SenTech A1 Instruction Manual

Product Overview
Fixed Buckle
Mating
Part
Key
FRONT
Di user
Head
Bottle
INSIDE
Bottle Key Screws
Installation
1 2
Unlock and Open: Insert the key into the corresponding slot, turn it counterclockwise to the "unlock"
1
position, and pull it out. Press the xed button on top and push forward to open.
Attach the Atomizer: Securely connect the atomizer head to the fragrance bottle, then install the
2
assembly into the di user.
Power the Device: Select either Power Mode (plug into an outlet) or Battery Mode (insert batteries). For
3
rst-time use, allow approximately 12 minutes for the machine to charge after connecting to power.
Lock and Secure: Insert the key back into the slot, align it with the keyhole, and turn it clockwise to lock.
4
5
Secure the mounting bracket to the wall using the 3 screws.
Note:
The 3M adhesive should only be applied to clean, smooth surfaces such as at tiles or wooden panels. For added security, it is
recommended to seal the edges of the adhesive with a suitable sealant. Please be aware that the 3M adhesive alone may not
provide strong xation, and improper installation could result in the di user falling.
Bluetooth Indicator
Searching for Signal – Flashing light
Connected – Steady light
Disconnected – Light o
BACK
Power Battery Reset Level Detector
Mode Mode Button Reset Button
Accessories
Mounting USB Cable
Manual
Bracket
(purchase on selection)
3 4
6
Carefully hang the di user onto the mounted bracket.
USB Port
Hanging
Hole
Bluetooth
Indicator
Specification
Model
A1
Power
1.5W
Concentration and Consumption
Grade
Intervals (min)
Consume (ml/h)
Grade
Intervals (min)
Consume (ml/h)
Note:
1. A 100ml bottle of essential oil can di use approximately 6,300 to 6,700 times under normal conditions.
2. The atomization duration for all the above grades is 3 seconds per cycle.
3. Oil consumption may vary depending on the selected grade and the type of essential oil used.
SMART AROMA DIFFUSER
Instruction Manual
Size Weight
148*58*158mm 450g
Coverage Bottle
30m²/90m³/3200ft³ 100ml
G1 G2 G3
15 13.5 12
0.04 0.05 0.06
G6 G7 G8
7.5 6 4.5
0.13 0.19 0.24
Voltage
DC 5V
Material
Plastic
G4 G5
10.5 9
0.07 0.08
G9 G10
3 1.5
0.30 0.35
