Outdoor Thermographic Telescope
User manual
Dongguan Xintai Instrument Co.,Ltd.
Add: Building F, No. 13-16, Hongye Industrial Zone, Tangxia
community, Tangxia Town, Dongguan City
Postcode:523710
Tel:+86-769-82612006
Fax:+86-769-82612005
Website:www.hti-meter.com
https://hti-instrument.com www.xintest.en.alibaba.com
User Manual Version 1.0. November 20，2020.
HT-C7
Advertisement
Table of Contents
Summary of Contents for HTI HT-C7
- Page 1 Outdoor Thermographic Telescope User manual Dongguan Xintai Instrument Co.,Ltd. Add: Building F, No. 13-16, Hongye Industrial Zone, Tangxia community, Tangxia Town, Dongguan City Postcode:523710 Tel:+86-769-82612006 Fax:+86-769-82612005 Website:www.hti-meter.com https://hti-instrument.com www.xintest.en.alibaba.com User Manual Version 1.0. November 20，2020. HT-C7...
-
Page 2: Table Of Contents
Table of Contents Summary HT-C7 Outdoor Thermographic Telescope takes advanced un-cooling focal plane infrared detector and high quality optical lens Summary as the core, and is combined with the convenient and fast operating Cautions and Safe Maintenance system. It has small shape design with perfect functional expansion spare parts and long service life. -
Page 3: Cautions And Safe Maintenance
Cautions and Safe Maintenance Performance Indicators ● To ensure the proper use of this product, please read the Detector type Un-cooled focal plane Resolution 384x288 infrared focal plane instructions carefully. LCD resolution 480x360 ● Do not use this product in flammable, explosive, humid or Focal length 25mm/35mm/75mm focal lengths optional Eyepiece... -
Page 4: Product Structure
Product Structure Description of Buttons The 5-way switch contains 5 buttons. The figure below is the diagram of button functions: 5-way switch (including 5 buttons inside) Display screen Battery compartment Fixing base (Type-C interface) Infrared thermal image sensor ①Photograph button Zoom lens ②Color palette button ③Brightness control button... -
Page 5: Description Of Operation
Description of Operation Press the brightness adjustment button to move down; Press the zoom in/out button to move to the left; ● Power on/off: Long press the power button for power on or off. Press the Palette button to move to the right; ●... -
Page 6: Description Of Battery Installation
3. After they are fully charged, disconnect power supply for the chargers, and remove the batteries. USB interface LED Indicator light Battery case Zoom Application Contact of the positive electrode When a photo of a far distance object is taken, the zoom function Contact of the can be used so as to view the object clearly. -
Page 7: Product After-Sale Service
4. Damage caused by natural disasters (earthquake, flood and lightning stroke) and external disasters; 5. Exceed the warranty period. Considerations: 1. If the product malfunction, repair or replacement with new or good product is made according to the condition after the product Rainbow Hot metal is inspected.
