Installation instruction
GST – 0-10V
The GST - 0-10V is a wireless control module with 24VDC power supply for a 0-10V damper or valve
actuator. With a GST - 0-10V you can easily control (per zone) an individual damper actuator, 2-way or
6-way valve actuator. Two 0-10V signals are available, one output and one input. Output for the
controlled valve position and the input for the actual valve position. A wide range of HVAC applications
is supported like VAV end devices and control valves for heating and cooling coils.
Safety
•
Installation and service should be performed by qualified personnel only.
•
The electrical installation must be in conformance with the national legislation and relevant
standards.
•
The mains connection of the GST-0-10V must be provided with a fuse or circuit breaker.
•
Disconnect power at the source before installation, inspection or removal
•
Do not use the GST-0-10V if it is damaged.
•
The GST-0-10V is suitable for use at indoor locations (IP20 protection class). Mount the GST-0-10V in
an IP66 housing for use at outdoor locations.
•
Same ambient temperature range apply as stated in product sheet and product label. These
temperatures do not include provision for heating by radiation from the sun. Avoid exposure to
direct sunlight, select housing and location accordingly.
•
The GST-0-10V is double insulated (protection class II).
•
The GST-0-10V terminals are isolated (SELV).
Installation instruction GST-0-10V
V3 / 24-04-2025
1
Advertisement
Summary of Contents for Simac MYMESH GST-0-10V
- Page 1 Installation instruction GST – 0-10V The GST - 0-10V is a wireless control module with 24VDC power supply for a 0-10V damper or valve actuator. With a GST - 0-10V you can easily control (per zone) an individual damper actuator, 2-way or 6-way valve actuator.
- Page 2 Application Refer to the GST-0-10V product sheet (see mymesh.nl) for the environmental conditions. Dimensions Mounting The GST-0-10V is provided with an internal antenna, which is located at the bottom of the housing. Since it is used for wireless communication with other Mymesh products it is important that operation of the antenna is not disturbed.
- Page 3 • Remove the securing clip straight up (e.g. with a screwdriver) to release the 230VAC cabling. Do not try to bend the securing clip. It might break. • Use 0.5-2.5 mm (AWG14-20) cable with flexible or solid kernel for the 0-10V connection, Maximum cable length is 3m •...
- Page 4 This product complies with the European directives and relevant standards for RED, REACH and RoHS. The Mymesh GST-0-10V is provided with a 2.4GHz radio. The applied frequency of the radio is within the band 2.401 – 2.482 GHz and the maximum transmit power is +4 dBm.
