Setech YD-10S User Manual

Hide thumbs

Advertisement

Table of Contents

SETech
User's Manual
SETech
347-5,Shindang-Dong, Dalseo-gu, Daegu.
TEL : +82-53-585-5261(Main)
FAX : +82-53-585-7848
http://www.setech.co.kr
e-mail : setech@setech.co.kr
YD-10S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YD-10S and is the answer not in the manual?

Questions and answers

Summary of Contents for Setech YD-10S

  • Page 1 SETech YD-10S User's Manual SETech 347-5,Shindang-Dong, Dalseo-gu, Daegu. TEL : +82-53-585-5261(Main) FAX : +82-53-585-7848 http://www.setech.co.kr e-mail : setech@setech.co.kr...

  • Page 2: Front Panel

    1. Outline. This manual is referred to the function and features of Model YD-10S Indicator so that you may use it with comportable and exact. 2. Features. 2-1. Data Hold and Peak Hold function. 2-2. ONE TOUCH DISPLAY AUTO ZERO function.
  • Page 3 ⓓ Program(PRG) : The key that can both change program modes and can confirm setting value. ⓔ The key that can change mumbers on each items. (0,1,2,3,4,5,6,7,8,9) ▲ ▲ ⓕ The key that can shift decimal point. (Possible to shift decimal point ▶...

  • Page 4: Dip Switch

    5. Back Panel ㉣ ㉤ ㉥ ㉦ ㉧ Must be connected ㉨ ㉠ ㉡ ㉢ (Standard Model) ㉠ SENSOR connection terminal. ㉡ Analog output terminal. ㉢ AC Input terminal. (Standard : 220v, option : 110v) ㉣ RELAY number 1 output terminal. ㉤...
  • Page 5 ( Terminal table Option Dimension. ) Must be connected (Standard model ) Must be connect (OPTION RELAY 8CH) Must be connecte (OPTION : BCD ) Must be connected...

  • Page 6: Cal Mode

    ( DISPLAY ONLY ) 6. PROGRAM Input Main ☞ The number of pressing Key is intial condition. In case of transferring the follow order on consecutive program, you just press Key one time.  In addition to store input value, you must press Key.
  • Page 7 Power is OFF.) Press PRG key 5times to enter RY1H mode as shown in left 0300.0 after RY1H is illuminated. At this time, you can input HI value on Relay number 1 you want to. Press PRG key 6times to enter RY1L mode as shown in left after RY1L is illuminated.
  • Page 8 r-R mode.) Press PRG key 12times to enter Display Speed setting mode d-10 as shown left. After you select value with ▲ key and you press ENT key. Main ☞ Standard setting is Max 15 time/sec. If you want to set 20time/sec please contact the Manufacture company.
  • Page 9 Press PRG key 16times to enter display step setting as shown in St001 left and operate ▲(2) key to change value. Main ☞ Possibility to set value from 0 to 255. Indicatingvalue is changed based on value set on Indicator. For example, in case value set on Indicator is 5, Indication is changed 5, 10, 15, 20…...

  • Page 10: Serial Communication Protocol

    8. SERIAL COMMUNICATION PROTOCOL. the below describe an example on the setting for communication between an indicator and a PC assuming that current display is 32.567 and the ID of indicator is 005. 1) Transfer the current display - Host(PC) Byte1 (indicator ID) Byte 2 (the command of sending data) R(52H)
  • Page 11 protocol version 1.0 Send Protocol : ID'R' Receive Protocol : STX[0x02] ID SIGN['+','-'] DATA ETX[0x03] For example ) When ID is 049 and current value is +12.345 Send Protocol : "IR" Receive Protocol : "[┏1+12.345┛] Make Send Protocol temp_id = StroToint[Edt_ID->Text]: sprint[temp_buf,"%cR"...

  • Page 12: Troubleshooting

    9. Trouble Shooting. Problem Cause Correction. 1). Defective sensors 1) Check sensor output 2). Wrong Connection 2) Check connection to sensor Display drifts 3). CABLE NOISE 3) Check power line & ground 4). Incorrect Filter Set. 4) Check filter Dip Switches. Programming again, after waiting Display CAL and Program erased...
  • Page 13 13. The way to change Power Supply. ( Refer to belowing picture) VOLTAGE SELECTOR Termi front Trans Main ☞ If you take out 2pcs painted black with hand, Voltage is indicated on Panel. And then, you move them as follwing pictures. 220V 110V...
  • Page 14 (option model pin connector pinmap) Relay 8CH Relay (NG output) binary Remark 37Pin 40Pin 0 digit RY1 High NG RY1 Low NG RY2 High NG RY2 Low NG 1 digit RY3 High NG RY3 Low NG RY4 High NG RY4 Low NG 2 digit RY5 High NG RY5 Low NG...
  • Page 15 (relay r-r mode/r-h mode Explanation) (r-h MODE set) Ry1H. ON Ry1L. ON (relay set explanation) (r-r set) Upper Hi value is On. Below LOW value is On...
  • Page 16 # OPTION (RS-232C, RS-485). The RS-232C and RS-485 are for general communication and used when receiving data from the PC. 1. Instruction : Set the board rate form the setting-up modes to use the RS-232C (RS-485). The board rate can be fixed in the range of 1200, 2400, 4800, 9600, 14400, 19200, 28800, 38400, 57600, 11520 bps.
  • Page 17 0 x 35 0 x 37 0 x 03 O : OK (0x4F)
