Summary of Contents for FSR 270 Awning V2
- Page 2 At FSR, we listen closely to you — our customers and our community. You’ve asked for innovation, top-tier quality, standout service, and gear that can go the distance. And thanks to your insight, we’ve built a product line that brings all of that to life.
-
Page 3: Table Of Contents
Table of Contents Product Overview......................270 Awning V2 Product Specifications................What's Included........................ Tools Required........................Attaching the 270 Awning V2................... Awning Setup Instructions....................Maintenance & Care...................... Troubleshooting Tips...................... FAQ’s..........................Safety Information......................Important Information..................... Warranty & Support...................... -
Page 4: Product Overview
Product Overview The Freespirit Recreation 270 Awning V2 is designed to provide rapid, reliable shelter from the elements. Whether you're seeking protection from intense sun or unexpected rain, the 270 Awning V2 delivers expansive coverage to enhance your time outside. -
Page 5: 270 Awning V2 Product Specifications
270 Awning V2 Product Specifications Coverage 80.7 sq/ft Closed Dimensions 90.5" x 5.9" x 5.9" Open Dimensions 72" x 112" Vehicle side, 52" x 126" Rear Weight 43 lbs Materials 600D Oxford Ripstop, PVC Exterior cover Power USB-A switch (battery pack sold separately) Backplate 2"... -
Page 6: What's Included
(3) Universal awning brackets included. It’s recommended to use your rack manufacturer’s awning brackets if applicable. *FSR Rooftop Tent Awning Brackets sold separately. We recommend (3) brackets for 270 awnings. -
Page 7: Tools Required
Tools Required ratcheting end wrench or socket ● 13mm ● Measuring tape ● Masking tape Attaching the 270 Awning V2 1. Prepare Hardware a. You’ll use (4) T-head bolts per bracket. We recommend you use a minimum of (3) brackets. - Page 8 5. Align and Secure a. Remove the masking tape once alignment is confirmed. b. With the help of another person, hold the awning up to the vehicle and get one end secured loosely by threading the bolts through the rear of your mounting brackets.
-
Page 9: Awning Setup Instructions
10. Press and hold the power button to adjust brightness. Release when the desired brightness is reached. The 270 Awning V2 includes an integrated keder rail along the base of the awning body. This allows the included gear grid, support pole bag, and small accessory bag to be mounted interchangeably for convenient storage and organization. -
Page 10: Maintenance & Care
Maintenance & Care 1. We recommend cleaning the exterior of the awning with mild soap and water using a soft sponge or cloth. Avoid harsh detergents or abrasive materials which can damage the finish or compromise waterproofing. After cleaning, dry thoroughly. 2. -
Page 11: Troubleshooting Tips
FAQ’s Q: Are poles required for setup? A: The 270 Awning V2 is designed to be freestanding in calm conditions. However, the included support poles should be used in windy, rainy, or unstable conditions (or when using optional awning walls) for added stability. -
Page 12: Safety Information
2. Please do not use your 270 Awning V2 if there is visible damage to any part or its components. Contact our team at customerservice@gofsr.com... -
Page 13: Important Information
Important Information Freespirit Recreation and our manufacturers are not liable for use or misuse of this awning or any of our other products. We are not liable for any damage or accidents that occur as a result of non-compliance with these usage instructions and basic common sense. Any modifications made to any parts, or the entirety of this awning are not covered under warranty and we are not liable for any injury or damage that could occur because these modifications were made.
