SGS 41CM PETROL LAWNMOWER
SPL41SP125
OWNER'S MANUAL
FOR YOUR SAFETY
PLEASE READ THESE INSTRUCTIONS CAREFULLY
AND RETAIN THEM FOR FUTURE USE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPL41SP125 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SGS SPL41SP125

Summary of Contents for SGS SPL41SP125

  • Page 1 SGS 41CM PETROL LAWNMOWER SPL41SP125 OWNER’S MANUAL FOR YOUR SAFETY PLEASE READ THESE INSTRUCTIONS CAREFULLY AND RETAIN THEM FOR FUTURE USE.

  • Page 2: Warning Symbols

    Beware of sharp blades - remove the spark plug lead before maintenance. No naked flames. Appropriate ear, eye, and head protection (PPE) must be worn. Add engine oil. Only refuel with unleaded petrol. Hot surfaces will burn the hands! WWW.SGS-ENGINEERING.COM PAGE 2...
  • Page 3 Warning! The lawn mowers exhaust gas contains toxic substances. Do not run the engine in closed or poorly ventilated areas. The blade continues to rotate for a period after the lawn mower is switched off. Do not touch the blade until all the lawn mower components have stopped completely.

  • Page 4: Safety Warnings

    Inspect all the parts for signs of damage. Do not assemble the lawn mower if you observe any damaged components. NOTE: This lawn mower complies with the Noise Emission Directive 2000/14/EC. WWW.SGS-ENGINEERING.COM PAGE 4...

  • Page 5: General Safety

    GENERAL SAFETY 1. Keep this operating and maintenance manual in a safe place for future reference. 2. Read the instructions carefully. Be familiar with the controls and the proper use of the equipment. 3. Never allow children or people unfamiliar with these instructions to use the lawn mower.

  • Page 6: Operation Safety

    4. Always be sure of your footing on slopes. 5. Walk, never run. 6. Mow across the face of a slope, never up and down. 7. Exercise extreme caution when changing direction on slopes. 8. Do not mow steep slopes excessively. WWW.SGS-ENGINEERING.COM PAGE 6...
  • Page 7 9. Use extreme caution when reversing or pulling the lawn mower towards you. 10. Stop the blade if the lawn mower has to be tilted for transportation when crossing surfaces other than grass, and when transporting the lawn mower to and from the area to be mowed.

  • Page 8: Intended Use

    This lawn mower is designed for domestic lawn mowing only. Use in any other way is considered contrary to the intended use. Compliance with the operation, service and repair, as specified in this manual, also constitutes essential elements of the intended use. WWW.SGS-ENGINEERING.COM PAGE 8...

  • Page 9: General View

    GENERAL VIEW In the box: A. Main mower deck (with upper handle attached) Lower handle C. Grass collection bag D. Handle tensioning clip x 2 Cable clip Handle fixing bolts x 4 (fitted on deck) G. Spanner H. Spark plug wrench Manual You will also need(not supplied): SAE 30 or 4-stroke oil...
  • Page 10 5. Grass collection bag 6. Lower handle 7. Safety flap 8. Height adjustment handle 9. Wheel 10. Engine 11. Steel deck 12. Handle fixing bolts x 4 (fitted on deck) 13. Cable clips x 1 14. Rope guide WWW.SGS-ENGINEERING.COM PAGE 10...

  • Page 11: Technical Specifications

    TECHNICAL SPECIFICATIONS Model No. XSZ41D Engine type Single cylinder 4-stroke Engine displacement 125cm Engine power 1.8kW/ 3000/min Max. engine speed 3000/min Cutting width 41cm Grass bag capacity Ignition T.C.I Fuel tank capacity 0.8L Oil tank capacity 0.47L A-weighted emission sound pressure level 81.9 dB(A), K=3dB(A) A-weighted sound power level 92.6 dB(A), K=3dB(A)
  • Page 12 Fix the lower handle firmly onto the deck, using the handle fixing bolts (F) and spanner (G) supplied. Assembly the upper handle Lift the upper handle and lock it in place using the handle tension clips (D). Ensure the lower and upper handles are firmly connected. WWW.SGS-ENGINEERING.COM PAGE 12...
  • Page 13 When you stand behind the mower, ensure the rope guide is on the right side. Engage the brake lever and pull the start cord to hang it on the rope guide. Assembly the grass bag IMPORTANT! Make sure the grass collection bag is in place before starting the engine.
  • Page 14 Raise the safety flap and hook the collection bag onto the mower. Release the safety flap. Attach the clips Ensure that the cable clips (E) supplied are used to fix the cable to the lower handle. WWW.SGS-ENGINEERING.COM PAGE 14...

  • Page 15: Operation

    OPERATION STOP! Do not start the engine before putting 470ml of SAE 30 oil into the engine. Failure to do so will result in irreparable damage to the engine and invalidate your warranty. Filling with engine oil IMPORTANT! The following procedures and adjustments must be performed before the engine is started.

  • Page 16: Filling With Engine Fuel

    Clean up any overflow or splashes of petrol before starting the engine. Tighten the filler cap after filling, finger tight only. NOTE: The 41cm push lawn mower has a maximum fuel capacity of 800ml. WWW.SGS-ENGINEERING.COM PAGE 16...

  • Page 17: Setting The Cutting Height

    Setting the cutting height WARNING! The blade can cause serious injury. Before adjusting the mower height, stop the engine and wait for the mower blade to come to a complete stop. Pull the lever towards the wheel, then move it forward or backward to adjust the cutting height.
  • Page 18 NOTE: When starting a warm engine, the primer does not need to be used. If the engine stops due to a lack of petrol, refill and press down the primer 3-5 times. 1. Start/stop bar activation Pull the start/stop bar towards you. WWW.SGS-ENGINEERING.COM PAGE 18...

  • Page 19: Failure To Start

    2. Pull cord handle With your right hand, slowly but firmly pull the starter handle and rope from the pull cord guide until you feel resistance, then pull briskly. If the engine fails to start after three pulls, repeat the start process. When the engine starts, return the starter rope to the pull cord guide gently.

  • Page 20: Empty The Grass Bag

    Store the lawn mower on a flat and level surface, with all 4 wheels on the ground. Store in a dry, safe place which is not accessible to children or people who are not familiar with operation. WWW.SGS-ENGINEERING.COM PAGE 20...

  • Page 21: Maintenance And Storage

    MAINTENANCE AND STORAGE Storing the lawn mower for extended periods CAUTION! Do not empty the petrol tank in enclosed areas, near fire or when smoking. Petrol fumes can cause explosions and fire. Always carry the product on its gripping surfaces. If the lawn mower is to be placed into storage at the end of the season, or if the mower is not to be used for a longer period than 6 weeks, storage maintenance must be performed, as follows:...

  • Page 22: Cleaning Or Replacing The Air Filter

    To loosen debris, gently tap the filter on a hard surface. If the filter is excessively dirty, replace with a new filter. Install the air filter. Install the cover tabs (D) into the slots (E). Close the cover and secure with the fastener (A). WWW.SGS-ENGINEERING.COM PAGE 22...

  • Page 23: Changing The Oil

    Cleaning or replacing the spark plug Once the engine has cooled, pull off the spark plug boot with a twist. Remove the spark plug using the socket spanner supplied. Clean the plug with a wire brush. Using a feeler gauge, set the gap to 0.51mm. Install the spark plug carefully by hand to avoid cross-threading.

  • Page 24: Replacing The Cutting Blade

    Check the washer is still slightly domed to keep the pressure on the bolt to stop it unwinding, keeping the blade firmly secure. Then replace the washer (right way around!) and bolts. Make sure the blade is correctly located, and then firmly tighten the bolt. Use a torque WWW.SGS-ENGINEERING.COM PAGE 24...
  • Page 25 wrench to tighten the blade bolt by 40 N∙m Do not over tighten. The upturn of the blade must project into the motor compartment. NOTE: If you are unsure about performing this operation, call our helpline or go to an authorised dealer to change the blade for you.

  • Page 26: Troubleshooting Chart

    Blade is blunt Sharpen the blade Cutting height is too Set correct height Unsatisfactory grass Cutting height is too Set correct height collection Replace the blade Blade is worn Clear any clogged grass Grass bag is clogged debris WWW.SGS-ENGINEERING.COM PAGE 26...

  • Page 27: Parts Diagram

    PARTS DIAGRAM PAGE 27...
  • Page 28 69 165mm front wheel 908659 V Belt with teeth 908624 70 165mm front wheel cap 908660 Belt cover 908625 71 Wrench 908661 Bolts M6x12 908626 72 Spark plug socket wrench 908662 WWW.SGS-ENGINEERING.COM PAGE 28 CALL FOR ASSISTANCE: 01332 576 850...
  • Page 29 PARTS DIAGRAM PAGE 29...
  • Page 30 SETS PARTS DIAGRAM Qty Code No Description Qty Code No Description A01 Cable sets assembly 908663 A05 Blade assembly 908667 A02 Rear flap assembly 908664 A06 Grass catcher assembly 908668 A03 Connection assembly 908665 A07 Wheel assembly 908669 A04 Gear box assembly 908666 PAGE 30...
  • Page 31 SGS Engineering (UK) Ltd Unit 1 West Side Park Raynesway Derby, DE21 7AZ EC Declaration of Conformity This is an important document and should be retained MANUFACTURER’S NAME: SGS Engineering (UK) Ltd TYPE OF EQUIPMENT: 46cm petrol lawnmower PART NUMBER:...
