ELECTRIC PLANER

INSTRUCTION MANUAL

SAVE THIS MANUAL !

You will need this manual for safety instructions, operating procedures and warranty.

Put it and the original sales receipt in a safe dry place for future reference.

230V-240V~50Hz

900W

Table of Contents

Need help?

Do you have a question about the FORCE XPRESS 79535 and is the answer not in the manual?

Questions and answers

Summary of Contents for TOLSEN TOOLS FORCE XPRESS 79535

Page 1 79535 ELECTRIC PLANER INSTRUCTION MANUAL 230V-240V~50Hz 900W SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
Page 2: Important Safety Information
SAFETY IMPORTANT SAFETY INFORMATION General Power Tool Safety Warnings Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, ﬁre and/or serious injury. Save all warnings and instructions for future reference. The term ″power tool″ in the warnings refers to your mains-operated (corded) power tool.
Page 3: Planer Safety Warnings
11. Maintain labels and nameplates on the tool. These carry important safety information. If unreadable or missing, contact TOLSEN Tools for a replacement. 12. Avoid unintentional starting. Prepare to begin work before turning on the tool. 13. Do not lay the tool down until it has come to a complete stop. Moving parts can grab the surface and pull the tool out of your control.
Page 4: Vibration Safety
SAFETY AND SYMBOLOGY Vibration Safety 1. Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. 2. Do not use the power tool if the Trigger does not turn it on and oﬀ. Any power tool that cannot be controlled with the Trigger is dangerous and must be repaired.
Page 5: Safety Specifications
SPECIFICATIONS SAFETY SAFETY SAFETY SAFETY SAFETY SAFETY SAFETY SAFETY SPECIFICATIONS SPECIFICATIONS Electrical Requirements 230-240VAC / 50Hz / 900W No load Speed : 16000/min Planing width 82mm Planing depth 0-3mm Rabbet depth 0-15.5mm...
Page 6 SETUP SPECIFICATIONS SETUP - BEFORE USE Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Functions Safety button Trigger Main handle Depth adjustment knob Rabbet depth guide...
Page 7 SETUP Operating Instructions Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Tool Set Up TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Make sure that the Trigger is in the oﬀ-position and unplug the tool from its electrical outlet before performing any procedure in this section.
Page 8: Depth Adjustment
SETUP SAFETY SAFETY SAFETY SAFETY SAFETY SAFETY SAFETY SAFETY 11. Insert the entire Knife Holder assembly all the way into the slot in the Drum with the Bolt heads facing the Adjustable Base Plate. Install it in the same orientation as earlier and in the same orientation as the other knife.
Page 9: Attaching The Dust Bag
SETUP Attaching the Dust Bag Slip the open end of the Dust Bag around the open end of the Dust Chute . Note: You can install the Dust Bag on either side of the Planer: 1. If installed, remove the Dust Bag from the Dust Chute. 2.
Page 10 SETUP Rabbeting Rabbeting is creating a step on the edge of a workpiece. Rabbeting is typically used in door and window jambs. When rabbeting, the Rabbet Depth Gauge will contact the unplaned portion of the workpiece and help prevent planing too deeply. 1.
Page 11: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Problem Possible Causes Likely Solutions Tool will 1. Cord not connected. 1. Check that cord is plugged in. not start 2. No power at outlet. 2. Check power at outlet. If outlet is unpowered, 3. Tool’s thermal reset breaker turn oﬀ...
Page 12: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product ELECTRIC PLANER 230-240V~ 50Hz, 900W Serial number: N/A Complies with the essential health and safety requirements of the following Directices: EC Machinery Directive 2006/42/EC The EMC Directive 2014/30/EU Standards and technical speciﬁcations referred to:...
