Page 1 INDUCTION HEATING SYSTEM FIRE F180...
Page 2: Operating And Safety Instructions
IMPORTANT: Read these operating safety instructions before using the INDUCTOR FIRE F180. OPERATING AND SAFETY INSTRUCTIONS INDUCTOR FIRE F180 Specializing in High Performance Induction Heating Systems...
Page 3 Dear Customer, Thank you and congratulations for choosing our induction heating system INDUCTOR FIRE F180, an instrument of great versatility that will be of great help to your business for many years. Our after-sales service is at your disposal for any problems regarding the use or maintenance of this machine.
Page 4: Warranty
The first use of INDUCTOR FIRE F180 involves the implicit acceptance from the user of all conditions prescribed by the manufacturer...
Page 5 Rules references Directive CE2004/40/ Esposizione ai campi elettromagnetici Directive CE delle basse tensioni 2014/35/EU Direttiva macchine 2006/42/EG Directive EMC 2014/30/EU RoHS Directive 2011/65/EU Directive CE 2012/19/EG Use of the manual It is very important that this manual, designed to provide the operator with a general knowledge of this machine as well as with the instructions for its use and maintenance deemed necessary for proper functioning,...
Page 6 ATTENTION! The operator has the responsibility for complying all the rules that relate to safety, not only for himself, but also those who may be exposed to the risks of the machine. Therefore, before performing any operation with the machine, read this manual carefully, it shows the instructions and how to proceed properly and safely.
Page 7: Construction Features
Do not allow the operator to come into direct contact with live parts during working that can result in electric shock or injury. And everything else needed to make the use of the machine safe. main parts composing INDUCTOR FIRE F180 can be described as follows: 1) Power switch 2) Control panel...
Page 8 Plates and warnings signs On the machine are placed warning signs and mandatory signs that the operator must follow for his safety and security. List of protections The machine is safe if used correctly, however, should be as careful as heated material may cause burns to the touch even long after the passage of the inductor.
Page 9: Unpacking And Installation
Unpacking and Installation The machine is supplied ready for use. Before using it, you must remove all packing material and place it carefully in place (leveled floor, dry and windy). WARNING! The installation must be designed to allow easy access to all its parts. The minimum spaces, on its perimeter, must ensure the use and maintenance, without problems and risks for the operator.
Page 10: Preventive Maintenance
ATTENTION! • Whenever you need to use the INDUCTOR FIRE F180 previously control the efficiency of safety devices, connection status, or that there are not any other anomalies, making several test maneuvers idling and on ferrous scrap.
Page 11: Electric Drawing
Electric drawing...
Page 12: Components And Spare Parts
Components and spare parts This section lists the components of the machine in question. Its contents can be used for the identification technique of spare parts as it lists the parts in detail and provides descriptive data and recognition. For a speedy delivery of spare parts, please quote the following order: 1.
Page 13 Table 1. Cabinet exploded view...
Page 15 Table 2. Hydraulic exploded view...
Page 16 Pos. codice item 1 IND-11/005.2 Trasformatore in ferrite 2 IND-11/005 scheda elettronica potenza 3 IND-5KW/VT1 vite M5 x 10 4 IND-11/005.6 Condensatore 0.33 Kemet 5 IND-5KW/VT9 Dado M5 6 IND-5KW/VT13 vite M3 7 IND-11/005.30 isolatore 8 IND-5KW/VT4 Vite M6 x 10 9 IND-5KW/VT11 vite M4 10 IND-5KW/005.C2...
Page 17 Inductor FIRE F180 MACHINE LOG We recommend using the following chart to record the maintenance of FIRE F180 Inductor and all inquiries made over time on the tool. This will allow the user to be able to have at any moment suitable information on the activity cycle of the machine.
Page 18: Declaration Of Conformity Rohs
Top Auto s.r.l. declares that: from 1 July 2006 any product placed on the market by Top Auto s.r.l. is in conformity with RoHS Directive, and does not contain concentrations that exceed the limits for the following substances:...
Page 19 (according to the Machinery Directive 2006/42/CE and s.m. , Attachment II /A ) Il Fabbricante/The Manufacturer Top Auto s.r.l. Viale del Lavoro 40 37030 Colognola ai colli ( VR) ITALY Dichiara che la macchina/declares that the machine INDUTTORE FIRE F180 INDUCTOR-18KW Nome commerciale/Commercial name Modello/Model Matr. Nr: Matricola/Serial Number Anno costruzione/Year...
Page 20 Top Auto S.r.l. Viale del Lavoro 40 37030 – Colognola ai colli (Verona) Technical Assistance: Mob: +39 3312451070 Mail: tech@topauto-equipment.com...
