Olfer CBU-2RL-2P Instruction Manual

CBU-2RL-2P
Instructions manual
CBU-2RL-2P
Instructions manual
Read this manual before installation.
Keep this manual for future reference.
WARNING: Risk of electrical shock, personal injury or death.
This device may only be installed and put into operation by qualified personnel.
Check the information of the devices to be controlled to see if they are compatible.
This device is designed for use in lighting and industrial control.
Do not use this device in equipment where malfunction may cause severe personal injury or threaten human life.
Turn power off before installing the device.
Respect national and applicable installation regulations.
If damage or malfunction should occur during operation, immediately turn power off and send device to the factory for
inspection. Do not open, modify or repair the device. The device does not contain serviceable parts.
Description
CBU-2RL-2P is a Casambi relay for controlling non-dimmable loads. CBU-2RL-2P device uses Bluetooth Low Energy
communication to receive a command signal from the Casambi app and control the power supply to the connected
loads through the internal relays according to the selected fixture profile.
CBU-2RL-2P has a two switched live outputs of up to 5A each and allows control of loads powered by AC or DC (24V)
through its two different power supply modes.
There are several Casambi fixture profiles available for CBU-2RL-2P, which include different control modes: Toggle,
Independent Toggle, Press, Pulse...
CBU-2RL-2P also integrates two independent push button inputs for controlling Casambi devices.
Configuration and control can be done from a mobile phone or tablet using the free CASAMBI APP (available for iOS
and Android).
To access all user guides and documents, consult below link or scan QR code:
https://www.olfer.com/olfer-cbu-2rl-2p.html
OLFER EN-V1.0 20 March 2025 1
