- Page 2 Precautions 200kg max. 1 + 1 CAUTION! Maximum load Maximum capacity: No safeguard 2 persons capacity against drowning. Instructions for use 7 years and older For swimmers only Safety zone & safety Offshore winds Offshore currents instructions must be observed...
- Page 3 Congratulation to your GTS inflatable SUP board We are proud to present you a quality product at an affordable price. Please take the necessary time to read and study this manual. It provides details on how to handle, operate and maintain your board. Familiarize yourself with your board before using it in water in order to ensure your safety and to avoid accidents.
- Page 4 Drawing GTS iSUP-Boards 1 - Large cargo net 7 - Valve cover 2 - Non-slip deck pads 8 - D-ring for pulling function 3 - Handle 9 - Nose Protection 4 - Additional handle 10 - Double layer skin 5 - Tail end cargo net...
- Page 5 Technical specifications GTS iSUP-Boards Model Länge Breite Höhe Gewicht Volumen (cm/foot) (cm/inch) (cm/inch) (kg/lbs) (Liter) RS 12.6 381/12.6‘ 73,7/29,0“ 15/6“ 9/19.8 ------------------------------------------------------------------------------------------------------- RST 12.6 381/12.6‘ 75/29.5“ 15/6“ 9,6/21.1 ------------------------------------------------------------------------------------------------------- CRUISER 11.6 354/11.6‘ 82,5/32.5“ 15/6“ 9/19.8 ------------------------------------------------------------------------------------------------------- SPORTSTOURER 12.0 366/12.0‘ 76/30,0“...
- Page 6 Double-stroke pump LEVANTE (1) Attach hose Attach hose to to inflate deflate The LEVANTE double-stroke pump enables effective pumping and suction (1) both when pulling and when pushing. A reliable pressu- re gauge (4) is used to control the pressure. Other features include removable handle ends (2), fold-up foot parts (3), an extensive adapter set and three adjustment options...
- Page 7 Double-piston pump DOUBLE MAX (1) Attach hose Attach hose to to inflate deflate The DOUBLE MAX double piston pump enables even more effecti- ve pumping and suction (1) when pulling as well as pushing. A reli- able pressure gauge (4) is used to control the pressure.
- Page 8 Instructions / Inflation / Deflation Inflate your board with the provided pump or any other SUP-pump. These types of pumps are equipped with a hose and an adapter in order to mount the valves onto the deck of the board. Choose a smooth and clean surface to inflate your board.
- Page 9 GTS paddle (4) Handle part Assembling the 3-part paddle with markings First connect the lower part with the blade (6) to the middle part. To do this, press down the pin (1) and push both parts together until the pin locks in the (5) Clamp opening (2).
- Page 10 When you expose your board to intensive sunlight, check the air pressure and, if necessary, release some air. Otherwise the board can burst. In this case the warranty becomes invalid. The surrounding tempe- ratures have an impact on the pressure inside the board: a change of 1°C / 1.8°F causes a change of pressure of +/- 4 mbar (0.06 psi) within the board.
- Page 11 Maintenance / Care 1. To ensure long-lasting performance of your board you have to maintain it. 2. Clean and check the valve and all accessories. Make sure that the board iscompletely dry before you store it and that neither sand nor other impurities remain in the valve or between the rear of the board and the inner chambers.
- Page 12 4 phases - paddle stroke Bend your upper body forward as much as possible and stretch out your arms as illustrated. Unlock your knees. The paddle stroke should always be carried out parallel to the board. Place the paddle into the water and stroke it forcefully towards your body.
- Page 13 Remove the paddle from the water alongside your body. Now rotate the paddle at 90 degrees making it vertical to the board; then move it forward with the paddle-blade edge.
- Page 14 Paddle position Front/nose Rear/tail...
-
Page 15: Warranty
Warranty 24 months warranty + 6 months upon registration = 30 months The manufacturer´s warranty is 24 months. Upon registration of your product you are granted an extended warranty period of 6 months. Please register here: https://www.grandtoursports.de/support/produktregistrierung/ In the case of a product warranty or return claim the buyer bears all shipping cost. - Page 16 HEAD OFFICE GTSports GmbH Eiswerderstraße 18 Gebäude 129 13585 Berlin / Germany Telefon: +49 30 20654716 E-Mail: info@grandtoursports.com...
