please refer to the QR code. Installing the Clean Station • Run the power cord of the Clean Station along the round groove at the bottom. Make sure the power cord is correctly placed so that the Clean Station stands without tilting. •...
  • Page 19 NOTE • If clumps of dust, hair, threads, etc. wound Auto dustbin around the Metal Mesh Grille Filter and prevent lid closer the dustbin from emptying, repeatedly press the START/STOP button on the Clean Station until the dustbin is empty. Clean the dustbin if you find any foreign matters after emptying it.
  • Page 20 Operation • If the Auto Empty function is enabled, the Auto Empty LED indicator turns white. Press the Auto Empty button to enable and disable the function. • For optimal performance, we recommend enabling the Auto Empty function. The Auto Empty function can affect the performance of the Metal Mesh Grille Filter and the self-diagnosis.

  • Page 21: Factory Reset

    Setting and canceling the network connection • Refer to the ‘ SmartThings app’ section for network connection settings. To cancel the network connection after entering the AP mode, press and hold the Auto Empty button for 5 seconds. Resetting the network connection •...

  • Page 22: Charging The Battery

    Operation Charging the battery • When the battery level indicator turns red or the ‘ Low battery’ message appears on the display , charge the battery. • You cannot use the vacuum cleaner while charging. • Make sure the back of the battery is correctly placed onto the vacuum charging part. •...

  • Page 23: Charging The Additional Battery

    Charging the additional battery Charge the additional battery on the battery cradle. Battery level • Firmly push the battery onto the battery cradle. indicator • Battery level indicator turns on and changes color to red, orange, and yellow as the battery charges.

  • Page 24: Using The Buttons And Display

    Operation Using the buttons and display 01 Display Displays the current mode (‘ MIN, AI, MID, MAX, JET, or WET’) or the alert message. 02 Power ( Press this button to turn on or off the vacuum cleaner. When you turn on the power, the vacuum cleaner starts in the ‘ MID’ mode.
  • Page 25 Alert messages and what to do The vacuum cleaner displays alert messages for user to inspect certain parts or clean certain parts such as a filter. Also, its self-diagnosis feature provides a guide that helps you maintain its best performance. Message What to do Object stuck in brush/tool...

  • Page 26: Using The Accessory Cradle

    Operation Using the Accessory Cradle ‘Click’ ‘Click’ • To detach the accessories, press the release button on the back of each accessory. • Dust that remains in the accessory may fall when you detach it from the vacuum cleaner. When you finish using the vacuum cleaner, shorten the Telescopic Pipe and operate the vacuum cleaner in the 'MAX' mode for more than 10 seconds.

  • Page 27: Using The Accessories

    Using the accessories Detaching the accessories • To detach the accessories, press the release button on the back of each accessory. • Before detaching the accessories, operate the vacuum cleaner in the 'MAX' mode for 10 seconds to prevent any foreign matter remains inside the accessory.
  • Page 28 Operation Spray Spinning Sweeper Use to clean a wooden or linoleum floor with a wet Reusable wet pad pad. • The Spray Spinning Sweeper does not have a Spin disk dust suction function. Using the reusable wet pad • When attaching the wet pad, make sure the pad is in the center of the spin disk.

  • Page 29: Maintenance

    Maintenance Cleaning the Clean Station Replacing the dust bag If the START/STOP button on the Clean Station turns red, check if the dust bag is full. If the dust bag is not full, check if the vacuum cleaner’s dustbin , pipe, or brush is clogged. •...

  • Page 30: Cleaning The Vacuum Cleaner

    Maintenance Cleaning the vacuum cleaner For detailed information, please refer to the QR code. Dustbin / Washable Micro Filter CAUTION • After cleaning the dustbin and Washable Micro Filter with water, you should dry them completely in the shade for more than 24 hours before use. When heat is applied, part deformation may occur.
  • Page 31 Fine Dust Filter Make sure to turn off the product before cleaning the filter. • Twist and pull off the Fine Dust Filter , and tap it gently to remove the dust. • Wash the filter with running water once a month to maintain the best performance of the filter. •...
  • Page 32 Maintenance Jet Dual Brush+ • Do not clean the brush with water. • When foreign matter remains on the brush, remove it with a wet tissue or a dry cloth. Removing the front brush • Disengage the release lever to remove the front brush. To disengage with your hand, hold the recessed area at the side of the release lever and lift it in the direction of the arrow.
  • Page 33 Slim LED Brush+ ‘Click’ CAUTION • Do not clean the brush with water. • When foreign matter remains on the brush, remove it with a wet tissue or a dry cloth. NOTE • If the spin brush does not work after cleaning the Slim LED Brush+ , the overheating prevention device of the motor may have been enabled.
  • Page 34 Maintenance Slim LED Brush+ roller wheels Use a small screwdriver to disassemble the front and rear roller wheels. Rear roller NOTE wheel Tools required for disassembly. Flat head screwdriver (3 mm or less in width), Phillips Front roller wheel screwdriver, prying tool. CAUTION •...
  • Page 35 Rear roller wheel Release lever ‘Click’ Release lever • Lift the release lever to detach the rear roller wheel. • Detach the rear roller wheel and remove the tangled foreign matter. Then, reassemble the wheel. • Insert the rear roller wheel into its place, and then press the release lever until you hear a click. CAUTION Be careful not to damage the release lever with a screwdriver.
  • Page 36 Maintenance Spray Spinning Sweeper NOTE If the spin disk does not work after cleaning the Spray Spinning Sweeper , the overheating prevention device of the motor may have been enabled. Wait 30 minutes or more to cool the motor and operate again. Pet Tool + Cut the tangled hair or fur with scissors, and then use a vacuum cleaner to suck up the pieces.

  • Page 37: Appendix

    DHCP server option is from the markets (Google Play Store, Apple activated on your wireless router. App Store, or Samsung Galaxy Store). To find • The vacuum cleaner supports the WEP-OPEN, the app, use the keyword “SmartThings”.
  • Page 38 • When the vacuum cleaner cannot be registered STEP 3  Setting up a Samsung account to the SmartThings app • You must sign in to a Samsung account before - Refer to the SmartThings app guide or pop- using the SmartThings app.

  • Page 39: Software Update

    Open Source Announcement The software included in this product contains open source software. The following URL http://opensource.samsung.com/opensource/SMART_TP1_0/seq/0 leads to open source license information as related to this product. Security updates information Security updates are provided to strengthen the security of your device and protect your personal information.
  • Page 40 ※ This menu may not be available on some Call and message alert devices. Supported devices: Samsung smartphones with Android 11 (R OS), One UI 3.1 or later. Unsupported devices: Some Samsung smartphones (A1x, A2x, M1x, M2x) and third- party smartphones.
  • Page 41 Functions Explanation You can set the time that takes for emptying the vacuum cleaner’s dustbin . • Short (8-10 seconds), Normal (12-14 seconds), Dustbin emptying duration Long (20-22 seconds) (Default: Normal ) ※ If there is a lot of dirt (hair / lint), increase the emptying duration.

  • Page 42: Notes And Cautions

    • Install the Clean Station in a place where there are no objects that could break and cause damage. – This may affect the performance of the self-diagnosis. • If you have a problem with installing the Clean Station , contact a Samsung service center. English...

  • Page 43: Battery Usage

    • If the product does not work after you charge the battery, replace the battery. If it still does not work with the new battery, contact a Samsung service center. • Spare batteries and the Accessory Cradle chargers need to be purchased separately.
  • Page 44 Do not boil the wet pad. • Use a genuine wet pad of Samsung Electronics for the Spray Spinning Sweeper. • If the Spray Spinning Sweeper is used without a wet pad, any product malfunction will not be covered by warranty and a service fee will be charged.
  • Page 45 • When the dust bag in the Clean Station is filled with dust, the Clean Station may stop due to the overheating prevention device of the motor. Replace the dust bag and then use the Clean Station . • If there is a larva in the suctioned dust, it can multiply in the dust bag . Clean the Clean Station with a wet tissue and replace the dust bag.
  • Page 46 Appendix • Do not step heavily on the upper part of the Spray Spinning Sweeper while using it. – Product damage or floor damage may occur. • When cleaning, be careful that the side of the brush does not bump into a molding part, a wall, furniture, etc.
  • Page 47 Maintenance NOTE • If the inner part of the Spray Spinning Sweeper is clogged with large foreign matter, spinning speed decreases or the spin disk stops. CAUTION • Do not push the vacuum cleaner while it is stored in the Clean Station . –...

  • Page 48: Troubleshooting

    • Replacement filters are available at your local Samsung service agent. • Materials of a mat (childcare center mat, noise prevention mat for Static electricity occurs between floors, etc.) may cause static electricity.
  • Page 49 Problem Solutions • When using the Spray Spinning Sweeper for the first time, the air in the internal pump and the tube may cause to delay in spraying water. The Spray Spinning Sweeper Detach the water tank, press the + button, and check that the does not spray water.
  • Page 50 Appendix Problem Solutions • Make sure the Clean Station is properly plugged in. • Make sure the vacuum cleaner is properly placed on the Clean Station. • Check if you enabled the Auto Empty function. • Check the Bluetooth connection. Press and hold the Clean Station ’s START/STOP button for 5 seconds.
  • Page 51 Bluetooth is not connected and blinks in blue for 5 seconds when the Bluetooth is connected. I cannot log into the • Check your ID and password on the screen of the Samsung account. Samsung account. The wireless router I want to connect is not detected •...
  • Page 52 Appendix Problem Solutions • Turn off the SmartThings app and then run it again. Clean Station is successfully • Disconnect the smartphone from the wireless router and then connected to the connect it again. smartphone, but I cannot • Turn off the Clean Station and turn it back on. Wait for a few minutes, operate the product from the and then open the SmartThings app again.

  • Page 53: Product Specification

    Product specification Charging and cleaning time may differ depending on the brushes and the conditions of use. Model VS80F28*** Power consumption (Vacuum cleaner) Based on a handy vacuum cleaner: 770 W Battery specification Li-ion 25.2 V, 2200 mAh, 7 cell 2.70 kg ( Jet Dual Brush+ ) Weight (Vacuum cleaner) 2.49 kg ( Slim LED Brush+ )

  • Page 54: Warranty

    During the applicable warranty period, a product will be repaired, replaced, or the purchase price refunded, at the sole option of SAMSUNG. SAMSUNG may use new or reconditioned parts in repairing a product, or replace the product with a new or reconditioned product. Replacement parts and products are warranted for the remaining portion of the original product’s warranty or ninety (90) days, whichever is longer.
  • Page 55 SAMSUNG does not warrant uninterrupted or error-free operation of the product. No warranty or guarantee given by any other person, firm, or corporation with respect to this product shall be binding on SAMSUNG. To obtain warranty service, please contact SAMSUNG at: Samsung Electronics America, Inc.

  • Page 56: Warranty (Canada)

    Proof of purchase to SAMSUNG or SAMAUNG’s authorized service center. SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above.
  • Page 57 CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE.
  • Page 58 Memo...
  • Page 59 Memo...
  • Page 60 (English) CANADA 1-800-Samsung (726-7864) www.samsung.com/ca_fr/support (French) 1-800-SAMSUNG (726-7864) U.S.A www.samsung.com/us/support 1-844-SAM-PAYS (726-7297) OID86384-00...
