Summary of Contents for Norden EYENOR ENJ-P0301Q

  • Page 2: Packing List

    Preface Thank you for purchasing our products, and if any questions or needs, please contact us.This product is specially for multi-IP PTZ dome cameras realize unified control and R&D(Research and developed) IP keyboard controller in the same (LAN) .This equipment adopts ONVIF protocol to starting communication, connection, and control etc operation which application in most of this industry.
  • Page 3 catalog 1. Product Overview 1.1 Description 1.2 Product Feature 1.3 Connection Diagram 1.4 Technical Specifications 2. Installation and Setting 2.1 Connection and landing 2.2 Search and add 2.3 Query and Control 3. Web Configuration 3.1 Home page 3.2 LAN Setting 3.3 User Management 3.4 Upgrade 3.5 Factory Reset...

  • Page 4: Product Overview

    1. Product Overview 1.1 Description The network keyboard Adopt industrial grade LCD modules, have better display. Support Onvif protocol, good Compatibility, high Scalability, built-in web server,which made the configuration interface concise, easy to use, and easy to control the IP camera. 1.2 Product Features Support ONVIF protocol Support offline search and add equipment...

  • Page 5: Installation And Setting

    1.4 Technical Specifications 2. Installation and Setting 2.1 Connection and landing Connect the keyboard with the power supply, and the network cable. When the keyboard start up,the screen displays local IP 192.168.x.xxx, enter the IP address into the browser and you can enter the page The default user name: admin; Password is empty.

  • Page 6: Web Configuration

    2.3 Query and Control 1. By pressing the "Search" button to view the added equipment. 2. By pressing the "Enter" button to select the corresponding device. 3. When the screen display "Destination IP:192.168.x.xxx", indicate the successful connection.Then you can operate such as controlling PTZ, zoom and so on.

  • Page 7: Lan Setting

    5. Click the "Search" button to search in LAN, it will be displayed automatically in the green box after the search completed. 6. Select the device you want to add in the search list, then click the "Add" button By pressing "Ctrl" to multiple choice. 7.

  • Page 8: User Management

    3.3 User Management The defaulted account of keyboard is super admin, we suggest user add new admin account, and user can set up more accounts for easier management. Super administrator: defaulted account, they can get all the permission authority, revise and delete account. Administrator: Non-defaulted account, they can get almost part of permission authority, revise and configure device including all pages parameter, but they are not authorized to delete super administrator.

  • Page 9: Factory Reset

    3.5 Factory Reset In case any improper setting or configuration wrongly operated, Select factory reset function to ensure the normal working again. Be careful of it! 3.6 Restart After long time working, Select restart function to ensure the device get the proper maintenance. 4.
