SafezoneXID-500 Instruction Guide
Ver 0.3

Advertisement

loading
Need help?

Need help?

Do you have a question about the CNS SafezoneXID-500 and is the answer not in the manual?

Questions and answers

Summary of Contents for LG CNS SafezoneXID-500

  • Page 1 All manuals and user guides at all-guides.com SafezoneXID-500 Instruction Guide Ver 0.3...

  • Page 2: Safety Instructions

    All manuals and user guides at all-guides.com Safety Instructions  The Following instructions ensure your safety and prevent any damage. Be sure to read the following instructions and use the product correctly ① Do not install the terminal in a place affected by direct sunlight, humidity, dust or soot. ②...
  • Page 3 All manuals and user guides at all-guides.com 1. Port...
  • Page 4 All manuals and user guides at all-guides.com 1. Port ① LAN Port (for RJ-45) ② DIP S/W -R232 : Connect 2-3 and 5-6 with shunt -WIEGAND : Connect 1-2 and 4-5 with shunt ③ R485/RS232(WIEGAND) port ④ INPUT port 1) INPUT1 : can be used when using EXIT Button 2) INPUT2 : is indicating DOORSTATUS signal 3) INPUT3 : Optional Input ⑤...
  • Page 5 All manuals and user guides at all-guides.com 1. 단말 포트  Caution in connection of each port 1) Power * SMPS or Adaptor : Installer should check the voltage level if it is 12V * Since including Adaptor have FGND so that Installer should check FGND with Adaptor 2) RS232/WIEGAND Dip-switch install * RS232 : Set as 2-3 and 5-6 * WIEGAND :...

  • Page 6: Network Setting

    All manuals and user guides at all-guides.com 2. Network Setting...
  • Page 7 All manuals and user guides at all-guides.com 2. 네트워크  Notice for connecting LAN jack - Should be check the connection of hook - Prevent the substance in the RJ-45 - The following Icon indicates the network condition  Link down, please check the cable connection ...
  • Page 8 All manuals and user guides at all-guides.com 3. EM / Deadbolt / Strike (One-direction Installation)
  • Page 9 All manuals and user guides at all-guides.com One-direction Installation 3. EM / Deadbolt / Strike ※ Electrical Lock should have the sensor of Hi-Box AWG24 * 2C the door status ※ Connection Set UTP cable 1 PCS, Power GND- AWG24*1C AWG24*1C ( power+) ( LOCK NC)
  • Page 10 All manuals and user guides at all-guides.com One-direction Installation 3. EM / Deadbolt / Strike INPT1 INPT1 INPT2 INPT2 INPT3 INPT3 LOCK LOCK LOCK LOCK 전원 전원 TR(+) TR(-) Room Door Lock...
  • Page 11 All manuals and user guides at all-guides.com One-direction Installation 3. EM / Deadbolt / Strike [Operation Mode] [Manager] > [Controller] [Manager] > [LCM]  LCM유형 : None  Set to “단말기 해체 경보음”  DoorLock 설정 : Set on purpose of ...
  • Page 12 All manuals and user guides at all-guides.com One-direction check-point 3. EM / Deadbolt / Strike  Abnormal LOCKing 1. In case of the operation of LOCK is reversed : 1) Confirm the setting of LCM as “RelayOut#1” 2) Check the wire connection it is LOCK NC or NO. -ex) Fail safe type should be set as LOCK NC.
  • Page 13 All manuals and user guides at all-guides.com One-direction check-point 3. EM / Deadbolt / Strike  Abnormal Door status sensing 1. In case of the operation of the Door status is reversed : : Check the wire connection and the setting of LCM is proper setting NC/NO 2.
  • Page 14 All manuals and user guides at all-guides.com 4. EM / Deadbolt / Strike (Bi-directional Installation)
  • Page 15 All manuals and user guides at all-guides.com Bi-directional Installation 4. EM / Deadbolt / Strike ※ Electrical Lock should have the sensor of Hi-Box AWG24 * 2C the door status ( Power+-) AWG24 * 2C ( Power+-) ※ Connection Setting Outdoor XID-500 UTP cable 1 PCS, Power Line 2P...
  • Page 16 All manuals and user guides at all-guides.com Bi-directional Installation – Outdoor XID 4. EM / Deadbolt / Strike INPT1 INPT1 INPT2 INPT2 INPT3 INPT3 LOCK LOCK LOCK LOCK 전원 전원 TR(+) TR(-) Power Power Indoor XID Room RS-485 Port...
  • Page 17 All manuals and user guides at all-guides.com Bi-directional Installation – Indoor XID 4. EM / Deadbolt / Strike INPT1 INPT1 INPT2 INPT2 INPT3 INPT3 LOCK LOCK LOCK LOCK 전원 전원 TR(+) TR(-) 전원 Power Power Power Power(+) Outdoor XID Room Door Lock RS-485 Port Power(+)
  • Page 18 All manuals and user guides at all-guides.com Bi-direction Installation 4. EM / Deadbolt / Strike [기기관리] > [기기제어] [기기관리] > [LCM] [운용]  LCM Type : None  Set to “출입”  Set to “단말기 해체 경보음”  DoorLock 설정 : Set on purpose of ...
  • Page 19 All manuals and user guides at all-guides.com Bi-direction notice 4. EM / Deadbolt / Strike  Abnormal LOCK 1. You can check the following when the door lock is not operated - Confirm the setting of RS485 IN/OUT - Be sure the direction of XID-500 Indoor/Outdoor ※...
  • Page 20 All manuals and user guides at all-guides.com 5. Dummy...
  • Page 21 All manuals and user guides at all-guides.com 5. DUMMY ※ Please RS232 port of XID-500 with other device in order to operate the dummy mode Other Device AWG24 * 2C ( DC 12V ) AWG24 * 3C (RS232)
  • Page 22 All manuals and user guides at all-guides.com 11. DUMMY ※ RS232/WIEGAND Header - Check the shunt connection of 2-3 and 5-6 INPT1 INPT1 INPT2 INPT2 INPT3 INPT3 LOCK LOCK LOCK LOCK 전원 전원 TR(+) TR(-) Power Power ROOM...
  • Page 23 All manuals and user guides at all-guides.com Dummy Installation 11. DUMMY [운용] > [Customize] > [Dummy설정] [운용]  Set to “Dummy”  Dummy Type : RS232  Select the type of message(Message, Card number)  Confirm output mode...
  • Page 24 All manuals and user guides at all-guides.com 6. LCM Connection...
  • Page 25 All manuals and user guides at all-guides.com 6. LCM Connection Hi-Box ※ RS485 port can connect with LCM XID3.0 LCM 파랑 초록 ※ LCM Power should be seperated with XID-500 검정 AWG24 * 2C ( DC 12V ) AWG24 * 2C ( DC 12V ) Join RS485 wire AWG24 * 3C...
  • Page 26 All manuals and user guides at all-guides.com 6. LCM Connections INPT1 INPT1 INPT2 INPT2 INPT3 INPT3 LOCK LOCK LOCK LOCK 전원 전원 TR(+) TR(-) Power Power Room TRXD- TRXD+ LCM RS485 port...

  • Page 27: Installation

    All manuals and user guides at all-guides.com Installation 6. LCM Connections [운용] [기기관리] > [기기제어] [기기관리] > [LCM]  Set to “단말기 해체 경보음”  LCM Type : XID3.0  Set “운용모드” to “출입”  In/Out : Set on the direction purpose ...
  • Page 28 All manuals and user guides at all-guides.com 7. Additional Relay...
  • Page 29 All manuals and user guides at all-guides.com Additional Relay  The method of additional Relay connection The Relay capability should meet the ③ ① ⑤ ④ minimum requirements of 12V/5A Left image is showing 2 poles and 8 pins To operate NC1 or NO1, connect Pole1. To operate NC2 or NO2, connect Pole2.
  • Page 30 All manuals and user guides at all-guides.com XID-500 Product Specifications Item XID5.0 Card Option 13.56 MHz ISO14443 A/B(MIFARE) Physical Size (mm) 84 X 164 X 22.8 Weight (g) Interface Communication Interface RJ45, TCP/IP, 10/100T RS-485 RS-232 USB (for Printer) USB (for F/W Upgrade) Wiegand Output Built-in Relay...
  • Page 31 All manuals and user guides at all-guides.com XID-500 Product Specifications Item XID5.0 Hardware 536 MHz (SAMA5D31, Cortex A5) Memory 8 MB S-flash + 4 GB eMMC + 256 MB RAM LCD Display 4.3” color touch screed Humidity 90 % Tamper Switch Operating Voltage 12 VDC...
  • Page 32 All manuals and user guides at all-guides.com XID-500 Product Specifications Item XID5.0 Power Voltage (V) Current (mA) 400 (Max.) Switch VIH (V) Input VIL (V) GND (Low) Pull-up resistance (Ω) 10 K Wiegand VOH (V) Output VOL (V) GND (Low) Pull-up resistance (Ω) 4.7 K Relay...
  • Page 33 All manuals and user guides at all-guides.com FCC Information This device complies with part 15 of the FCC Results. Operation is subject to the following two conditions : (1) This Device may not cause harmful interface, and (2) This device must accept any interference received, including interference that may cause undesired operation.
