Consequently, Philips has not undertaken any such broad evaluation. Accordingly, a servicer who uses a service procedure or tool which is not recommended by Philips must first satisfy himself thoroughly that neither his safety nor the safe operation of the equipment will be jeopardized by the service method selected.
[metres] [inch] [metres] [inch] [metres] Ceiling mount (LCA2211/00) VGA extension cable, 15 metres (LCA5300/00) Executions LC6231/17 USA version LC7181/17 USA version 1086 LC6231/40 RoW version LC7181/40 RoW version LC6231/45 UK version LC7181/45 UK version 1552 * : depending on regional requirement...
3. Warnings & Notes LC6231/LC7181 Warnings Notes Safety regulations require that the unit should be returned in The direct voltages and oscillograms should be measured its original condition and that components identical to the with regard to earth (4), or hot earth (5) as this is called.
4. Mechanical instructions LC6231/LlC7181 Opening the cabinet Remove the 4 screws (D) holing the top cover (Fig. 3). If the 4 screws are removed, the top cover can be lifted off. Please be careful not to pull of the cable to the keyboard.
Page 6
LC6231/LC7181 Remove the 6 screws “F” holding the top shield Remove screw “K” and connectors “L” (Fig. 8). (Fig. 5). Then remove the 3 screws “G” and the Nor the DRB (Drive Boards) can be removed. 2 screws “H” (Fig. 6). Now the top shield can be DRB Board removed.
Page 7
LC6231/LlC7181 Remove the 4 screws “M” (Fig. 10). Now the side cover can To operate the projector in this situation, connect the SSB be removed. and DRB together again, and connect the top-cover, LCD fan and dust filter switch to the SSB. Put some insulation under the SSB and DRB board.
Page 8
LC6231/LC7181 Remove screws “P” to remove the Power supply (Fig. 13). Mounting of air guide: First put the bottom pin into hole “R”, and then click the top pin into hole “S”. (Fig. 16). Power Supply Engine CL 266450004_057.eps Fig. 13 240402 CL 266450004_060.eps...
5. Block diagrams & Wiring diagram LC6231/LlC7181 BLOCK DIAGRAM Audio in Data IR Receiver Keyboard Leds Audio in Video Downstream Data Video Audio Audio control ampl. controller Flash memory EEPROM PW 166 Drive electronics Video CVBS Scaler sync panels decoder...
LC6231/LlC7181 SCALER / FRAMEBUFFER / MICROPROCESSOR 7510 7511 AM29LV800 CY62127 7501 ST24E16 FLASH ROM +3V3 EEPROM 7300 PW166 +2V5 ROM/RAM INT I/O PORTS UART MCKEXT VIDEO CLOCK VIDEO µPROC. PROC. PROC. DCKEXT DATA FRAME COLOUR SCALER PROC. BUFFER MEMORY CONTROL...
LC6231/LlC7181 Lamp supply board 1902 +300V to PSB Lamp Lit Lamp is on Supply to SSB Control Lamp Start Lamp EN 26645004_034.eps 160402 POWER SUPPLY BOARD 100- +295V Auto- To lamp 250V voltage supply +295V panel Standby +5 STBY supply...
8. Optical alignments LC6231/LlC7181 Corner mirror Red Put on a red picture. If dark bands are visible on the sides, loosen the two screws (A) fixing the mirror on top, and move the mirror till the dark bands are gone.
Page 60
LC6231/LC7181 Convergence alignment In the standard configuration the convergence cannot be adjusted. If convergence adjustment is necessary (e.g. after replacing an LCD), this can only be done after replacing the LCD fixation screws by special screws. The alignment is then done by moving the LCD panel itself around the screws.
Page 61
LC6231/LlC7181 Aligning the convergence With a the key (I), the 2 screws (H) can be loosened from the top. This is a critical action: the crews have to be loosed so that the LCD can be moved with some friction.
