Summary of Contents for LIW LeviCare Hoist Q140
- Page 1 Hoists LIW Care Technology liwcare.com...
- Page 2 Care System Levicare Q140...
-
Page 3: Main Product Features
Care System Levicare Q140 LeviCare Hoist Q140 PKLC-01 Main product features: • adjustable boom length; • various installation possibilities depending on the architectural conditions of the room; • possibility to adjust the hoist to small, restrictive areas; • maximum user weight 140 kg and 180 degrees turning capacity;... -
Page 4: Installation Options
The use of LeviCare Q140: The LeviCare Q140 is a versatile system which can be adapted to any room. Innovative way of installation allows to use one hoist with many bases. The device can be used as a transport, bath, toilet or pool hoist. Q140 hoists are a common solution to transfer in harbours or at the stables to enable the transfer of people to horses, kayaks, boats, sailboats or motorboats. -
Page 5: Electrical Specification
Fig.1 LeviCare Q140, side view Fig. 2 LeviCare Q140 top view Dimensions (Fig.1,2) 920 mm- 1340 mm R - Lifting arm / boom radius 36.2- 52.7 inch B - Overall height 735 mm/ 28.9 inch C - Rotation radius 0° – 180° D - The distance between the horizontal pivot and a wall 125 mm / 4.9 inch E - The distance between the vertical pivot and a wall... -
Page 6: Chassis Dimensions
Chassis LCQ140-R The chassis together with the battery power supply allows for the LeviCare Q140 hoist to be used as a mobile hoist. It consists of two detachable elements: a mast and the chassis. Attaching the Q140 hoist to a chassis is extremely simple and the high quality components of the chassis allow for easy transfer. - Page 7 Accessories Flat spreader bar Side spreader bar APLC-01 APLC-02 A standard flat (four-point) spreader bar for the hoist enables A side spreader bar (four-point) increases the comfort and the transfer of a disabled person in a sitting position. It can be flexibility of the lifted person, especially for obese people.
- Page 8 Finished projects Care System Levicare Q140...
- Page 9 Mobile hoists LeviCare mobile hoist J160/J190 J160/190-M/E The main advantages of a mobile hoist: • different versions of devices dedicated to different applications; • replaceable batteries; • wide lifting range, including the possibility of lifting from the floor level; • no interference in the structure of the building;...
-
Page 10: Electrical Data
Mobile hoist dimensions A – device height 1300 mm / 51.2 inch B – push handle height 850 – 1170 mm / 33.5 – 46 inch – range of operating depth (b. for lifting) 590 mm / 23.2 inch – range of operating depth (b. for upright positioning) 480 mm / 18.9 inch E –... - Page 11 LeviCare Mobile Hoist J160 Mini J160-M/E-MINI The LeviCare J160 Mini has all the advantages of the J160/190, but with the difference of its compact dimensions. Dedicated to users with limited living space. It is perfect for areas where limited space does not allow for free manoeuvring of a standard size hoist.
- Page 12 MOBILE HOIST DIMENSIONS A – device height 1170 mm / 46.0 inch B – push handle height 1060 mm / 41.7 inch – range of operating depth 470 mm / 18.5 inch – range of operating depth 460 mm / 18.1 inch E –...
- Page 13 Accessories Flat spreader bar Side spreader bar APLC-01 APLC-02 A standard flat (four-point) spreader bar for the hoist enables the transfer of a disabled person in a sitting position. It can be A side spreader bar (four-point) increases the comfort and used with any type of sling.
- Page 14 LeviCare Mobile Hoist Compact The LeviCare Compact is the newest mobile hoist. Similar in size to the J160 Mini, it is lighter in weight, has a reduced width, a wider legs spacing and a lithium-ion battery. The lithium-ion battery charges faster and has a longer service life.
- Page 15 Mobile hoists...
- Page 16 THIS MATERIAL PRESENTS MEDICAL DEVICES. PLEASE REFER TO THE USER MANUAL AND FOLLOW THE PROPER INSTRUCTIONS STATED IN THE USER MANUAL AND THE LABELING INSTRUCTIONS. CONTACT DETAILS: Tomasz Chmielecki t.chmielecki@liwcare.pl tel. +48 505 06 88 44 Maciej Matwijczak m.matwijczak@liwcare.pl tel. +48 509 08 98 16...
