Summary of Contents for World Chemical YD-200FS-12CSPW
- Page 1 Floating Oil Collecting System “Coolant Saver Portable Hybrid” YD-200FS-12CSPW YD-270FS-12CSPW Instruction manual Ver. 20231227...
-
Page 2: Table Of Contents
Preface Thank you very much for purchasing our floating oil collecting system “Coolant Saver Portable Hybrid”. This system is installed at coolant tanks, washing/waste tanks and various collection tanks, and two patterns of switching operation are possible. (1) Oil collecting (2) Slurry collecting. Operation can be selected according to the collection application. -
Page 3: Safety Precautions
This instruction manual intended standard specification systems. For special specification systems, replace the specifications with the corresponding items or words in the text when reading. Safety precautions This document classifies safety precautions into "Danger" and "Caution" as follows. Wrong handling may result in a dangerous state which Danger may cause death or severe injury. -
Page 4: Other Cautions
II. Prepare and operating precaution Danger (1) When operatig with high-temperature liquid, the flow path temperature of the collecting skimmer, pump, separator and hose rises near to the liquid temperature. Handle it carefully to avoid burn. The maximum temperature of collecting liquid is 50C or less. Caution (2) Stop the operation at time of emergency such as an earthquake or fire. -
Page 5: ２．Parts Name And Material
2. Parts name and material This product consists of a suction and a body as shown in the figure. The main body mainly consists of a separator, collecting pump, strainer unit, drain oil receiving tank, and operation board. Parts name and material Part name Material Part name... -
Page 6: ３．Specification
3. Specification Oil collecting Slurry collecting Model YD-270FS-12CSPW Capacity Oily water: 1-5 L/min. Slurry liquid: to 30 L/min. Operating Maximum 50 degrees temperature Body dimension 980W x 330D x 990H (mm) Weight Approx. 75 kg (Dry) Collection suction <Float type> <Nozzle type>... -
Page 7: ４．Suction Handling Instruction
4. Suction handling instructions <1. Oil collecting> Handling instructions of the collecting skimmer The collecting skimmer absorbs while keeping the water depth of the oily water inlet (Gate ring) constant and efficiently collects surface oil. Two types of 200FS and 270FS can be selected when ordering, depending on the amount of inflow and installation space. - Page 8 <2. Slurry collecting> Handling instructions of the collecting nozzle for slurry The nozzle has a shape as shown in the figure below so that it takes up slurry accumulated at the bottom of the collection tank. Firmly fix the handle and start operation. Be aware that if you let go of A release hole is provided so that water the handle while driving, it will...
-
Page 9: ５．Operation Preparation
5. Operation preparation To use the product safely, be sure to make the following preparations before operation. -
Page 10: ６．Operation Switching
6. Operation switching This product can be switch between two patterns of operation: (1) oil collecting and (2) slurry collecting and select the operation depending on use. To switch the operation, change the switch on the operation board and the hose shown below. The operation is switched by turning the two knobs. When collecting oil, set the knobs to the "OIL"... -
Page 11: ７．Operation
7. Operation Regarding oil or slurry collecting, there are differences in operating methods and routes. Two operations are explained. <1. Oil collecting> (1) Turn on the ON/OFF valve to start operation. (2) Adjust “Flow rate valve” on the operation board that collecting flow... - Page 12 (4) The discharged oil from the oil drain port of the separator passes through the collected oil drain valve and enters the 4L drain oil tank at the bottom. When approximately 3L of oil accumulates in the tank, the mechanical valve detects the weight and stops operation.
-
Page 13: ８．Store
It is possible to check the collected slurry through the window of the strainer. Window Before the strainer is full, remove slurry. At that time, remove foreign objects stuck to the mesh of the strainer. The foreign objects cause clogging during operation. When collecting oil, also the strainer should be treated as the same. -
Page 14: ９．Maintenance
9. Maintenance If large amount of slurry or solid foreign objects get mixed in collected oil, the performance is affected, so perform maintenance and inspection periodically or as necessary. When performing maintenance and inspection, make sure to observe the following precautions. Cut off the pump air supply to the device. - Page 15 Pump up during slurry operation. (3) Separator Accumulation of foreign objects such as Drain valve: slurry at the bottom of the separator inhibit close normal oil and water discharge. If there is the following signs, it may be due to accumulation, so please clean it.
-
Page 16: １０．Troubleshooting
10. Troubleshooting ＜ 1. Oil collecting ＞ Trouble Cause Measure Improper adjustment of Move the inlet of the collecting skimmer up and the skimmer. down to readjust the inflow of oily water. Decrease in pumped Check the pump and replace parts as water. - Page 17 ＜ 2. Slurry collecting ＞ Trouble Cause Measure Clogging of the tip of the Raise the attachment out of the water and attachment due to remove any foreign objects. foreign objects. Decreased in pumped Check the pump and replace parts as water.
-
Page 18: １１．Warranty, Repair
11. Warranty, Repair The warranty period and range (1) The warranty period is 12 months from the date dispatched from our factory. (2) During the warranty period, when pumps break down caused by our manufacturing detects even if they are used under the condition instructed in this manual, the failed parts are repaired free of charge. - Page 19 WORCHEMI TAIWAN CO., LTD. / Taichung, Taiwan No.915, Zhongshan Rd., Shengang Dist., Taichung City 42955, TAIWAN TEL 886-4-2562-8358 FAX 886-4-2562-8351 WORLD CHEMICAL USA, INC. / California, U.S.A. 25691 Atlantic Ocean Dr.Unit B-15 Lake Forest, CA 92630, U.S.A. TEL 1-949-462-0900 FAX 1-888-860-3364 SUZHOU WORLD TECHNOLOGY CO., LTD.
