Melbourne MTC-11428 Owner's Manual

Cabinet scraper
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CABINET SCRAPER
Owner' s Manual
Invoice Number: ................................................................
Date of Purchase: .............................................................
Record the invoice number and date of purchase
in your manual for future reference.
1
V1 01/24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MTC-11428 and is the answer not in the manual?

Questions and answers

Related Manuals for Melbourne MTC-11428

Summary of Contents for Melbourne MTC-11428

  • Page 1 V1 01/24 CABINET SCRAPER Owner’ s Manual Record the invoice number and date of purchase in your manual for future reference. Invoice Number: ..............Date of Purchase: .............
  • Page 2 Cabinet Scraper Specifications: MTC-11428 Length 70mm (2 ¾") Width 290mm (11") Sole Length 68mm (2 5/8") Sole Width 85mm (3 3/8") Weight 875g (1lb 15oz) Blade Steel Carbon Steel Blade Width 70mm (2 ¾") Blade Thickness 1.5mm (1/16") Replacement Blade...

  • Page 3: Table Of Contents

    Honing Burnishing Setting the Blade Taking a Shaving Section 4: Maintenance Section 5: Troubleshooting Tool Will Not Cut Hard to Push The Wood is Scratched or Gouged Section 6: Warranty Melbourne Tool Company Warranty Statement Disclaimer Manual Accuracy Technical Support...

  • Page 5: Introduction

    Melbourne Tool Company Born from a desire to supply woodworkers with quality products at an affordable price, Melbourne Tool Company is proud to bring to market a growing range of authentic hand tools. Designed and developed in Melbourne, Australia, the MTC range will support...

  • Page 6: Section 1: Safety

    SECTION 1: SAFETY General Safety Rules For your own safety, please read and understand this instruction manual before installing and operating the tool. Owner’s Manual: Read and understand this owner’s manual before using the tool. Handle With Care: Hand tools include sharp blades that will cause serious injury if handled improperly.

  • Page 7: Section 2: Component Diagram

    SECTION 2: COMPONENT DIAGRAM Diagram 1. Body 5. Blade Clamp Thumbscrews 2. Sole 6. Blade 3. Blade Adjustment Thumbscrew 7. Blade Bed 4. Blade Clamp...

  • Page 8: Section 3: Operation

    SECTION 3: OPERATION First Use • Your cabinet scraper ships with a coating of rust-inhibiting oil to ensure it arrives to you in good condition, but this must be removed prior to use. • Remove the blade by backing off the blade adjustment thumbscrew, then loosen the blade clamp screws and lift the blade out, taking care with the sharp edges of the blade.

  • Page 9: Burnishing

    3. Burnishing: The final step is to burnish the edge using either a store-bought burnisher or an improvised one – a nail punch shaft is a reasonable substitute. A drop of oil wiped along the burnisher will help. Start with a few moderate strokes on the flat face of the blade to draw the edge.

  • Page 10: Setting The Blade

    Setting the Blade • Loosen the blade clamp thumbscrews so that there is ample room behind the clamp bar, and back off the blade adjusting thumbscrew so that it does not protrude through the body of the tool. • With the tool sitting on a flat surface install the blade, being careful to avoid damaging the burr.

  • Page 11: Taking A Shaving

    Taking a Shaving The MTC Cabinet Scraper is designed to be used on the push stroke. Place your thumbs either side of the blade adjustment thumbscrew, and the palms of your hands on the cork handles. Your thumbs and index fingers can be used to feel the cut, with your palms providing most of the thrust.

  • Page 12: Section 4: Maintenance

    SECTION 4: MAINTENANCE Maintenance • After each use, disassemble the cabinet scraper and clean off accumulated dirt, grease, resin and rust, especially from the threads and sole. An old toothbrush is ideal for this, however please check that your spouse has finished with it first.

  • Page 13: Section 5: Troubleshooting

    SECTION 5: TROUBLESHOOTING Tool Will Not Cut • The blade may not be protruding from the sole – advance the blade using the adjusting thumbscrew, or reset the blade • The burr may be turned too far so that it is riding on the curved back of the burr - pick-up the burr as described in Sharpening Hard to Push Tear-out occurs when the wood splits ahead of the blade.

  • Page 14: Section 6: Warranty & Support

    If your Melbourne Tool Company product has a warrant-able fault, please contact the retailer that it was purchased from. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.

  • Page 15: Disclaimer

    Disclaimer Customers should ensure that they take all reasonable safety precautions when operating MTC products. MTC will not be held liable to you in respect of any personal injury (including without limitation serious injury or death) that you may suffer or sustain directly or indirectly as a result of the use of products sold by us.
  • Page 16 Notes:...
  • Page 18 www.melbournetool.com...
