PRODUCT NAME: BW Clayton Trellis
ITEM NUMBER: AO146
ASSEMBLED DIMENSIONS : 84.88"H x 18.11" Square
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 11-15-2021
REQUIRED TOOLS:
Phillips Screwdriver
-Two person assembly suggested.
Ltr.
Qty.
Hardware/Components Included
A
4
B
4
C
4
D
8
4
E
F
1
1
G
Periodically dust with a soft, dry cloth.
Protect surfaces to prevent damage.
Do not use alcohol based cleaners or polishers.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
Long Screws
(M5 x 30mm)
Feet
Wood Dowel
(15 x 60mm)
Short Screws
(M4 x 15mm)
Metal Stakes
(M6 x 460m)
Top
Base
Cleaning and Care
MADE IN VIETNAM
Page 1 of 2
Advertisement
Summary of Contents for Ballard Designs BUNNY WILLIAMS Clayton Trellis AO146
- Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: BW Clayton Trellis ITEM NUMBER: AO146 ASSEMBLED DIMENSIONS : 84.88”H x 18.11” Square REQUIRED TOOLS: Phillips Screwdriver -Two person assembly suggested. Ltr. Qty. Hardware/Components Included Long Screws (M5 x 30mm) Feet Wood Dowel (15 x 60mm) Short Screws (M4 x 15mm)
- Page 2 Assemble in location for intended use. ASSEMBLY: 1. Attach Feet (B) to each corner post on Base (G) using Long Screws (A). 2. Set Base upright and insert a Wood Dowel (C) into top of each corner post then secure using a Short Screw (D). 3.
