EMPERO EMP.70.80.01 Manual

Refrigerated cabinets
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
REFRIGERATED CABINETS
Kasap Tip Dik Buzdolapları
CONTENTS
Page
2
Page
3
Page
3
Page
4
Page
4
Page
4
Page
5
Page
6
Page
7
Page
8
Page
9
Page
15
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EMP.70.80.01 and is the answer not in the manual?

Questions and answers

Related Manuals for EMPERO EMP.70.80.01

Summary of Contents for EMPERO EMP.70.80.01

  • Page 1: Table Of Contents

    REFRIGERATED CABINETS Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page...

  • Page 2: Ageneral Information

    REFRIGERATED CABINETS Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty.

  • Page 3: A1 Product Description

    Kasap Tip Dik Buzdolapları PRODUCT DESCRIPTION *The Professional Refrigerated Cabinets ,that provides high efficiency has been designed to be used in industrial kitchen. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.70.80.01 700x800x2050 750x900x2170 EMP.140.80.01 1400x800x2050 1460x940x2170 TECHNICAL INFORMATION Product Code EMP.70.80.01 EMP.140.80.01...

  • Page 4: A3 Transportation

    REFRIGERATED CABINETS TRANSPORTATION Kasap Tip Dik Buzdolapları *This appliance can not be moved by hand from area to area.It must be moved on pallet with forklift truck. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol.

  • Page 5: Csafety Instructions

    REFRIGERATED CABINETS Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. ...

  • Page 6: Doperation

    REFRIGERATED CABINETS OPERATION Kasap Tip Dik Buzdolapları *Control Panel; A : Degree increase B : Degree reduce C : Indicator ON/OFF D : SET approval button *Operating; • Clean the inner and outer surface of the appliance with warm cloth before first use.Then clean with wet cloth and dry.

  • Page 7: Ecleaning & Maintenance

    REFRIGERATED CABINETS Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE ➢ CLEANING AND MAINTENANCE AFTER EVERY USE • Always turn off the appliance and disconnect from the power supply before cleaning. • Clean the inner surfaces and shelves with moist cloth and then dry after every evacuation of material.

  • Page 8: Ftroubleshooting

    REFRIGERATED CABINETS TROUBLESHOOTING Kasap Tip Dik Buzdolapları Check if the appliance is plugged in. Check the electrical connections and THE APPLIANCE DOESN’T OPERATE voltage. Check if the fuse is on or off. Check the motor. THE APPLIANCE IS NOISY If the connection pipes contact with compressor,remove it.

  • Page 9: Gspare Part List- Exploding Drawing

    REFRIGERATED CABINETS Kasap Tip Dik Buzdolapları SPARE PART LIST- EXPLODING DRAWINGS EMP.70.80.01...
  • Page 10 REFRIGERATED CABINETS SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE : EMP.70.80.01 Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE CONDENSER POSITIVE (+) M.SOG-KDS-032 WING M.ELK-HVL-FKN-002 FAN CIRCLE WIRE ERK.M.MUH-001 FAN MOTOR M.ELK-MTR-FMT-014 COMPRESSOR M.SOG-KMS-022 FAN PLASTIC M.PLS-ERK-016 WING M.ELK-HVL-FKN-004 SIDE styrofoam...
  • Page 11 REFRIGERATED CABINETS Kasap Tip Dik Buzdolapları BOTTOM LEFT HINGE SHEET M.AKS-MNT-SC-002 GASKET(580*1446,5) M.CNT-ERK-052 HINGE TOP PLASTIC RIGHT M.ENJ-ERK-PLS-108 HAND PLASTIC TOP M.PLS-ERK-029 LOCK PLASTIC M.ENJ-ERK-PLS-131 COVER RIGHT ARA-ERK.DEPOKAPAK-430S HAND PLASTIC BOTTOM M.PLS-ERK-030 HINGE BOTTOM PLASTIC RIGHT M.ENJ-ERK-PLS-107 HINGE M.AKS-MNT-SC-006 PIPE M.ENJ-ERK-PLS-002 M.ENJ-ERK-PLS-024 FOOT...
  • Page 12 REFRIGERATED CABINETS SPARE PART LIST- EXPLODING DRAWINGS Kasap Tip Dik Buzdolapları EMP.140.80.01...
  • Page 13 REFRIGERATED CABINETS Kasap Tip Dik Buzdolapları SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE : EMP.140.80.01 PRODUCT NAME P.CODE INSULATION FOAM YIZ-ERK1480-MH-0001 EVAP POSITIVE M.SOG-EVP-036 FAN PLASTIC M.PLS-ERK-016 WING M.ELK-HVL-FKN-004 CONDENSER POSITIVE (+) M.SOG-KDS-032 COMPRESSOR M.SOG-KMS-022 WING M.ELK-HVL-FKN-002 FAN CIRCLE WIRE ERK.M.MUH-001 FAN MOTOR M.ELK-MTR-FMT-014...
  • Page 14 REFRIGERATED CABINETS HINGE BOTTOM PLASTIC LEFT M.ENJ-ERK-PLS-109 HAND PLASTIC BOTTOM M.PLS-ERK-030 HAND PLASTIC TOP M.PLS-ERK-029 Kasap Tip Dik Buzdolapları COVER RIGHT ARA-ERK.DEPOKAPAK-430S HINGE TOP PLASTIC RIGHT M.ENJ-ERK-PLS-108 GASKET(580*1446,5) M.CNT-ERK-052 HINGE BOTTOM PLASTIC RIGHT M.ENJ-ERK-PLS-107 HINGE M.AKS-MNT-SC-006 M.ENJ-ERK-PLS-024 PIPE M.ENJ-ERK-PLS-002 FOOT ERK.M.AKS-AYK-INX-001 53*65 WIRE SHELF M.RAF-ERK-031...

  • Page 15: Helectric Circuit Schema

    REFRIGERATED CABINETS Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA 70.80.01 M1 - COMPRESSOR ENGINE F1 - REFRIGERATOR INTERNAL COOLING FAN L1 - LAMP S1 - SWITCH PR1 - PROBE...
  • Page 16 REFRIGERATED CABINETS ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları 140.80.01 M1 - COMPRESSOR ENGINE F1 - REFRIGERATOR INTERNAL COOLING FAN L1 - LAMP S1 - SWITCH PR1 - PROBE...

This manual is also suitable for:

Emp.140.80.01
