- Page 1 79610 VACUUM CLEANER INSTRUCTION MANUAL 220-240V~50/60HZ, 3000W, 80L SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
-
Page 2: Important Safety Instructions
22. Maintain labels and nameplates on the appliance. These carry important safety information. If unreadable or missing, contact TOLSEN Tools for a replacement. 23. People with pacemakers should consult their physician(s) before use. Electromagnetic fields in close proximity to heart pacemaker could cause pacemaker interference or pacemaker failure. -
Page 3: Servicing Of Double-Insulated Appliances
SAFETY Servicing of Double-insulated appliances A double-insulated appliance is marked with one or more of the following: The words "DOUBLE INSULA- TION" or "DOUBLE INSULATED" or the double insulation symbol (square within a square): In a double-insulated appliance, two systems of insulation are provided instead of grounding. No grounding means is provided on a double-insulated appliance, nor should a means for grounding be added to the appliance. -
Page 4: Specifications & Setup
SPECIFICATIONS & SETUP SPECIFICATIONS Electrical Rating 220-240V~50/60Hz Input power 3000W Tank Capacity SETUP - BEFORE USE: Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: turn the power Switch of the appliance off... -
Page 5: Components And Controls
SET UP Components and controls 1. Engine cover handle 2. Start/Stop Switches 3. Entry suction tube 4. Bidone waste/liquid collection 5. Base 6. Wheel shi handle 7. Cover / Motor Body 8. Hook for closing between lid and bin 9. Handle 10. - Page 6 SET UP Assembly 1. Pull Clips outward, then remove Power Head by its Handle. Power Head Handle Clip Clip 2. Remove contents from Tank, then turn Tank over and attach Swivel Casters with Screws. Screw 3.For dry vacuuming: Slide Filter over Filter Cage. Filter 4.
-
Page 7: Maintenance And Servicing
MAINTENANCE AND SERVICING Procedures not specifically explained in this manual must be performed only by a qualified technician. TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: turn the power Switch of the appliance off and unplug the appliance from its electrical outlet before performing any procedure in this section. TO PREVENT SERIOUS INJURY FROM APPLIANCE FAILURE: Do not use damaged equipment. -
Page 8: Parts List
PARTS LIST PARTS LIST Part name Part name Handbar screw 4x80 Cotton bag Handbar Clamps sets Switch Water out sets Top cover screw 4x65 Screw 4x12 Top cover screw 4x25 Side hand bar Top cover Hose frame Screw 4x18 M5x20 Cabel press board Screw 4x20 Cabel... - Page 9 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. TolsenWorld MADE IN CHINA...
