INSTALLATION GUIDE
BLUEnet Door Controller
The BLUEnet door controller offers complete and easy
control for online and standalone access points in a
compact DIN rail built-in unit, including output relays and
input connectiones. Its universal SALTO compatibility
permits to integrate it with any door control device.
MODEL: ELECTRONIC INFO. CUC1B0 - CUCEB122
Copyright © 2025 Salto Systems, S.L.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Salto ECOSYSTEM BLUEnet CUC1B0
Summary of Contents for Salto ECOSYSTEM BLUEnet CUC1B0
- Page 1 The BLUEnet door controller offers complete and easy control for online and standalone access points in a compact DIN rail built-in unit, including output relays and input connectiones. Its universal SALTO compatibility permits to integrate it with any door control device. MODEL: ELECTRONIC INFO. CUC1B0 - CUCEB122...
- Page 2 INSTALLATION GUIDE | BLUEnet Door Controller CUC1B0 series CUCEB122 series (2-3/32") (1-1/4") (1-1/32") saltosystems.com PAGE 2/12...
-
Page 3: Installation
INSTALLATION GUIDE | BLUEnet Door Controller 安安 Installation Instalación Installation Installation Instalação 설치 ELECTRICAL CABINET WITH DIN RAIL CUADRO ELÉCTRICO CON CARRIL DIN SCHALTSCHRANK MIT DIN-SCHIENE 带 轨 轨 的 的 레일이 있는 전기 캐비닛 COFFRET ÉLECTRIQUE AVEC RAIL DIN ARMÁRIO ELÉCTRICO COM CALHA DIN 金金... - Page 4 INSTALLATION GUIDE | BLUEnet Door Controller ELECTRICAL CABINET WITH DIN RAIL AND TAMPER CUADRO ELÉCTRICO CON CARRIL DIN Y TAMPER SCHALTSCHRANK MIT DIN-SCHIENE UN SABOTAGE COFFRET ÉLECTRIQUE AVEC RAIL DIN ET SABOTAGE ARMÁRIO ELÉCTRICO COM CALHA 레일 및 변조 장치가 있는 전기 캐비닛 带...
- Page 5 INSTALLATION GUIDE | BLUEnet Door Controller (*) Please check the availability of the function in the software. Some options may not be available yet. It is recommended to install a maximum of 2 door controllers inside the CU Box. (*) Compruebe la disponibilidad de la función en el software por favor. Es posible que algunas funciones no se encuentren disponibles.
- Page 6 INSTALLATION GUIDE | BLUEnet Door Controller Wiring Conexionado Verdrahtung Câblage 布连 배선 Cablagem power input/output and proprietary serial bus for communication with 1. Input/Output: expansion boards. There are two groups of connections that are %100 identical. 2. Relay outputs: (1A/30VDC). 3.
- Page 7 INSTALLATION GUIDE | BLUEnet Door Controller Factory configuration inputs and relays Configuración fábrica inputs y relés Werksseitige Konfiguration der Eingänge und Relais Entrées et relais configurés en usine 出出外将 防和 输 继轨 器 공장 구성 입력 및 릴레이 Inputs e relés de configuraçao de fábrica 出厂配置...
- Page 8 INSTALLATION GUIDE | BLUEnet Door Controller OPERATING CONDITIONS POWER Input voltage Temperature -35ºC 70ºC Max Current Consumption* 700mA Humidity 95% (Non condensing) Reader output Voltage CABLE REQUIREMENTS EXT BUS 22 - 16 AWG (≤1m) * This is the consumption of the CUC1B0 and CUCEB122 series, Inputs AWG24 installer must calculate the power supply needed.
- Page 9 INSTALLATION GUIDE | BLUEnet Door Controller Applies to CUC1B0 model only! S’applique uniquement au modèle CUC1B0 SALTO BLUEnet CHARACTERISTICS SALTO BLUEnet CARACTÉRISTIQUES Frecuency Range 2400 MHz to 2483.5 MHz Gamme de fréquences 2400 MHz to 2483.5 MHz Norme Bluetooth 5.2 Standard Bluetooth 5.2...
- Page 10 Installation guide INSTALLATION GUIDE | BLUEnet Door Controller BLUEnet Door Controller Installation example: Ejemplo de instalación: Installationsbeispiel: Exemple d’installation: Exemplo de instalação: 安安安安 Optional Opcional Wahlfach Optionnelle Opcional Model: CUC1B0 件选 SP224895 Clear Rojo Rojo Touge Vermelho Rouge 红 色 Vermelho SP224895 Minimum distance between readers 20 in (50 cm)
- Page 11 INSTALLATION GUIDE | BLUEnet Door Controller Installation example with power supply on the left: Black Negro Schwarz Noir Negro Ejemplo de instalación con fuente de alimentación a la izquierda: Rojo Rouge Vermelho Installationsbeispiel mit Netzteil links: Blue Azul Blau Bleue Azul Exemple d’installation avec l’alimentation à...
- Page 12 INSTALLATION GUIDE | BLUEnet Door Controller Signalling Señalización Signalisierung Signalisation 壁安指 Sinalizaçao LED 状态 LED STATUS CUC1B0 CUCEB122 CUCEB004 CUC1B0 CUCEB122 CUCEB004 无电源 No power 不亮 所有内部通信已建立并正常工作（串行总线所有人 All internal communications established and working correctly 绿色常亮 SOLID GREEN WR） (serial Bus owner WRs) 启...
