- Page 1 IC45-DYNARATE VOYAGER 570G ® U S E R M A N U A L U S E R M A N U A L 98-05365-EN SPRAYER JOB COMPUTER...
- Page 2 Copyrights © 2023 TeeJet Technologies. All rights reserved. No part of this document or the computer programmes described in it may be reproduced, copied, photocopied, translated, or reduced in any form or by any means, electronic or machine readable, recording or otherwise, without prior written consent from TeeJet Technologies.
-
Page 3: Table Of Contents
SPRAYER JOB COMPUTER IC45-DYNARATE ® Table of contents IMPORTANT SAFETY INFORMATION CHAPTER 1 – HANDLING THE WORK SCREEN INTRODUCTION ORGANIZATION OF SCREEN AREAS Navigation Keys in the Menus ................................11 Function Keys ........................................ 11 Description of Function Keys .................................. 12 Customization of the Information Displayed on the Screen ....................... - Page 4 SPRAYER JOB COMPUTER IC45-DYNARATE ® CHOICE OF REGULATION MODE How to Switch between Manual and Automatic Modes ......................39 Automatic Mode ......................................39 Manual Mode ........................................ 40 FILLING THE SPRAYER TANK Filling with the In-Cab Terminal ................................42 Filling setup with DynaFill Optional Feature ............................. 43 Filling the Tank with Liquid Fertilizer ..............................
-
Page 5: Important Safety Information
SPRAYER JOB COMPUTER IC45-DYNARATE ® IMPORTANT SAFETY INFORMATION FOREWORD This guide is intended for the user of the sprayer for the current operations of treatment of the crops or fertilization of the fields. It is considered that the settings inherent to the tractor, the sprayer, the ISOBUS terminal (TECU), the calibrations and the advanced settings have been carried out beforehand in the workshop. -
Page 6: General Warnings And Precautions
SPRAYER JOB COMPUTER IC45-DYNARATE ® GENERAL WARNINGS AND PRECAUTIONS DANGER! • Read and follow instructions. If instructions are unclear after reading the manual, please contact a local dealer. • Keep children away from equipment. • Do not operate machinery under the influence of alcohol or any illegal substance. •... - Page 7 SPRAYER JOB COMPUTER IC45-DYNARATE ® WARNING! PRESSURISED SPRAY SYSTEM • It is important to follow proper safety precautions when using a pressurised spray system. Fluids under pressure can penetrate skin and cause serious personal injury. • The system pressure should never exceed the lowest rated component. Always know your system and all component capabilities, maximum pressures and flow rates.
- Page 8 SPRAYER JOB COMPUTER IC45-DYNARATE ® CAUTION! HARNESS CABLE AND HOSE SAFETY • Routinely check all harness cables and hoses for damage or wear. Replace or repair when necessary. • Do not route harness cables and hoses with sharp bends. • Do not strap harness cables and hoses to lines with high vibration or spikes in pressure. •...
-
Page 9: Work Screen
1 - WORK SCREEN... -
Page 10: Chapter 1 - Handling The Work Screen
SPRAYER JOB COMPUTER IC45-DYNARATE ® CHAPTER 1 – HANDLING THE WORK SCREEN INTRODUCTION The start-up of the IC45-DynaRate work screen will depend on the If after several minutes the IC45 work screen does not appear, type of installation of your equipment: please contact the dealer who sold you the equipment. -
Page 11: Navigation Keys In The Menus
SPRAYER JOB COMPUTER IC45-DYNARATE ® Navigation Keys in the Menus Opens the settings menu. Returns to the previous screen Available on the main working screen Displays the next page of function keys. Each press Returns to the main working screen. of the key moves to the next page of function keys Available in the menus until you return to the first page. -
Page 12: Description Of Function Keys
SPRAYER JOB COMPUTER IC45-DYNARATE ® Description of Function Keys Key set may be different depending on your sprayer’s features. Toggle button OFF/ON In multiple menus, there are keys with buttons at the bottom. Spraying ON/OFF The key pictograms’ colour, as well as the colour of the slide behind the button, is grey when it is turned OFF. -
Page 13: Customization Of The Information Displayed On The Screen
SPRAYER JOB COMPUTER IC45-DYNARATE ® Customization of the Information Displayed on the Screen The configurable information zones are located in the dark bands on the upper and lower part of the screen. The central zone of the upper part is not modifiable, it is reserved for the speed and alarm indicator. -
Page 14: Graphic Indicators
SPRAYER JOB COMPUTER IC45-DYNARATE ® Graphic Indicators The center of the screen displays information about the status of the sprayer in real time. This allows you to quickly view the sprayer information at once. Tank level : The blue colored area represents the amount remaining in the tank, with the volume value here displayed. -
Page 15: Show/Hide Pressure Bargraph And Tank Volume
SPRAYER JOB COMPUTER IC45-DYNARATE ® Show/Hide Pressure Bargraph and Tank Volume The display of the Pressure / Droplets and Tank volume graphics are optional. To activate these options, go to : Main menu Machine Job settings User profile Show Pressure Bargraph: Press the line to toggle the button ON or OFF Show tank volume:... -
Page 16: Alarms
SPRAYER JOB COMPUTER IC45-DYNARATE ® Alarms The IC45 has an alarm system (see alarm settings on page 52) to warn the operator if the system cannot reach the predefined ALARM DEFAULT DISPLAY : parameters or if the system has an issue. Example: •... -
Page 17: Unlocking Ic45 Options
SPRAYER JOB COMPUTER IC45-DYNARATE ® Unlocking IC45 Options To unlock additional functions, you must enter a code purchased through your dealer. To enter the code, go to: Main menu Help menu Unlock codes Select the function to unlock. A virtual keyboard appears and you can enter the code to unlock optional paid feature. - Page 18 2 - AT THE BEGINNING OF THE SEASON...
-
Page 19: Chapter 2 - At The Beginning Of The Season
SPRAYER JOB COMPUTER IC45-DYNARATE ® CHAPTER 2 – AT THE BEGINNING OF THE SEASON IMPORTANT At the beginning of the season, we advise you to check that your If you are starting up your equipment for the first time, please calibrations are correct. -
Page 20: Speed Source And Calibration
SPRAYER JOB COMPUTER IC45-DYNARATE ® Speed Source and Calibration Several sources may provide a speed signal, like GNSS, Speed sensor, vehicle gearbox, etc.). Ensure that the source used is the preferred one and calibrate it, if the speed is incorrect. Enter the main menu Machine... -
Page 21: Calibrate Speed Sensor
SPRAYER JOB COMPUTER IC45-DYNARATE ® Calibrate Speed Sensor The calibration of the speed is done by driving a measured distance. The distance to be covered is 100 meters. Follow the instructions on the screen: • Machine stopped: press the Calibration key •... -
Page 22: Calibration Of Flow Sensor
SPRAYER JOB COMPUTER IC45-DYNARATE ® Calibration of Flow Sensor Calibration of the flow sensor is done either: - By entering the values provided by the sensor’s manufacturer in the computer (press each of the 3 lines to open the numeric keypad and type in the corresponding value). -
Page 23: Calibration Of Pressure Sensor
SPRAYER JOB COMPUTER IC45-DYNARATE ® Calibration of Pressure Sensor Calibration of the pressure sensor is done in two steps: Step 1: CALIBRATE SENSOR AT ZERO PRESSURE: • Press the “Calibrate ‘No Pressure’ “ line Follow the instructions on the screen: •... - Page 24 SPRAYER JOB COMPUTER IC45-DYNARATE ® Once the two steps described on the previous page are completed, no further pressure calibration is required for the perfect sprayer operation. Nonetheless, as the IC45 pressure sensor is located on the boom, while the hardware pressure gauge is fitted close to the regulation valve, they should read a slight difference of value at the same time.
-
Page 25: Calibration Of Tank Level Sensor
SPRAYER JOB COMPUTER IC45-DYNARATE ® Calibration of Tank Level Sensor Calibration of the tank gauge is done in 4 steps with 3 instantaneous measurements and 1 multipoint measurement to calibrate the tank shape. The last measurement is done by emptying the tank. NOTE: Tank Level Calibration is normally done by the machine manufacturer but it may be necessary to calibrate in special circumstances. - Page 26 SPRAYER JOB COMPUTER IC45-DYNARATE ® Step 3: CALIBRATE THE MAXIMUM LEVEL OF TANK: Press the Calibrate max tank level line. “ Max Tank Level” is a setting that is usually predefined by the manufacturer in the OEM Menu. The entered value is based on the tank itself and it will help you to calibrate the sprayer.
-
Page 27: Setting Up Your Nozzles
SPRAYER JOB COMPUTER IC45-DYNARATE ® SETTING UP YOUR NOZZLES Go to the Main Menu Machine Nozzle Presets The Nozzle Presets section contains 5 pages that can store up to 5 nozzles installed on the machine. NOTE: The preset nozzles will appear in the nozzle list when entering the spray parameters in the JOB WIZARD. -
Page 28: Select / Preset A Teejet Nozzle
SPRAYER JOB COMPUTER IC45-DYNARATE ® Select / Preset a TeeJet Nozzle • Use one of the 5 available pages (navigate with the “Next page” key) • Press the Nozzle Series line to select the nozzle model – In these pages, you will find all TeeJet nozzles. Press the line of the nozzle to select it. -
Page 29: Select / Preset A User Nozzle
SPRAYER JOB COMPUTER IC45-DYNARATE ® Select / Preset a User Nozzle NOTE: TeeJet nozzles are already pre-registered, to preselect them see procedure on previous page. In the User Nozzle menu, accessed with the User Nozzle key, you can enter up to 10 nozzle names. - Page 30 SPRAYER JOB COMPUTER IC45-DYNARATE ® Return to the Nozzle Presets screen, by pressing the return key. • Select one of the five nozzle preset pages by use of the Next Page key. • Press the Nozzle Series line to open the nozzle list, select “User Nozzle”.
-
Page 31: Other Nozzle Functions
SPRAYER JOB COMPUTER IC45-DYNARATE ® Other Nozzle Functions Key resets the User Nozzle list to the factory configuration. (After verification on the next window). NOTE: The Reset Nozzles key will delete all general and user nozzle presets. This key, is only displayed when a TeeJet nozzle is selected. -
Page 32: How To Use Simulated Speed
SPRAYER JOB COMPUTER IC45-DYNARATE ® HOW TO USE SIMULATED SPEED The following keys can be used to simulate a speed to test the sprayer settings before working, while remaining stationary. This key activates or deactivates the simulation mode. The button is only available when no other speed source is available. - Page 33 SPRAYER JOB COMPUTER IC45-DYNARATE ® The simulated speed values (slow/fast) are set as follows: Main Menu Machine Job Settings Operation Press the lines to change the speed settings of the low (tortoise) or high (hare) speeds. 98-05365-EN-R2...
- Page 34 3 - USE AND SPRAYING...
-
Page 35: Chapter 3 - Use And Spraying
SPRAYER JOB COMPUTER IC45-DYNARATE ® CHAPTER 3 - USE AND SPRAYING ENTERING THE SPRAYING PARAMETERS VIA JOB WIZARD Selecting the Target Rate • Press the JOB WIZARD key from the Work Screen • Pressing the Target Rate line opens the screen for entering the desired target rate. -
Page 36: Activating Tank Agitation
SPRAYER JOB COMPUTER IC45-DYNARATE ® USING TANK AGITATION Activating Tank Agitation NOTE: Agitation mode may not be available on all sprayers. For more information, contact your manufacturer. The tank agitation system performed by the spray pump can be activated/deactivated both from the Sprayer Job computer, as well as other physical locations, according to the ongoing task: –... -
Page 37: Machine Profile
SPRAYER JOB COMPUTER IC45-DYNARATE ® MACHINE PROFILE Go to the Main Menu Machine Job settings Machine Profile Section Width Press the Section number you wish to change the numerical value The number of pages in this menu, depends on how many of (cm). -
Page 38: Nozzle Spacing
SPRAYER JOB COMPUTER IC45-DYNARATE ® Nozzle Spacing Enter the value in cm, how far there is between each of your nozzles. Shortened Section Pressing this line, will turn the toggle ON, meaning you instantaneously alter your outermost working widths, by the value of the number entered in the line below. -
Page 39: Choice Of Regulation Mode
SPRAYER JOB COMPUTER IC45-DYNARATE ® CHOICE OF REGULATION MODE How to Switch between Manual and Automatic Modes This key on the Work Screen allows you to select the control mode between manual and automatic regulation. A green “M” indicates Manual mode. Mode: Manual Automatic... -
Page 40: Manual Mode
SPRAYER JOB COMPUTER IC45-DYNARATE ® Manual Mode In manual mode, the application rate is not automatically regulated according to the vehicle speed. The target rate is adjusted manually by pressing the Rate decrease or increase keys. These keys will open or close the control valve and adjust the target rate as desired. - Page 41 SPRAYER JOB COMPUTER IC45-DYNARATE ® SETUP OF THE DOSE RATE ADJUST STEPS: You can modify the percentage of the dose rate boost keys. The default step is +/- 5%. To modify this percentage go to: Main menu Machine Job Settings Operation Press the “Boost percentage step”, then enter the desired value.
-
Page 42: Filling The Sprayer Tank
SPRAYER JOB COMPUTER IC45-DYNARATE ® FILLING THE SPRAYER TANK Tank filling can be done in different ways, depending on the – The features of your Sprayer Job Computer (is it fitted with functions supported by your sprayer: the Tank Fill option or not) –... -
Page 43: Filling Setup With Dynafill Optional Feature
SPRAYER JOB COMPUTER IC45-DYNARATE ® JOB COMPUTER CONTROLS: If using a sprayer with this feature, the filling is started, simply by pressing the “Filling Status” line to toggle the button ON. This will display the “Filling Progress” line on the bottom line, showing the percentage of the ongoing filling progress, in real- time. - Page 44 SPRAYER JOB COMPUTER IC45-DYNARATE ® Press the Settings to access the Settings Menu. There are two ways of calculating the required volume, Simple and Advanced. SIMPLE MODE: To set the calculator to simple mode, use the navigation button arrows (Up/Down) to move the black dot cursor to the “Calculator Type”...
- Page 45 SPRAYER JOB COMPUTER IC45-DYNARATE ® Enter the desired volume to be filled into the tank with the central button: - The left and right arrows move the rectangle cursor to the left or right. - The up and down arrows increase or decrease the number in the rectangle cursor unit by unit.
- Page 46 SPRAYER JOB COMPUTER IC45-DYNARATE ® Enter the required values in each of the other lines, using the central button. When all information lines have been filled in, validate. The required volume is calculated and the result (in this case 1260 liters) is automatically registered in the system as “Desired content”, displayed on the remote display as well as on the universal terminal display in the cabin.
-
Page 47: Filling The Tank With Liquid Fertilizer
SPRAYER JOB COMPUTER IC45-DYNARATE ® START FILLING AND FILLING STATUS: A tap is displayed on the DynaFill Terminal indicating the remaining volume to be filled to reach the required volume. Start filling The fill button activates the filling valve (ON/OFF) Pressing the Increase Pump Fill Speed or Decrease Pump Fill Speed will change the speed of the filling pump, by the percentage that has been set in the Settings Menu. - Page 48 SPRAYER JOB COMPUTER IC45-DYNARATE ® USING THE DYNAFILL TERMINAL: Display the calculator by pressing the corresponding button. Both simple and advanced mode of the calculator, feature the density setup function you will use, to move from water solution to liquid fertilizer spraying and vice-versa. Use the Up/Down arrows of the navigation button to move the black dot cursor to the Density line as shown below: Advanced mode:...
-
Page 49: Agitation
SPRAYER JOB COMPUTER IC45-DYNARATE ® Agitation NOTE: Agitation mode may not be available on all sprayers. For more information, contact your manufacturer. You may want to keep the spray solution properly mixed while you are driving toward the field or during the whole spraying operation. The agitation system can be activated from the work screen of the in-cab terminal with the dedicated key or from the JOB WIZARD by toggling the Agitation button to ON. -
Page 50: Use Of The Hydraulic Functions Of The Boom
SPRAYER JOB COMPUTER IC45-DYNARATE ® USE OF THE HYDRAULIC FUNCTIONS OF THE BOOM NOTE: Folding options depend on the sprayer’s configuration. Boom Lock Whether driving on the road, folding or unfolding boom, the boom’s pendular suspension must be locked, both for safety and to ensure a proper fixed position. -
Page 51: Up / Down
SPRAYER JOB COMPUTER IC45-DYNARATE ® This screen may feature several key pages, depending on the sprayer type and configuration, and will also display the Spray Boom’s pendular suspension lock/unlock key. To unfold, use the following keys : Unfolding the Left-hand Unfolding the Right-hand spray boom spray boom... -
Page 52: Folding
SPRAYER JOB COMPUTER IC45-DYNARATE ® Folding To fold the boom, first lock the boom’s pendular suspension, then use the following keys : Folding the Left-hand Folding of the Right-hand spray boom spray boom As long as the key is pressed, the hydraulic system performs the desired movement and the terminal screen displays an illustration of the moving part colored in blue and with a direction arrow. -
Page 53: Alarm Configuration
SPRAYER JOB COMPUTER IC45-DYNARATE ® ALARM CONFIGURATION Accessible from the Main menu, the alarm settings page allows you to choose the events that will trigger a visual alarm on the screen during the work. By touching a line you can access the value entry screen that uses a numeric keypad. -
Page 54: Start Spraying
SPRAYER JOB COMPUTER IC45-DYNARATE ® START SPRAYING When all settings are completed and the sprayer is ready for work, start spraying by pressing the “spray” key. The working screen displays the information in real time, the automatic regulation sets the required rate. www.teejet.com... -
Page 55: Useful Information When Spraying
SPRAYER JOB COMPUTER IC45-DYNARATE ® USEFUL INFORMATION WHEN SPRAYING A selection of information is permanently displayed on the screen in the configurable information areas. To view other available information: - Press on one of the information areas - The list of information is displayed (Multiple pages) with actual values in real time. -
Page 56: Status Bar
SPRAYER JOB COMPUTER IC45-DYNARATE ® STATUS BAR The grey status bar at the bottom of the screen, displays icons indicating active functions: agitation system status, boom lock status, sensors, etc. By pressing the status bar, a list of the possible symbols will be accessible, along with the meaning of each symbol (Multiple pages): www.teejet.com... -
Page 57: Section Control On The Screen
SPRAYER JOB COMPUTER IC45-DYNARATE ® SECTION CONTROL ON THE SCREEN The function key pages on the work screen include commands to turn ON and turn OFF spray boom sections. The sections are represented by rectangles under the spray boom: • Sections are Blue, when the sections are turned ON and the sections are spraying... -
Page 58: After Spraying
4 - AFTER SPRAYING... -
Page 59: Chapter 4 - After Spraying
SPRAYER JOB COMPUTER IC45-DYNARATE ® CHAPTER 4 - AFTER SPRAYING TASK COUNTER The Job Data key in the general menu accesses Press on the line to access the corresponding counters: the counters page. The device has 3 counting levels: • Mission, with 16 independent task counters which can be reset •... -
Page 60: Alarm Log
SPRAYER JOB COMPUTER IC45-DYNARATE ® ALARM LOG The logbook key records alarms that occur The alarm log will assist the user or service technician in getting during work. on an overview of the most common issues and thereby make it easier to pinpoint the root cause of any problem that may be It should be able to be found on one of the occurring or have occurred. - Page 61 5 - DIAGNOSTICS...
-
Page 62: Chapter 5 - Diagnostics
SPRAYER JOB COMPUTER IC45-DYNARATE ® CHAPTER 5 - DIAGNOSTICS To access test and other functions. Go to Main Menu: Help DIAGNOSTIC OF SENSORS To test the connection and activity of the sprayer sensors: Go to Main Menu: Help Test Inputs - ECU Power = System supply voltage - Implement Speed = Number of impulses from speed sensor - Flow = Number of impulses from flow meter... -
Page 63: Diagnostic Of Actuators
SPRAYER JOB COMPUTER IC45-DYNARATE ® DIAGNOSTIC OF ACTUATORS To test the operation of the valve actuators: master valve, regulation valve, filling valve, section valves: Go to Main Menu: Help Test Outputs Pressing the ON /OFF buttons activates the corresponding valves via the on-board computer to verify that they are responding correctly to its commands. - Page 64 IC45-DYNARATE U S E R M A N U A L 98-05365-EN-A4/LT R2 English International © TeeJet Technologies 2023 www.teejet.com...
