Home Depot CE TECH EC022WH-C Use And Care Manual

TOOLS REQUIRED
Phillips
Safety Goggles
Screwdriver
PACKAGE CONTENTS (parts are not to scale)
A - Cord and Switch x 1
Installation
1
Planning the installation
Layout the xtures (C), connectors (D), and plug (A) in the desired
locations for installation.
Prior to installation, remove the bulbs (B) from the xture housings (C)
by turning counterclockwise.
Measure and mark the desired locations of the xtures (C). Ensure
that you leave enough room for the 19 in. connector cords (D) to
connect between the xtures (C) and for the plug (A) to reach your
electrical outlet. Screw the xture housings into place using the
mounting screws (E) provided.
Twist the bulbs (B) clockwise back into the xture housings (C) until
they lock in place.
B
E
D
C
NOTE: Wires must be aligned with the cord port on the side of the xture
housing to ensure correct electrical connection.
Use and Care Guide
3 Light Linkable Fluorescent Under Cabinet Kit
Pencil
B - Bulbs x 3 C - Fixtures Housings x 3
B
E
C
D - 19 in. Connectors x 2
2
Connecting the xtures and connectors
to the plug
Connect the power cord (A) to the rst xture (C) closest to the outlet.
Connect the second xture (C) to the rst xture
19 in. connector cords (D) included.
Connect the third xture (C) to the second xture (C) using the
remaining 19 in. connector cord (D).
Plug the power cord (A) into the outlet and turn on the breaker to the
outlet.
Use individual power switches (1) on each xture (C) or use the
master power switch located on the plug cord (A) to light all three
xtures simultaneously.
E
D
1
C
Item #642-265
Model #EC022WH-C
E - Mounting Screws x12
(C) using one of the
D
E A
1
C
WWW.HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
120V
