Penpower EZGoW01 Hardware Introduction

Hide thumbs

Advertisement

Table of Contents

No need to install EZGo Wireless in any computer. All you need to
do is plug the EZGo Wireless into a computer and then you can use the
handwriting recognition immediately.
The front side of the
Left Button Middle Button Right Button
Status LED
Multifunctional
quick selection
area
Hardware Buttons:
• Left button: Change the recognized character with the candidate
characters.
• Middle button: Remove a character before the cursor.
• Right button: Input/Switch common-used symbols.
Hardware Introduction
EZGo Wireless (Model No.:EZGoW01)
Handwriting
Area
1
Pen Holder

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EZGoW01 and is the answer not in the manual?

Questions and answers

Related Manuals for Penpower EZGoW01

Summary of Contents for Penpower EZGoW01

  • Page 1 No need to install EZGo Wireless in any computer. All you need to do is plug the EZGo Wireless into a computer and then you can use the handwriting recognition immediately. The front side of the EZGo Wireless (Model No.:EZGoW01) Left Button Middle Button Right Button Status LED Pen Holder...

  • Page 2: Hardware Connection

    The back of the EZGo Wireless (Model No.:EZGoW01) Power Switch Pairing Button Battery Cover Dedicated Receiver (Model No.:JLMT-001) Hardware Connection Please open the battery cover on the back of the EZGo Wireless, insert two AAA batteries, and turn on the power switch.
  • Page 3 Status Indicators Power On Purple Light Connected Steady Blue Light Low Battery Flashing Red Light Standby None (EZGo Wireless can be woken up by any button press or writing action.) Pairing Flashing Blue Light Power Off None Reminder: EZGo Wireless can be used without pairing; re-pairing is only necessary when replacing the receiver.

  • Page 4: Getting Started

    Getting Started (The following instructions and operations are primarily based on the Windows platform.) EZGo Wireless can recognize your handwriting and send it out to any text field. Take Microsoft Word for example. Connect the dedicated receiver of the EZGo Wireless to the USB port of your computer.
  • Page 5 Post-related Words :Candidate Words :Function Menu :Full/Half Width Symbol :Show/Hide Post- related Words, Homophone, :Post-related Words Related Phrases :Homophone :Writing Pad :Input Tool ◎ Multi-words Writing Mode Character Buffer EZGo Wireless default uses [Multi-words Writing Mode], please open any text editor, such as Microsoft Word. Write a word on the writing area.
  • Page 6 In this mode, you can write single word or multi-words at a time, when you stop writing, the program will send the recognitions to Microsoft Word. Tip: You should stare at the handwriting on the screen, not focus on the writing pad. ◎...
  • Page 7 Please open any text editor, such as Microsoft Word. Write a word on the writing area. While you are writing, please look at the screen rather than the tablet. When you stop writing, the program will send the recognitions to Microsoft Word. To close EZGo Wireless, please click button on the toolbar and don’t unplug the tablet until the message disappears.

  • Page 8: Virtual Function Keys

    ◎ Virtual function keys EZGo Wireless provides you virtual function keys, it allows you to quickly switch between candidate characters and frequently used symbol input without using the mouse. The backgroud paper of writing area is as below. The numbers and symbols in the top and bottom rows are virtual function keys.

  • Page 9: Writing Pad

    symbols, so that you can quickly complete the selection without looking at the tablet to select. Note: The virtual function keys in the upper row only work in multi-word writing mode; if you do not use the virtual function keys, you can close it in the [Settings]. Writing Pad ◎...
  • Page 10 Virtual Button: Virtual Button: Clear Finish Writing Pad Tips: 1. You can tap the left/ right top corner of the writing pad with the pan to use Clear and Finish functions, or you can also click the bottom of the writing pad with the mouse to use the functions.
  • Page 11 words in the candidate area to replace the current one. Candidate character Tip: While using English keyboard, click to change to capital letter and click again to return to small letter. * For further information, please click on the normal version interface to refer to the user manual on the website.
  • Page 12 : " G o " / " A p p l i c a t i o n s " / " P P J r _ M a c folder"/"PenPower Jr. Mac" to run EZGo Wireless.
  • Page 13 To ensure that writing can be accurately sent to the target software, please follow the steps below: Open "System Preferences." Go to "Security & Privacy". Go to "Accessibility" and enable the "PenPower Jr. Mac" item.
  • Page 14 Next, go to "Input Monitoring," and similarly enable the "PenPower Jr. Mac" item to complete the setup.
  • Page 15 Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
  • Page 16 which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.
