Packaged Air Conditioners
Indoor unit
PKA-M·HA
PKA-M·HAL
PCA-M·KA
OPERATION MANUAL
For safe and correct use, please read this operation manual thoroughly before operating the air-conditioner unit.
BEDIENUNGSHANDBUCH
Zum sicheren und einwandfreien Gebrauch der Klimaanlage dieses Bedienungshandbuch vor Inbetriebnahme
gründlich durchlesen.
MANUEL D'UTILISATION
Pour une utilisation correcte sans risques, veuillez lire le manuel d'utilisation en entier avant de vous servir du
climatiseur.
BEDIENINGSHANDLEIDING
Voor een veilig en juist gebruik moet u deze bedieningshandleiding grondig doorlezen voordat u de
airconditioner gebruikt.
MANUAL DE INSTRUCCIONES
Lea este manual de instrucciones hasta el final antes de poner en marcha la unidad de aire acondicionado para
garantizar un uso seguro y correcto.
ISTRUZIONI DI FUNZIONAMENTO
Leggere attentamente questi istruzioni di funzionamento prima di avviare l'unità, per un uso corretto e sicuro della
stessa.
ΕΓΧΕΙΡΙΔΙΟ ΟΔΗΓΙΩΝ ΧΡΗΣΕΩΣ
Για ασφάλεια και σωστή χρήση, παρακαλείστε διαβάσετε προσεχτικά αυτό το εγχειρίδιο χρήσεως πριν θέσετε σε
λειτουργία τη μονάδα κλιματισμού.
MANUAL DE OPERAÇÃO
Para segurança e utilização correctas, leia atentamente o manual de operação antes de pôr a funcionar a
unidade de ar condicionado.
DRIFTSMANUAL
Læs venligst denne driftsmanual grundigt før airconditionanlægget betjenes af hensyn til sikker og korrekt brug.
DRIFTSMANUAL
Läs denna driftsmanual noga för säkert och korrekt bruk innan luftkonditioneringen används.
Işletme Elkitabı
Emniyetli ve doğru biçimde nasıl kullanılacağını öğrenmek için lütfen klima cihazını işletmeden önce bu elkitabını
dikkatle okuyunuz.
BRUKSANVISNING
Vennligst les nøye gjennom denne bruksanvisningen, for sikkert og riktig bruk av klimaanlegget.
INSTRUKCJA OBSŁUGI
Aby zapewnić bezpieczne i prawidłowe korzystanie z urządzenia, należy wcześniej uważnie przeczytać niniejszą
instrukcję obsługi.
FOR USER
FÜR BENUTZER
POUR L'UTILISATEUR
VOOR DE GEBRUIKER
PARA EL USUARIO
PER L'UTENTE
ΓΙΑ ΤΟΝ ΧΡΗΣΤΗ
PARA O UTILIZADOR
TIL BRUGER
FÖR ANVÄNDAREN
KULLANICI İÇİN
FOR BRUKER
INFORMACJA DLA UŻYTKOWNIKA İÇİN
English
Deutsch
Français
Nederlands
Español
Italiano
Ελληνικά
Português
Dansk
Svenska
Türkçe
Norsk
Polski
Advertisement
Table of Contents
Related Manuals for Mitsubishi Electric PKA-M HA Series
Summary of Contents for Mitsubishi Electric PKA-M HA Series
- Page 1 Packaged Air Conditioners Indoor unit PKA-M·HA PKA-M·HAL PCA-M·KA OPERATION MANUAL FOR USER English For safe and correct use, please read this operation manual thoroughly before operating the air-conditioner unit. BEDIENUNGSHANDBUCH FÜR BENUTZER Deutsch Zum sicheren und einwandfreien Gebrauch der Klimaanlage dieses Bedienungshandbuch vor Inbetriebnahme gründlich durchlesen.
-
Page 2: Table Of Contents
EC Article 20 Information for end-users and Annex II. Your MITSUBISHI ELECTRIC product is designed and manufactured with high quality materials and components which can be recycled and/or reused. This symbol means that electrical and electronic equipment, batteries and accumulators, at their end-of-life, should be disposed of separately from your household waste. -
Page 3: Parts Names
1. Safety Precautions Caution: Disposing of the unit • Do not use any sharp object to push the buttons, as this may damage When you need to dispose of the unit, consult your dealer. the remote controller. • Never block or cover the indoor or outdoor unit’s intakes or outlets. 2. - Page 4 2. Parts Names ■ Wired Remote Controller Controller interface The functions of the function buttons change depending on the screen. Refer to the button function guide that appears at the bottom of the LCD for the functions they serve on a given screen. When the system is centrally controlled, the button function guide that corresponds to the locked button will not appear.
- Page 5 2. Parts Names Display The main display can be displayed in two different modes: “Full” and “Basic”. The factory setting is “Full”. To switch to the “Basic” mode, change the setting on the Main display setting. (Refer to operation manual included with remote controller.) <Full mode>...
- Page 6 2. Parts Names ■ Wireless Remote-Controller [PKA-M·HAL only] Transmission area Transmission indicator Remote controller display Timer indicator * For explanation purposes, all of the items that appear in the display are shown. * All items are displayed when the Reset but- ton is pressed.
-
Page 7: Operation
3. Operation ■ About the operation method, refer to the operation manual that comes with each remote controller. 3.1. Turning ON/OFF [ON] [OFF] Press the [ON/OFF] button. Press the [ON/OFF] button again. The The ON/OFF lamp will light up in green, ON/OFF lamp will come off, and the and the operation will start. - Page 8 3. Operation 3.3. Temperature setting ■ Automatic fan speed setting (For wireless remote controller) It is necessary to set for wireless remote controller only when automatic <Cool, Dry, Heat, and Auto> fan speed is not set at default setting. It is not necessary to set for wired remote controller with automatic fan speed at default setting.
- Page 9 3. Operation 3.5.2 Vane·Vent. (Lossnay) <Navigating through the pages> <Accessing the menu> Main Main menu page Vane·Louver·Vent. (Lossnay) Press [F3] to go to the previous Select “Vane·Louver·Vent. (Loss- Main Main menu High power Vane·Louver·Vent. (Lossnay) Timer page. nay)” from the Main menu (refer to High power Weekly timer Press [F4] to go to the next...
-
Page 10: Timer
3. Operation 3.6. Ventilation Note: During swing operation, the directional indication on the screen ● For LOSSNAY combination ■ does not change in sync with the directional vanes on the unit. The following 2 patterns of operation is available. Available directions depend on the type of unit connected. ●... -
Page 11: Care And Cleaning
6. Care and Cleaning ■ Filter information When the is displayed on the will appear on the Main display Main display in the Full mode, the in the Full mode when it is time to Room clean the filters. system is centrally controlled and Room Cool Set temp. - Page 12 6. Care and Cleaning ■ PKA-M·HA(L) 1 Pull both the bottom corners of the intake grille to open the grille, then lift the filter. ■ PCA-M·KA 1 Open the intake grille. 2 Hold the knob on the filter then pull the filter up in the direction of an arrow.
-
Page 13: Trouble Shooting
7. Trouble Shooting Having trouble? Here is the solution. (Unit is operating normally.) ■ Clean the filter. (Airflow is reduced when the filter is dirty or clogged.) Air conditioner does not heat or cool well. ■ Check the temperature adjustment and adjust the set temperature. ■... -
Page 14: Specifications
7. Trouble Shooting Having trouble? Here is the solution. (Unit is operating normally.) ■ Draining water or motor rotation sound is heard. When cooling operation stops, the drain pump operates and then stops. Wait approximately 3 minutes. ■ Noise is louder than specifications. The indoor operation sound level is affected by the acoustics of the particular room as shown in the following table and will be higher than the noise specification, which was measured in anechoic room. - Page 15 Travellers Lane, Hatfield, Herts., AL10 8XB, England, U.K. Polish Branch Krakowska 50, PL-32-083 Balice, Poland MITSUBISHI ELECTRIC TURKEY ELEKTRİK ÜRÜNLERI A.Ş. Şerifali Mah. Kale Sok. No: 41 34775 Ümraniye, İstanbul / Turkey Please be sure to put the contact address/telephone number on this manual before handing it to the customer.
- Page 16 Related Links Model Number: PKA-M50HA Mr Slim Power Inverter Brochure - R32 PCA-M50-140KA Operation Manual PKA-M35-50HA Declaration of Conformity PKA-M35-50HA Installation Manual PKA-M35-50HA Operation Manual PKA-M35-50HA Parts List PKA-M35-50HA Service Manual (OCH660)
