Summary of Contents for Alliance RV Avenue

  • Page 1 OWNER ' S GUIDE OBSESSED WITH PROVIDING THE BEST RV OWNERSHIP EXPERIENCE!
  • Page 2 WELCOME TO THE ALLIANCE RV FAMILY! Congratulations on the purchase of your new Alliance RV. We are honored that you have placed your trust in the Alliance RV Team, and it is our privilege to help you enjoy a great RV ownership experience! One of the best ways to begin enjoying your Alliance RV experience is by taking time to read and familiarize yourself with the contents of this owner’s manual along with the individual...
  • Page 3 MY INFO: Alliance RV Model (ie. Paradigm): ___________________________________________ Floorplan or Model # (ie. 370FB): _________________________________________ VIN (17 Digits): Dealership Name: ___________________________________________________ Dealership Address: ___________________________________________________ ___________________________________________________ ___________________________________________________ Dealer Phone: ___________________________________________________...

  • Page 4: Table Of Contents

    Unable to Complete Warranty Claim Within the Warranty Period ............9 Repair Remedy: Exclusive Remedy ......................9 Warranty Exclusions ..........................9 Events Discharging Alliance RV from Obligation Under Warranty ............10 Warranty Registrations ........................... 11 Care and Maintenance ..........................11 LEGAL REMEDIES .............................
  • Page 5 TOW VEHICLE: HITCH AND CONFIGURATION CONCERNS ................18 Hitch and Hitch Selection ........................18 Hitch Ball ..............................18 Hitch Weight ............................18 Hitch Height ............................19 Suspension .............................. 19 Sway Control (Customer Supplied) ......................19 Sway Control (Customer Supplied) ......................19 TIRE AND WHEEL INFORMATION &...
  • Page 6 Axle Bearing Inspection and Grease Repacking .................. 28 TOW PLUG ..............................29 Tow Plug Troubleshooting ........................29 Tow Plug Maintenance ........................... 29 Inspection ............................29 Wire Lug Torque ..........................30 SAFETY CHAINS ............................31 TOWING YOUR RV ............................32 Before and After Travel: Checklists ......................33 HITCH RECEIVER ............................
  • Page 7 Smoke & CO/Carbon Monoxide Alarm ....................60 LP & CO Alarm ............................. 61 PROPANE ..............................62 Traveling with Propane ........................... 63 Two Stage LP Regulator .......................... 63 External Appliance Quick Connect ......................65 Propane Cylinders ........................... 67 Filling Your Propane Cylinders ........................ 67 Cooking with Propane Gas ........................
  • Page 8 Adjusting Electric Slide-out “OUT” Position ..................80 Adjusting the Electric Slide-out Room Horizontally ................81 Adjusting the Electric Slide-out Room Vertically ................81 Synchronizing Electric Slide-out Room Travel ..................82 IN-WALL® ELECTRIC SLIDE-OUT SYSTEM (SCHWINTEK) (IF EQUIPPED) ............84 Operating Your In-Wall Slide-out System ....................84 Extending Your In-Wall Slide-out ......................
  • Page 9 BAL Accu-Slide Maintenance ........................96 Cable Adjustment Procedure ......................96 Stand-off Bracket Alignment ....................... 97 Manual Override ..........................98 ELECTRICAL: GENERAL ..........................99 Electrical System Overview ........................99 Electrical Troubleshooting ........................100 Removing All Power from the RV ......................101 Power Cord ............................
  • Page 10 Sleep Mode Wake Up Operation ...................... 115 Manual Backlight Disable ........................115 User Settings ............................. 116 Settings Available ..........................116 Preset Capacity and Voltage Setting ....................117 Set Capacity to Zero or Full ....................... 117 Capacity Calibration .......................... 117 Check and Reset the Actual Capacity ....................117 Renogy Battery Monitor Troubleshooting ....................
  • Page 11 INVERTER (IF EQUIPPED) ........................... 132 Overview ............................... 132 Intellitronix Energy Management System (If Equipped) ............... 132 Standard Programming ........................133 Using the Control Module ......................... 134 Intellitronix Maintenance ........................134 Inspection & Torque Check ....................... 135 Progressive Dynamics Inverter (If Equipped) ..................135 Operation ............................
  • Page 12 Go Power! Solar Charge Controller Maintenance ................156 Renogy Rover Solar Charge Controller, 20A or 40A (If Equipped) ............157 Overview ............................157 Main Display Screens / Operating the Unit ..................160 Programming ............................ 160 Renogy DC Home app (Bluetooth) ....................160 Lithium Battery Reactivation ......................
  • Page 13 Monitoring Operation via LED Indicators ..................179 Monitoring Operation via the VictronConnect app ................180 Programming Options ........................180 Victron Solar Charger Troubleshooting ....................181 Victron Solar Charger Maintenance ...................... 181 TV & STEREO ............................. 182 ALL TV ..............................182 Winegard TV Antenna ...........................
  • Page 14 Furrion Single Zone Thermostat (IF Equipped) ..................196 Identification ............................. 196 Operation ............................196 Modes Available ..........................197 Furrion Single Zone Thermostat Troubleshooting ................198 Furrion Air Conditioners (If Equipped) ....................198 Furrion AC Maintenance ........................199 Cleaning the AC Filter ........................199 AC Coil Cleaning ..........................
  • Page 15 Range Vent (Vent Hood) ........................210 Range/Cooktop ............................. 210 Before Using Your Range ........................210 PLUMBING AND UTILITIES ........................211 Centralized Docking Station ........................211 Docking Station Handle Position and Valve Routing ................212 Cable and Satellite Connection ......................213 Filling the Fresh Water Tank –...
  • Page 16 Toilet ..............................237 Operation ............................237 Dumping Your Waste Tanks ........................238 Waste Tank Pull Valve Maintenance ....................238 Monitoring Your Water Systems ......................239 Tank Heaters ............................240 Washer / Dryer Prep (If Equipped) ....................... 241 INTERIOR ..............................242 Window Blinds ............................

  • Page 18: Owner's Information Bag

    OWNER’S INFORMATION BAG You will find the manuals and registration cards for individual components in your Alliance RV Owner’s Information Bag. It is important that you take time to register and activate each component warranty according to the information and timelines provided. Doing so will help any potential delays in the event your RV requires warranty service.

  • Page 19: Owner Support Resources

    You can find all current links at https://jointhealliance.com/. It is worth noting that the Facebook page “Alliance RV Group” is a particularly focused point of contact that is monitored by not only many Alliance employees, but also several Owner Empowerment Ambassadors –...

  • Page 20: Alliance Academy

    Some of the available resources are: • Alliance RV Training: Over 4 hours of videos produced in partnership with the NRVTA covering RV Electricity, Propane Systems, Water Systems, Air Conditioning, Leveling Systems, and Slideouts. This also includes new owner walkthroughs of interior and exterior components! •...

  • Page 21: Vehicle Identification Number (Vin)

    VEHICLE IDENTIFICATION NUMBER (VIN) Alliance RV vehicles all have a unique 17-digit VIN. You will find your VIN listed on the Federal Certification label located toward the front of the RV on the off-door side. The following VIN decoder identifies each digit location and its function.

  • Page 22: Reporting Safety Defects

    To Contact NHTSA: Website: www.safecar.gov Address: NHTSA Headquarters Attn: Administrator 1200 New Jersey Avenue, SE Washington DC 20590 Toll Free Vehicle Safety Hotline: 888.327.4236 TTY: 800.424.9153 For additional information, please refer to the NHTSA website at www.safecar.gov. In Canada: If you believe that your recreational vehicle has a defect which could cause a crash or cause injury or death, you should immediately inform Transportation Canada’s Defect Investigations and Recalls...

  • Page 23: Service & Warranty

    Alliance RV, LLC (Alliance RV) provides the following Limited Base and Limited Structural Warranties with this recreational vehicle which sets forth what Alliance RV will cover and what Alliance RV will do if a defect is found to exist. Please read the following warranty details closely before your purchase of the recreational vehicle.
  • Page 24 Alliance RV reserves the right to make changes in the design or material of its products without obligation to incorporate such changes in any product previously manufactured.

  • Page 25: Extended Or Third-Party Warranties

    Extended or Third-Party Warranties Alliance RV does not offer any warranties outside of those outlined on pages 6-7 on the new purchase of an Alliance RV. Any extended or third party warranties obtained in connection with the purchase of an Alliance RV is the product of another organization.

  • Page 26: Parts Information For Non-Warranty Purposes

    Alliance RV pay an independent service shop to perform repairs to the defect. If the defect is still incapable of being repaired, Alliance RV may, at its option, provide you the diminished value damages (the difference in purchase price and actual value of your recreational vehicle on the date of purchase).

  • Page 27: Events Discharging Alliance Rv From Obligation Under Warranty

    Alliance RV is not liable to return the aftermarket addition to like-new condition. For example, replacement of graphics due to warranty coverage will not result in Alliance RV paying for a new ceramic coating application.

  • Page 28: Warranty Registrations

    The selling dealer will assist you in completing and submitting the Alliance RV product warranty registration form. That form must be returned to Alliance RV within ten (10) days of your taking delivery of the recreational vehicle. Failure to file this warranty registration with Alliance RV will not affect your...
  • Page 29 WARRANTIES, WHETHER SOUNDING IN CONTRACT, TORT OR STATUTE, WILL BE GOVERNED BY THE LAWS OF THE STATE OF INDIANA, INCLUDING ITS STATUTE OF LIMITATIONS, WITHOUT GIVING EFFECT TO ANY CHOICE OR CONFLICT OF LAW PROVISION OR RULE (WHETHER OF THE STATE OF INDIANA OR ANY OTHER JURISDICTION) THAT WOULD CAUSE THE APPLICATION OF THE LAWS OF ANY JURISDICTION OTHER THAN THOSE OF THE STATE OF INDIANA.

  • Page 30: Safety Precautions

    SAFETY PRECAUTIONS Throughout this manual, you will find the symbols shown below. This information is provided to help you avoid personal injury or death as well as damage to your RV and other property. Take the time to review all these warnings. INDICATES POTENTIAL MINOR TO MODERATE INJURY AND/OR PROPERTY DAMAGE INDICATES POTENTIAL DEATH OR SERIOUS INJURY INDICATES POTENTIAL DEATH OR SERIOUS INJURY...

  • Page 31: Symbols Used

    SYMBOLS USED Information box: Used to highlight particularly helpful information about the topic. Technical Hint or Troubleshooting box: Used to present a short technical hint or troubleshooting method related to the topic. This symbol denotes an available vendor manual or Tech Tip at Alliance Academy. This symbol denotes an available video at Alliance Academy.

  • Page 32: Weight Ratings, Associated Labels, Loading And Weighing

    Knowing and understanding the following weight terms are a crucial step to overall safety of your RV. By becoming familiar with this information, you will be better equipped in making decisions when using your Alliance RV product. GAWR = Gross Axle Weight Rating and is the maximum weight the recreational vehicles axle(s) are rated for.

  • Page 33: Federal Certification

    Figure 2. Tire and Loading Information label. WYKW: Alliance RV Tire Pressure Cargo Capacities & Weighing Your RV Weight and balance of your RV is crucial to your safety. To ensure that you are within all the established...
  • Page 34 Always make sure that your RV is loaded evenly from side to side, never exceeding the specified weight ratings established for your RV. Always secure loose items and ensure that all factory provided securements are in place before you travel. LP Gas and fresh water are considered cargo weight.

  • Page 35: Tow Vehicle: Hitch And Configuration Concerns

    TOW VEHICLE: HITCH AND CONFIGURATION CONCERNS Hitch and Hitch Selection There are many different hitch options. The type of hitch you select will impact the towing and handling characteristics of the travel trailer. Selecting and installing an appropriate hitch on the tow vehicle is vital to towing the travel trailer safely.

  • Page 36: Hitch Height

    Hitch Height Hitch height is determined when the trailer is level. Once the travel trailer is connected to your tow vehicle, verify the hitch ball height by taking a measurement from the center of the hitch ball to the ground. This is your hitch height reference measurement. •...

  • Page 37: Tire And Wheel Information & Safety

    Tire Size Alliance RV uses a very robust Load Range F ST235/85R16 for the Avenue trailer line. Only purchase new tires that are the same size as the vehicle’s original tires. Look at the tire information label or on the sidewall of the tire you are replacing to find the information.
  • Page 38 TIRE PRESSURE SHOULD BE CHECKED AT THE BEGINNING OF A TRIP. ALWAYS FOLLOW ALL INSTRUCTIONS ON THE FEDERAL CERTIFICATION LABEL FOR ESTABLISHED REQUIREMENTS. 1. Inspection of the tires o Check your tires regularly, this is crucial to your safety. Ideally, tires should be inspected monthly.

  • Page 39: Changing A Tire

    Changing a Tire WYKW: Where to Place Your Tire jack 1. Keep the recreational vehicle attached to the tow vehicle. Block the tire on the opposite side of the recreational vehicle from the tire you are changing. 2. Remove the spare tire from the Spare Tire Carrier. 3.
  • Page 40 ALWAYS TORQUE THE WHEEL LUG NUTS TO THE REQUIRED SPECIFICATIONS. TRAILERS EQUIPPED WITH THE MORRYDE INDEPENDENT SUSPENSION MUST TORQUE THEIR LUG NUTS TO THE SPECIFICATIONS LISTED AS PER MORRYDE DOCUMENTATION. Table 1. Wheel lug nut torque specifications. STUD ACCEPTABLE LUG NUT DIAMETER RIM SIZE RIM TYPE...

  • Page 41: Brake Systems

    BRAKE SYSTEMS Alliance trailers come standard with drum brakes. The brakes are actuated via a brake controller to provide an electric signal to the trailer via the Tow Plug to apply the brakes. That signal travels to each wheel where an electromagnet applies the brakes. It is important to regularly inspect and maintain the brake systems according to the maintenance schedule.

  • Page 42: Brake Maintenance

    Symptom: There is a known issue on Chevy/GMC trucks where a “Check Trailer Wiring” or “Service Trailer Brake” issue will post on the Driver Information Center, yet all tail lights and brakes function • Damage to tow vehicle socket or trailer plug causing poor blade or socket connection. Refer to GM service bulletin 21-NA-155 to check for this issue.

  • Page 43: Leaf Spring Suspension System

    -Brakes (electric drum) -Double eye leaf springs Heavy Duty Shackle Kit – MORryde product page Equalizer - MORryde, Tandem Axle, CRE3000 product page WYKW: Why is there a slight bend in your Alliance RV Axles? Figure 5. MORryde CRE3000 equalized suspension.

  • Page 44: Morryde Cre 3000 Equalizer

    MORryde CRE 3000 Equalizer A tandem axle equalizer is a component in a trailer's suspension system that is used to distribute the load evenly between the two axles, ensuring that the weight is shared and balanced as the trailer moves over uneven terrain.

  • Page 45: Wet Bolt Torque

    Wet Bolt Torque Always use a calibrated torque wrench to confirm proper torque according to the Maintenance Schedule. Do NOT under torque or over torque under any circumstance. Torque the nuts of all wet bolts to 40 ft-lbs. There are seven locations per side, as indicated with red circles in Figure 8. Figure 8.

  • Page 46: Tow Plug

    TOW PLUG The tow plug (7-way wire harness) is wired to your RV to connect electrical power from the tow vehicle for the RV brakes, taillights, clearance lights, turn signals and brake lights. The plug is keyed to fit into a receptacle on your tow vehicle and can only be inserted one way.

  • Page 47: Wire Lug Torque

    Wire Lug Torque The Tow Plug cord is connected to the trailer wiring through a junction box mounted on the back of the Pin box. According to the Maintenance Schedule, one should follow this procedure to assure a solid wiring connection. 1.

  • Page 48: Safety Chains

    SAFETY CHAINS Requirements for safety chains vary by state. Your travel trailer RV comes equipped with chains to meet Society of Automobile Engineers (SAE) standards for the maximum gross trailer weight. Using safety chains when towing is always recommended. The recommended method is to cross them under the trailer tongue and attach them to the safety chain loops on the tow vehicle’s hitch.

  • Page 49: Towing Your Rv

    TOWING YOUR RV When pulling an RV, the most obvious thing is shear mass. You’ll be taller, wider and much heavier. Allow yourself plenty of room and time to maneuver out of potentially difficult situations. Being taller, RVs are more susceptible to sway caused by cross winds and turbulence created by other large passing vehicles.

  • Page 50: Before And After Travel: Checklists

    (electronics, camp chairs, utility connections.) In order to move place to place, it’s important to prepare for the trip carefully, review items during travel (depending upon distance being traveled,) and set up at the new location. Finally, it’s good to assure that your Alliance RV continues to be “road ready” between trips.
  • Page 51 Some of the suggested checklists are: • Pre-travel or departure checklist: This list contains all steps that might be needed to transition from a stationary campsite to a traveling RV, departing the campground. Sometimes, this list may need to start being addressed the day before travel (tow vehicle checks, electronic device charging are two points that might need to be reviewed the day before.) The list commonly contains things like packing up decorations, making sure to empty any water out of the fresh water tank, pack up satellite dishes, ensuring all doors and windows are latched in position, vent...

  • Page 52: Hitch Receiver

    HITCH RECEIVER The Alliance Avenue is supplied with a factory hitch receiver and you can tow an additional small trailer behind your RV. Do not use a draw bar longer than 10 inches. The maximum length of the draw bar is from the center of the fastening pin to the center of the ball.

  • Page 53: Connecting To The Tow Vehicle

    CONNECTING TO THE TOW VEHICLE The following procedure assumes that: • The trailer has wheel chocks properly placed in front of and behind the wheels on both sides. • The trailer has been prepared for hitching, with all jacks and stabilizers up, and the hitch is high enough to enable one to position the hitch ball underneath the hitch ball receiver on the trailer tongue.
  • Page 54 VISUALLY CHECK ALL JACKS TO ENSURE THAT THEY ARE FULLY RETRACTED BEFORE TOWING THE UNIT.

  • Page 55: Disconnecting And Leveling Your Rv

    THE LEVELING OF THE RECREATIONAL VEHICLE SHOULD BE DONE BEFORE THE STAIRS ARE LOWERED AND WITH THE SLIDES IN. WYKW: Do you level your Alliance RV with your slides in or out? WYKW: Make Sure Steps are Up BEFORE Leveling 10.

  • Page 56: Bal Ls 5.3 Auto Leveling System

    BAL LS 5.3 AUTO LEVELING SYSTEM Your Avenue travel trailer is equipped with the LS 5.3 Auto Leveling & Stabilizing system from BAL RV Products. This is a five point automated system equipped with a powered tongue jack, two rear leveling jacks, and one powered c-jack near the front corners of the trailer.

  • Page 57: Towing The Unit

    • NEVER USE THE LEVELING SYSTEM AS A LIFT FOR CHANGING TIRES OR WORKING UNDER THE UNIT. • KEEP PEOPLE AND PETS CLEAR OF THE UNIT BEFORE TURNING THE LEVELING SYSTEM ON AND WHILE OPERATING THE SYSTEM. • ALWAYS CHOCK THE TIRES BEFORE DISCONNECTING THE UNIT FROM THE TOW VEHICLE AND/OR OPERATING THE LEVELING SYSTEM.
  • Page 58 4. Open the cover to the tongue jack, providing access to the illuminated control screen. 5. Press the ON/OFF button to activate the display. Figure 11. Leveling system HOME SCREEN. White buttons are available options 6. Press the TONGUE JACK MODE on-screen button. 7.
  • Page 59 11. Press AUTO LEVEL. Figure 13. AUTO LEVEL execution screen. VEHICLE, PEOPLE, PETS AND OBSTRUCTIONS MUST BE COMPLETELY CLEAR OF UNIT BEFORE EXECUTING THE “AUTO LEVEL” FUNCTION. 12. Press OK to begin “AUTO LEVEL” or STOP to make another selection. The system will go through a series of moving the jacks and checking the unit for level.

  • Page 60: Reconnecting The Trailer To The Tow Vehicle

    Reconnecting the Trailer to the Tow Vehicle 1. Press the ON/OFF button to activate the display. Figure 15. HOME SCREEN display after turning the system 2. Press AUTO MODE, then press AUTO RECONNECT. Figure 16. AUTO RECONNECT execution screen. 3. Press OK to begin “AUTO RECONNECT” or STOP to make another selection. The system will retract all stabilizer jacks and the rear leveling jacks, then extend or retract the tongue jack until the proper connection height is achieved.
  • Page 61 Figure 17. AUTO RECONNECT status displays. 4. Press HOME SCREEN. Position the tow vehicle’s hitch ball underneath the hitch ball receiver. If needed, use the EXTEND button to raise the hitch ball receiver on the trailer. 5. Ensure the receiver latch mechanism is open/up to receive the hitch ball correctly. 6.

  • Page 62: Manual Mode Functions

    ALWAYS CHECK TO ENSURE THAT THE UNIT IS PROPERLY CONNECTED TO THE TOW VEHICLE BEFORE RETRACTING THE TONGUE JACK. 9. Press OK to begin retracting the tongue jack. Press STOP to make another selection. a. The display will read “TONGUE JACK RETRACT IN PROGRESS.” b.

  • Page 63: Manual Leveling Jack Mode

    2. Press MANUAL MODE. Figure 20. Leveling system HOME SCREEN. 3. Press and hold EXTEND/RETRACT to operate the stabilizer jacks. Figure 21. STABILIZER MODE execution screen, allowing manual control of the stabilizers only. 4. Press MANUAL MODE or HOME SCREEN to continue. ALWAYS MAKE SURE THAT THE STABILIZER JACKS ARE FULLY RETRACTED BEFORE OPERATING THE TONGUE JACK OR REAR LEVELING JACKS.

  • Page 64: Auto Leveling System Troubleshooting

    REAR: Both leveling jacks on the rear of the unit will move. NOTE: Run the rear leveling jacks all the way to the ground before lifting side to side. LEFT: The left rear leveling jack will move (road side.) RIGHT: The right rear leveling jack will move (curb side.) Figure 22.

  • Page 65: Auto Leveling System Maintenance

    Table 2. BAL LS 5.3 leveling system error messages. LCD Message What's Happening? What Should Be Done? Rear raised too high during auto Move the unit into an area with stable soil level process. (Without being or place load distribution pads under each AUTO LEVEL FAILED able to lift side to side) This may jack.
  • Page 66 b. Remove the plastic plug on the tube just under the top casing. c. Apply a small amount of grease on the screw. d. Reinstall the plastic plug. Figure 24. Tongue Jack grease access hole. 3. Grease the rear leveling jacks: a.

  • Page 67: Manual Override

    Figure 26. Stabilizer c-jack grease location. 5. Check all bolts for correct torque. a. Tongue Jack: 30 ft. lbs. b. Rear Leveling Jacks: 80 ft. lbs. c. Stabilizer Jacks: 30 ft. lbs. Manual Override Each component can be manually driven should the need arise. The leveling and tongue jacks each have an override access point at the bottom of the motor, while the tongue jack also has a top access point.
  • Page 68 Jack Override (tongue and rear leveling from bottom) 1. Remove the round plug at the bottom center of the motor. 2. Insert the 5/16” socket mounted in a drill driver to rotate the motor. Figure 28. Manual override of jack motors from the bottom. Upper images are the tongue jack, lower images are the rear leveling jacks.

  • Page 69: Programming The Zero Point Or "Level Position

    DAMAGE TO THE LEVELING SYSTEM AND/OR THE RV. THIS SERVICE INFORMATION IS DESIGNED FOR EXPERIENCED RV TECHNICIANS. ALLIANCE RV NOR BAL RV PRODUCTS ARE RESPONSIBLE FOR DAMAGE THAT MAY RESULT FROM THE MISUSE OF THIS INFORMATION. 1. To access the programming screen, press and hold the voltage readout in the bottom left corner of the home screen.
  • Page 70 3. Now that you are at the programming screen, you will see the buttons necessary to manually level the RV. First run both rear leveling legs to the ground, then use the extend and retract buttons as necessary to achieve the true level position. A carpenter’s bubble level on the RV floor may be helpful for this step.

  • Page 71: Occupant Safety

    OCCUPANT SAFETY Alliance RV trailers are equipped with safety systems that work together to help protect the occupants in the event of an emergency. Please read and fully understand all safety functions before using your new RV. Emergency Exit Windows While all RV brands are different, the operation of the emergency windows are generally consistent across brands.
  • Page 72 Table 3. Styles of emergency exit windows that may be present on your RV. Each opens differently. 1. Pull or Tab Style Latch: This style is generally used on larger slider style exit windows. Pull the handle out, or rotate the tab out (similar to other sliding windows) to slide the window open for escape.
  • Page 73 3. Lever Style Latch: This style has a handle that will either rotate or pull out and up to disengage to window retention. Once opened, push out the window, which will hinge at the top. Figure 35. Rotation-Lever style latch on an emergency exit. Rotate the handle up into the window area to disengage the latch.

  • Page 74: Fire Safety

    Fire Safety Safety is always important, whether you’re at home or on the road. As far as your RV, make sure to keep fire safety a top priority. IN A FIRE, EVACUATING ALL OCCUPANTS FROM THE RV SAFELY MUST BE YOUR TOP PRIORITY.
  • Page 75 DO NOT TURN ELECTRICAL POWER BACK ON AFTER THE USE OF AN EXTINGUISHER. INSPECT EXTINGUISHERS WEEKLY. IF YOUR RV HAS BEEN IN STORAGE, INSPECT BEFORE THE RV IS USED. ALWAYS INSPECT BEFORE A VACATION OR TRIP WITH YOUR RV. Some early model Alliance trailers had a combination smoke & carbon monoxide (CO) alarm.

  • Page 76: Propane And Carbon Monoxide (Lp & Co) Alarm (Base Of Wall Near Stairs)

    If this alarm sounds, get out of the RV as quickly as possible and call your emergency services. Do not go into the RV until the problem is identified and corrected. Propane and Carbon Monoxide (LP & CO) Alarm (Base of Wall near Stairs) For your safety, your RV is equipped with a combination LP and CO Alarm.

  • Page 77: Alarm Troubleshooting

    1. Press the TEST/MUTE button to temporarily silence the alarm. 2. Evactuate the RV. Make sure to account for everyone. 3. Call 911 or the local emergency services available in your area. 4. Do not re-enter the RV until the problem has been corrected Propane Alarm - If propane is detected, the RED led will will flash and the alarm will sound with a steady tone and remain on until the area is clear from propane gas.

  • Page 78: Lp & Co Alarm

    • Clean the alarm at least once a month by blowing air across it from a vacuum output or dusting the cover with an appropriate cloth or dusting tool. • ALWAYS USE THE EXACT BATTERIES SPECIFIED BY THE ALARM MANUFACTURER. •...

  • Page 79: Propane

    PROPANE The propane system provides heat, hot water, fuel for cooking, refrigeration and can be used for other small appliances. The propane supply for an RV is stored in a DOT cylinder that is positioned vertically upright and mounted outside the living space of an RV. Repair and/or replacement should always be done by certified service technicians.

  • Page 80: Traveling With Propane

    IF YOU SMELL PROPANE: • DOT PROPANE TANKS MUST BE TRANSPORTED AND STORED IN AN UPRIGHT POSITION SO THE PRESSURE RELIEF VALVE CAN FUNCTION PROPERLY. LAYING A TANK ON ITS SIDE MAY CREATE A VERY DANGEROUS SITUATION. • THE LP PIGTAIL HOSE MUST BE INSTALLED IN A MANNER TO AVOID TENSION OR STRESS AT EITHER END OF THE HOSE.
  • Page 81 This regulator allows for removal of empty cylinders for refill without interrupting propane supply and will automatically switch from the supplying cylinder to the reserve cylinder when empty. Figure 40. Two stage regulator with 11" water column pressure output for the trailer's appliances.

  • Page 82: External Appliance Quick Connect

    Figure 41. Using the Automatic Changeover regulator. External Appliance Quick Connect The quick connection port allows you to use the onboard propane supply for external appliances outside of your RV. The pressure at the port is already at 11” of Water Column (wc), meaning your appliance (BBQ Grill, firepit, etc.) needs to be able to connect to this port without having the propane supply travel through another regulator.
  • Page 83 Using the External Quick Connect Connecting an Appliance 1. Remove the Dust Cover. 2. Push the retaining ring back (toward on/off lever.) Ensure that the shutoff lever is as shown in the picture, turned perpendicular (across) the flow of propane. The ring will not move when the lever is inline with the direction of flow (propane flow ON.) 3.

  • Page 84: Propane Cylinders

    The pressure at the quick connect port is 11" of water column, which is the desired operational pressure of most propane appliances. If the appliance connected to the quick connect port has an additional regulator, the pressure will be too low to function. Verify proper set up with accessory manufacturer.

  • Page 85: Cooking With Propane Gas

    A propane cylinder can only be filled to 80% of their total capacity. The remaining 20% is for expansion that takes place when subjected to heat. If a cylinder is filled to 80% when it is cold outside, that same cylinder may be at 90% on a much warmer day. Always ensure that the cylinder is filled to the required limit only.

  • Page 86: Inspection (Professional)

    If issues are found: Turn off the propane cylinders immediately. The propane system should be serviced by a qualified technician immediately upon an issue being identified. Never paint propane cylinders, valves or mounting hardware. Inspection (Professional) As per the Maintenance Schedule, your RV’s propane system should be inspected by a certified professional.

  • Page 87: Slide-Outs Overview

    SLIDE-OUTS OVERVIEW Slide-out Safety Information FAILURE TO ADHERE WITH THE FOLLOWING INFORMATION MAY RESULT IN DEATH, SERIOUS INJURY, RV OR OTHER PROPERTY DAMAGE. All slide-out systems are intended solely for opening and closing the slide-out room and should never be used for any other purpose. Before operating your slide-out, please keep these things in mind: •...
  • Page 88 Late model Alliance Trailers also have slide switches located either at the utility panel at the off-door- side, or in the forward pass-through (door side). They are individual switches labeled to control the same slide numbers as the inside Monitor Panel. Figure 47. Remote slide controls in the utility bay of the Avenue.

  • Page 89: Electric Slide-Outs (If Equipped)

    ELECTRIC SLIDE-OUTS (IF EQUIPPED) Alliance RV utilizes an electric through frame slide-outs for the main floor slide-outs on Avenue trailers. This system has a single electric actuator with manual override capability. The system is robust, low maintenance, and enables easy adjustment of the slide if needed.

  • Page 90: Slide-Out Gear Pack

    synchronized. A single actuator drives the system from one side, and has a gold-colored Stop Can and nuts secured to the brackets in order to control the precise in and out travel distances. Slide-out Gear Pack The Gear Pack converts the linear motion from the drive bar into rotational motion, which is transmitted to the idler side of the system via the crossbar, and a second gear pack converts the rotational motion back to linear motion.

  • Page 91: Retracting Your Electric Slide-Out

    If your slide room does not move, or moves initially and then stops, the first item to check is the state of charge of your battery. Retracting Your Electric Slide-out 1. Ensure the floor is swept clean and no debris is present that will get caught under the slide and damage the floor.

  • Page 92: Electric Slide-Out Maintenance

    Table 4. Electric Through-frame slide troubleshooting. WHAT IS HAPPENING? WHY? WHAT SHOULD BE DONE? Restriction or obstruction Check for and clear obstruction. inside or outside of unit. *Check battery voltage and charge if needed. This must be above 10.5V, Room doesn't move under load.

  • Page 93: Mechanical Maintenance

    and, in some situations, may be detrimental to the environment and long-term dependability of the system. THE GEAR PACKS SHOULD BE LUBRICATED PERIODICALLY OR WHEN EXCESSIVE SOUND IS HEARD, PLEASE REFER TO THE APPROPRIATE MAINTENANCE SECTION. Mechanical Maintenance Although the system is designed to be almost maintenance free, actuate the room once or twice a month to keep the seals and internal moving parts lubricated.

  • Page 94: Manual Electric Slide-Out Operation (Manual Override)

    2. Apply dry silicone onto gear pack drive shaft at lubrication points A through D in Figure 52 and Figure 53. Figure 52. Gear Pack lubrication points - exterior. Figure 53. Gear Pack lubrication points - interior. Do not lubricate rack or pinion gear teeth, lubricate drive shaft only. If lubricant gets on pinion/bar, dirt and debris can stick and cause premature wear.
  • Page 95 The Lippert Electric Through Frame Slide-out comes with a Manual Override system. The manual override is accessed through specially placed access holes which penetrate the lower skirting and frame of the trailer. These holes are placed on the opposite side of the trailer from the slide-room, near the location of the actuator.

  • Page 96: Advanced Maintenance: Adjusting Your Electric Slide-Outs

    Advanced Maintenance: Adjusting Your Electric Slide-outs While slide-outs are adjusted at the factory to achieve smooth and consistent operation, normal wear and tear may require slides are adjusted over the lifetime of the trailer. WE RECOMMEND THAT SLIDE-OUTS ARE ADJUSTED BY A CERTIFIED RV TECHNICIAN. •...

  • Page 97: Adjusting Electric Slide-Out "Out" Position

    Figure 55. Electric slide-out IN and OUT adjustment components on the actuator. Adjusting Electric Slide-out “OUT” Position 1. Locate the cylinder coming through the frame. 2. If the slide is fully extended, bring it partially in. 3. Referring to Figure 55Error! Reference source not found., use a 1-1/8” wrench for nut (B) and a 1-1 /16”...

  • Page 98: Adjusting The Electric Slide-Out Room Horizontally

    Adjusting the Electric Slide-out Room Horizontally BEFORE BEGINNING THIS PROCEDURE, MAKE SURE THE VERTICAL ADJUSTMENT BOLT ON BOTH BRACKETS IS DRIVEN FULLY UP AGAINST IT’S BRACKET. IF NOT, THE ROOM WILL DROP WHEN YOU LOOSEN THE BOLTS IN STEP 4. REFER TO THE VERTICAL ADJUSTMENT PROCEDURE FOR AN IMAGE OF THE BOLTS OF CONCERN.

  • Page 99: Synchronizing Electric Slide-Out Room Travel

    4. Loosen carriage bolts (Figure 57A) on each bracket located at the end of each guide rail. The image shown is from the top of the bracket, where the slide-out room is sitting. Figure 57. Room Bar mounting bracket - idler side. The drive side will not have adjustments on the guide rail.
  • Page 100 If the synchronization requires more distance than that provided by the adjustment bracket, a more advanced procedure is required to adjust the gear pack position on the telescoping bar. That procedure is beyond the scope of this section. Refer to Lippert documentation for further assistance.

  • Page 101: In-Wall® Electric Slide-Out System (Schwintek) (If Equipped)

    IN-WALL® ELECTRIC SLIDE-OUT SYSTEM (SCHWINTEK) (IF EQUIPPED) Early model-year Alliance trailers utilize the In-Wall® electric slide-out system in the upstairs portion of the RV, typically a bedroom slide-out. This system is commonly referred to as a Schwintek slide-out system. The system has two in-wall channels with gear racks at the top and bottom. The motors are connected to a single controller.

  • Page 102: In-Wall Slide-Out Controller Overview

    In-Wall Slide-out Controller Overview Figure 60. In-Wall (Schwintek) slide controller. Each slide will have one controller. • Status LEDs: 2 LEDs, 1 green and 1 red, are provided to indicate current controller status and faults. • Mode Button: Used to engage the electronic manual override. •...

  • Page 103: In-Wall Slide-Out System Overview

    In-Wall Slide-out System Overview Figure 62. In-Wall slide out system diagram. In-Wall Slide-out Motor and Harnesses Check for proper connections between the motors and harnesses. Visually inspect the exposed harnesses to ensure they are not pinched or damaged. Note: Ribs on motor connector lineup with notch inside of female connector on the wiring harness.

  • Page 104: In-Wall Slide-Out Troubleshooting

    In-Wall Slide-out Troubleshooting Lippert In-Wall® Slide-out Troubleshooting and Service Manual If problems occur with your slide-out, follow these steps to find the issue. • If there is no movement in the slide, and no noise can be heard: 1. Check controller for a fault code. See Controller Fault Codes, below. 2.

  • Page 105: Controller Fault Codes

    Controller Fault Codes During operation when an error occurs, the controller board will use the LEDs at the upper left corner to indicate where the problem exists (see Figure 64). For motor specific faults the green LED will blink 1 Figure 64.

  • Page 106: Resynchronizing In-Wall Slide-Out Motors

    Resynchronizing In-Wall Slide-out Motors If operated properly, holding down the Extend/Out button every time until both motors shut themselves off, your slide-out motors will normally remain in synchronization with each other. However, there can be electrical events or mechanical friction which causes them to not operate simultaneously. If you notice one side moves more than the other, or the system stops retracting the slide after a few inches (commonly stopping when askew) then you may have to resynchronize the slide using the following procedure.

  • Page 107: Motor Disengagement Procedure

    Figure 65. Controller interface showing Mode button. Motor Disengagement Procedure The following procedure can be used to manually move a slide when one motor is unresponsive and the slide must be extended or closed. This procedure is also the method by which a motor can be replaced. Further details can be found at https://lci-support-doc.s3.amazonaws.com/technical-information- sheets/slideouts/ccd_0002058.pdf...
  • Page 108 Figure 66. In-Wall system overview, showing relevant positions for motor disengagement. After removal of motor, the remaining motor can be activated and the slide moved as long as there are person(s) able to manually assist the side of the slide with the missing motor. Once the slide is in the desired setting, the motor must be lowered back into place and the retention screw applied to ensure the slide will not move.

  • Page 109: Bal® Exact-Slide Slide-Out System (If Equipped)

    BAL® EXACT-SLIDE SLIDE-OUT SYSTEM (IF EQUIPPED) Some Alliance Avenue trailers utilize an Exact-Slide in-wall slide system. These systems have two in-wall channels connected via a single controller. BAL Exact-Slide product information (see Support and Video tabs) Operating Your Exact-Slide System Extending Your Slide-out 1.

  • Page 110: Bal Exact-Slide Maintenance

    • To determine if the controller is not getting a signal from the switch, locate the Motor 1 (M1) and Motor 2 (M2) move IN switches (shown in white in the lower corners of the control board, and marked on the cover.) Push one at a time to see if the corresponding slide motor moves in. If so, look for power loss from the switch or a bad switch.

  • Page 111: Bal® Accu-Slide Slide-Out System (If Equipped)

    BAL® ACCU-SLIDE SLIDE-OUT SYSTEM (IF EQUIPPED) Some Alliance Avenue trailers utilize an Accu-Slide in-wall slide system. These systems can be identified by having a single motor above or below the slide on the inside wall, with a dual chain system connecting both sides of the slide.
  • Page 112 WHAT IS HAPPENING? WHY? WHAT SHOULD BE DONE? Adjust cable tension. Tighten all 4 jam Chain is caught on a bracket nuts. Place white anti-vibration blocks on cable nuts. Put chain back on sprocket. Re-adjust cable Chain is off the sprocket tension, tighten all jamb nuts (4).

  • Page 113: Bal Accu-Slide Maintenance

    WHAT IS HAPPENING? WHY? WHAT SHOULD BE DONE? 1. Remove the tension from the cable via the cable adjustment nut. 2. Remove the screws from the standoff bracket and adjust to the approximately appropriate location. Cable is bent and/or Standoff bracket was not 3.

  • Page 114: Stand-Off Bracket Alignment

    4. Tension the IN TOP and IN BTM cables and chain until you have reached ½” deflection on the exterior cables. (Deflection: you should be able to use your thumb and pointer finger to easily lift the cable ½” and push the cable down ½” from center.) 5.

  • Page 115: Manual Override

    Manual Override Use the flexible shaft included in your owner’s packet. You may or may not need the #3 square bit mounted on the shaft, depending upon your specific motor. Some motors will have a square drive hole, some will have a hex drive socket. in a drill/driver. DO NOT USE AN IMPACT DRIVER. Figure 70.

  • Page 116: Electrical: General

    Carbon Monoxide and LP detectors, and depending upon the refrigerator some, or all, of its power. You’ll also find that Alliance RV uses Smart Wire Technology, where 12-volt wiring is color coded and numbered. Further details on Smart Wire Technology are covered below.

  • Page 117: Electrical Troubleshooting

    Owner Empowerment Series Video – Electrical System Overview. Electrical Troubleshooting There are a number of individual electrical systems in your Alliance RV. Some of them interact with each other, and all of them are connected through the Power Distribution Center, either on the 120 V side, or the 12 V side.

  • Page 118: Removing All Power From The Rv

    Symptom One or more of the 120V outlets in the RV do not work. Possible Causes Breaker tripped, faulty GFCI, loose connection. Suggested 1. Locate any breaker labeled GFI in the Power Distribution Center. Action(s) Turn each breaker off, then on. Do this even if they don't seem to have been tripped.

  • Page 119: Power Cord

    Power Cord A heavy-duty power cord with a 4-prong grounding plug is used to plug the RV into an external 120V source. Figure 71. Power plug port and connected cord. Never connect the power cord to a power source: • That is not wired to the National Electric Code standard for 50 amp 120V/240V.

  • Page 120: Gfci (Ground Fault Circuit Interrupter)

    7. Turn on the MAIN breakers in the Power Distribution Center. • DO NOT plug your RV 50-amp shore cord into any receptacle that is not wired to National Electric Code for 50 amp 120/240V configuration. Doing so will supply the RV with the incorrect electrical power causing extensive damage to the electrical system and 120-volt components which would not be warrantable.

  • Page 121: Gfci Troubleshooting

    incoming current. A GFCI is specifically designed to protect a person from electrical shock by reacting to an imbalance that can be as small as 4 or 5 milliamps, when detected, in less than one tenth of a second the circuit is tripped and shuts off. GFCI Troubleshooting If the GFCI circuit breaker trips, and cannot be reset by pushing the RESET button, please check the following things:...

  • Page 122: Solar Disconnect Switch (If Equipped)

    WITHOUT A BATTERY/BATTERIES CONNECTED. Battery Unless certain upgraded solar packages are purchased from the factory, Alliance RV does not supply batteries in trailers. Trailers not equipped with these solar options have their batteries selected and installed by the dealership from which you purchased your trailer.

  • Page 123: Battery Troubleshooting

    the battery and will select an appropriate charging profile based on the battery type and state of charge (how full it is.) The battery type setting on the converter may be manually set, or it may be automatic. Please refer to the Power Distribution Center section for more information. The converter will also charge the battery when the trailer is connected to a running generator (if equipped) as the generator simulates shore power.

  • Page 124: Non-Vented Batteries (If Equipped)

    Renogy Batteries (If Equipped) When equipped with certain solar packages, Alliance RV will install up to three Lithium Ion Phosphate batteries each rated at 100 Ah and wired in parallel (if more than one) to provide up to 300 Ah of power.

  • Page 125: Identification Of Parts

    • The warning status is only visible on the Renogy Monitoring Screen and the DC Home app. • The warning status will not affect the normal use of the battery. But it is recommended to pay closer attention to the battery to prevent it from entering the protection mode.

  • Page 126: Connecting Batteries In Banks

    Figure 76. Renogy battery activation cable - power button (switch). Connecting Batteries in Banks DO NOT STRING BATTERIES IN SERIES. DOING SO CAN CAUSE CATASTROPHIC FAILURE. • DO NOT STRING BATTERIES WITH DIFFERENT CHEMISTRIES, BRANDS, MODELS, RATED CAPACITIES, OR NOMINAL VOLTAGES IN PARALLEL. •...

  • Page 127: Activation Switch Operation

    Activation Switch Operation PLEASE LEAVE THE BATTERY IN SHELF MODE DURING INSTALLATION. DO NOT SWITCH THE BATTERY TO ACTIVE MODE UNTIL MAKING SURE THAT ALL THE CONNECTIONS ARE CORRECT AND SECURE. CONNECTING ACTIVE BATTERIES TO THE SYSTEM MAY TRIGGER THE SHORT CIRCUIT PROTECTION OF THE BATTERY. The battery can be switched between active mode and shelf mode with the Activation Switch, shown in Figure 75 and Figure 76.

  • Page 128: Battery Storage

    A common error when trying to activate/de-activate the battery is plugging into the incorrect port. Notice the correct port (pictured) is closer to the Positive battery terminal. Battery Storage • DO NOT EXPOSE THE BATTERY TO THE EXTREME TEMPERATURES OVER 149°F (65°C). •...

  • Page 129: Renogy Battery Troubleshooting

    Renogy Battery Troubleshooting • PLEASE KEEP THE BATTERY AWAY FROM WATER, HEAT SOURCES, SPARKS, AND HAZARDOUS CHEMICALS. • DO NOT PUNCTURE, DROP, CRUSH, BURN, PENETRATE, SHAKE, OR STRIKE THE BATTERY. • DO NOT OPEN, DISMANTLE, OR MODIFY THE BATTERY. • DO NOT TOUCH ANY TERMINALS OR CONNECTORS. •...

  • Page 130: Renogy Battery Maintenance

    WHAT IS HAPPENING? WHY? WHAT SHOULD BE DONE? Battery terminal voltage shows battery internal fuses Contact Renogy for assistance. 0V in active mode may have blown due to severe over-current Battery voltage gets too low to Battery charging circuit 1. Disconnect battery and charge on a fault Lithium-compatible charger reliably power electric loads or...

  • Page 131: Cleaning

    TERMINAL CORROSION MAY ADVERSELY AFFECT THE BATTERY PERFORMANCE AND PRESENT A SAFETY HAZARD. PLEASE KEEP TERMINALS FREE OF CORROSION. Cleaning If inspection reveals a need to clean the battery, follow these steps: 1. Turn the Solar Disconnect switch to the OFF position. IF A SOLAR DISCONNECT SWITCH OR BREAKER IS NOT PRESENT, PLEASE SEE DOCUMENTATION FOR THE SOLAR CHARGE CONTROLLER BEFORE PROCEEDING.

  • Page 132: Operational Display

    Operational Display During normal operation, the following information will be displayed. The monitor has a backlight that will be on when the monitor senses any current flow above minimum levels. When charging the battery, the backlight will blink. See the section Manual Backlight Disable if desired. Figure 79.

  • Page 133: User Settings

    User Settings Figure 80. Renogy Battery Monitor programming display. Settings Available Table 10. Available settings on the Renogy Battery Monitor. Preset capacity: An initial capacity has been set at the factory, please set it according to the real capacity of your battery. HIGH V Full capacity voltage: When the voltage is higher than the set value, the capacity will be automatically set to 100%.

  • Page 134: Preset Capacity And Voltage Setting

    Preset Capacity and Voltage Setting 1. Press the “OK” key for 3s to enter setting menu 2. Click “up” or “down” key to select the desired setting item 3. On the desired setting, click the “OK” key to activate the setting. The set value will flicker, click the “OK”...

  • Page 135: Renogy Battery Monitor Troubleshooting

    Renogy Battery Monitor Troubleshooting Table 11. Renogy Battery Monitor troubleshooting guide. WHAT IS HAPPENING? WHY? WHAT SHOULD BE DONE? Backlight blinking (as loads are B- and P- of the shunt is See Owner's Manual for proper being connected) wired inversely. connection diagram.

  • Page 136: Power Distribution

    In the below sections, you’ll find separate discussions of most items due to the variety of installations in Alliance RV models. If you need help verifying what is installed in your RV, take a look at the images in the sections to identify which equipment you have, or feel free to contact Alliance RV to learn what your specific trailer has.

  • Page 137: 12 Volt Bus Bar

    WYKW: Smart Wire Quick Tip 12 Volt Bus Bar While not in the Power Control Center, it is important to note the location of where several 12 Volt circuits receive their power. These circuits may require high current or a certain type of fused connection, such as a self-resetting circuit breaker.

  • Page 138: Trained Persons

    If the breaker immediately trips again, contact Figure 81. Progressive Dynamics Power Control Center. your dealer or Alliance RV for assistance. If you believe a circuit breaker has tripped, but the switch is not visibly moved from its ON position, it is suggested to turn it off and then back on anyway.

  • Page 139: 12 Volt Fuse Panel

    • CIRCUIT BREAKERS AND FUSES WILL NOT OFFER COMPLETE PROTECTION OF THE ELECTRICAL SYSTEM IN THE EVENT OF POWER SURGE OR VOLTAGE SPIKE • REPLACEMENT CIRCUIT BREAKERS MUST BE OF THE SAME VOLTAGE, AMPERAGE RATING AND TYPE. NEVER USE A HIGHER RATED REPLACEMENT CIRCUIT BREAKER, DOING SO MAY CAUSE A FIRE BY OVERHEATING THE RV WIRING.

  • Page 140: Reverse Battery Protection Fuses

    • Disconnect batteries. Reverse Battery Protection Fuses In order to protect the RV from an improperly installed battery, the Power Control Center features a set of ATC type fuses and associated circuit. Located at the lower-right corner of the panel and separated from all other fuses, these easily accessible fuses will blow when a battery is connected in reverse.

  • Page 141: Progressive Dynamics Power Control Center Maintenance

    Table 12. Progressive Dynamics Power Distribution Center troubleshooting guide. WHAT IS HAPPENING? WHY? WHAT SHOULD BE DONE? No Output Proper AC power not connected Connect power supply Check AC distribution panel for proper operation Reverse battery fuses blown Check for reverse battery connection Replace fuses with same type and rating Short circuit...

  • Page 142: Inspection & Torque Check

    Inspection & Torque Check As per the Maintenance Schedule, perform the following inspection and bolt torquing procedure to the Power Control Center. 1. Completely remove all power from the RV as per the associated procedure discussed above. 2. Using a Voltmeter set to AC Voltage, ensure no power is present on either AC Mains breakers. 3.

  • Page 143: Wfco Power Control Center

    Table 13. Required torque values for lugs in the Progressive Dynamics power distribution center. LOCATION/BOLT WIRE GAUGE (AWG) TORQUE REQ. (in. lbs.) AC Breakers See breaker mfg. data AC Neutral & Ground Bars 10-14 DC Fuse Panel Lugs (+VCC, NEG-, POS+) 30-50 DC Terminal Block: Single Ckt Terminals DO NOT REMOVE...

  • Page 144: 120 Volt Circuit Breakers

    To reset a breaker, simply flip the switch to the off position then immediately back to the on position. If the breaker immediately trips again, contact your dealer or Alliance RV for assistance. If you believe a circuit breaker may have tripped, but the switch is not visibly moved from its ON position, it is suggested to turn it off and then back on anyway.

  • Page 145: 12 Volt Fuse Panel

    At the beginning of camping season, inspect the circuit breakers and replace as needed. Test by turning each circuit breaker off and back on, circuit breakers are wearable parts and must be replaced as needed as part of your RV maintenance. 12 Volt Fuse Panel You’ll find the 12-volt fuse panel either in the main power control center, or in a separate narrow panel mounted near the main power panel.

  • Page 146: Wfco Power Control Center Troubleshooting

    and requires no user intervention. It is responsible to power the 12 V fused circuits and charge the battery bank when 120 Volt power is received. It is powered by a single 120V breaker as labeled on the power control center door. It can monitor and power both conventional (flooded) batteries as well as Lithium-Ion (Li-Ion) batteries.

  • Page 147: Wire Gauge

    2. Using a Voltmeter set to AC Voltage, ensure no power is present on either AC Mains breakers. 3. Set Voltmeter to DC Voltage, and ensure no voltage exists on any of the DC connections (inside the DC power distribution panel.) 4.
  • Page 148 120 V Ground Bus Bar (behind Neutral bar.) Neutral Bus Bar Figure 84. WFCO Power Control Center with the safety cover removed.

  • Page 149: Inverter (If Equipped)

    The Intellitronix CH-1 is an energy management system (EMS) coupled to the inverter installed by Alliance RV. It combines a standard breaker box with automatic power management, allowing it to sense available AC power and prioritize power distribution to circuits based on user preferences. This helps optimize power usage in environments with limited power supply such as an inverter.

  • Page 150: Standard Programming

    devices of lowest priority so that the remaining devices can run without issue. This is called load shedding. The system is comprised of a wall mount Control Module coupled with a nearby wall mount Power Module, which looks like a second power panel with only 120 V breakers. Both devices are mounted on the interior of the RV near the Power Distribution Center previously discussed.

  • Page 151: Using The Control Module

    Table 16. Intellitronix Load Shed priorities. CIRCUIT # PRIORITY APPLIANCE General Purpose GFCI Microwave Fireplace A/C Main Using the Control Module The Control Module has six LED indicators across the upper portion of the panel. The LED will light up when that circuit is turned on (enabled.) In Table 16, one will note that the order of priority for the circuits does not need to match the circuit number.

  • Page 152: Inspection & Torque Check

    Details about the inverter can be found in the User Manuals. If you have further questions on what your trailer has or how it’s configured, please reach out to Alliance RV Service at service@alliancerv.com. Please provide the last six digits of your VIN number when doing so.

  • Page 153: Progressive Dynamics Inverter Troubleshooting

    Figure 88 shows the display section on the inverter face. The remote display panel inside the trailer, if equipped, will have identical displays and operation, with the exception of the Remote Display port (which is only on the inverter itself.) Figure 88.
  • Page 154 • DO NOT CONNECT ANY AC SOURCE TO THE AC OUTPUT WIRING OF THE INVERTER. CONNECTING AN AC SOURCE TO THE AC OUTPUT OF THE INVERTER WILL RESULT IN A HAZARDOUS CONDITION. • ANY DIRECTLY WIRED AC INPUT AND AC OUTPUT WIRING MUST BE PROTECTED WITH PROPERLY SIZED CIRCUIT PROTECTION.
  • Page 155 Problem: The inverter has turned off for seemingly no reason. Solution: An interruption in the communication between the display and the inverter has taken place. Check to make sure that the equipment ground wire is properly secured to the ground lug.

  • Page 156: Progressive Dynamics Inverter Maintenance

    o Determine what loads are connected to the output of the inverter. Remove any unnecessary loads until power is below maximum rated power o Determine peak power draw from inductive loads (refrigerators and other motor drive loads). If total peak power draw exceeds 2x rate power loads remove loads until peak power is below 2x rate power •...

  • Page 157: Renogy Pcl Inverter-Charger (If Equipped)

    Renogy PCL Inverter-Charger (If Equipped) The Renogy PCL series inverter-charger combines an inverter with battery charger. When it senses the AC input is active (and has quality power to pass through), it will provide battery charging functionality as it lets the AC current pass through to the loads.

  • Page 158: Led Indicator

    Figure 91. Renogy PCL Inverter/Charger display and interface. Table 18. Renogy function keys and their use. Table 19. Renogy PCL LED indicator meanings. LED INDICATOR PARAMETER Solid Output is powered by an AC source in line AC/INV Green Flashing Output is powered by battery or in invert mode Solid Battery is fully charged Green...
  • Page 159 Figure 92. The Renogy PCL Inverter/Charger has many icons in the display. See below for their meaning. Note that on some PCL models the icons may differ slightly.

  • Page 160: Function Description

    Table 20. Renogy PCL inverter display symbol meaning. Some versions of the inverter may have slightly different symbols. ICON FUNCTION DESCRIPTION Input Source Information (Upper Left) Indicates AC input. Indicates: Input Voltage (V) (INPUT & AC illuminated) Battery Voltage (V) (BATT illuminated) Frequency (Hz) Inverter Temperature (°C) Charge Current (A)

  • Page 161: Wired Remote Control

    Indicates the unit is connected to shore power Indicates the load is supplied by utility power (shore power) Indicates the charging circuit is working Indicates the inverter circuit is working Mute Operation (Middle Right) Indicates the unit alarm is disabled Wired Remote Control The wire remote control for the inverter chargers gives users the opportunity to power on/off the inverter from a distance.

  • Page 162: Renogy Pcl Inverter-Charger Maintenance

    WARNING CODE FAULT CODE EVENT Battery voltage is too high Battery voltage is too low Output short circuit Output is too high or too low Overload Inverter fail to slow start Renogy PCL Inverter-Charger Maintenance Inspection & Cleaning According to the Maintenance Schedule: 1.

  • Page 163: Solar Equipment (If Equipped)

    SOLAR EQUIPMENT (IF EQUIPPED) Alliance RV is committed to continuous product improvement. As such, the implementation of solar options has resulted in several versions of solar installations from the beginning. This started with early model trailers having a Solar Prep option or being equipped with a Solar Option from the factory. Some early model year trailers had no solar prep from the factory.

  • Page 164: Solar Panels And Cable Entry Point (If Equipped)

    By adding a panel and controller, you will not have a solar charge going directly to your house battery that will support your 12 volt system. Please contact Alliance RV or your dealer for details on the controller and panel.

  • Page 165: Renogy 20A Dc-Dc Charger (If Equipped)

    120 volt system. Consult with your RV dealer for more detail. The solar prep and solar option are low voltage systems. For more details or any questions, please contact your Alliance RV dealer or Alliance RV. Renogy 20A DC-DC Charger (If Equipped)

  • Page 166: Renogy 20A Dc-Dc Charger Troubleshooting

    Renogy 20A DC-DC Charger Troubleshooting RISK OF ELECTRIC SHOCK, FIRE HAZARD, OR INJURY. TO MINIMIZE RISK: • ENSURE THE POSITIVE AND NEGATIVE TERMINALS FOR THE CHARGER DO NOT COME INTO CONTACT. • FIRMLY SECURE CABLES AND CONNECTIONS. • DISCONNECT THE PRODUCT FROM THE BATTERY EACH TIME BEFORE CLEANING OR BEFORE MAKING CHANGES TO THE CIRCUIT.
  • Page 167 Table 22. Determining the cause for a fault light. PROTECTION WHAT SHOULD BE DONE? 1.Use a multi-meter to measure the DC input and DC output batteries as well as the respective DC-DC input/output terminals. Battery over-voltage is 15.5-16V: Battery (High Voltage Shutdown @ 16 V, High Voltage Restart @ 15.5 V) Overvoltage 2.Disconnect any other chargers in the circuit and let the battery rest to lower the voltage.

  • Page 168: Renogy 20A Dc-Dc Charger Maintenance

    Renogy 20A DC-DC Charger Maintenance As per the Maintenance Schedule: 1. Inspect the wiring and note any wiring cracks, wear, tear, corrosion, or loose wiring and replace immediately. Inspect wiring terminals and ensure they’re tight as they may become loose during vehicle vibrations.

  • Page 169: Operation

    The Go Power! Solar charge controller has an available USB port on the front panel. It is 5.0 VDC, and can be used to charge devices with up to 800mA of current. Remove the rubber cover on the front panel to access the port. Go Power! GP-PWM-30-UL Solar Charge Controller User Manual Operation The charge controller runs automatically, managing the battery charge based upon the needs of the...

  • Page 170: Battery Voltage

    Figure 99. Go Power! Display details. Table 24. The following symbols are used to represent voltage and state of charge on the Go Power! Display. ICON BATTERY VOLTAGE 4 bars: 100% (only after Boost or Equalization cycle) 3 bars: >12.6 V 2 bars: >= 11.8 V - 12.6 V 1 bar: >...
  • Page 171 The other display icons are as follows: Table 25. Go Power! display icons not related to battery charge. ICON DESCRIPTION Nighttime Daytime USB charger ON (when not connected, no symbol will show) Inverter on (shown for completeness: Alliance does not install a Go Power! Inverter, this will not show on display when other brand inverters are on.) Flashing: Controller ready to pair (Bluetooth)

  • Page 172: Go Power! Solar Charge Controller Troubleshooting

    Go Power! Solar Charge Controller Troubleshooting ELECTRICITY CAN BE VERY DANGEROUS. INSTALLATION SHOULD BE PERFORMED ONLY BY A LICENSED ELECTRICIAN OR QUALIFIED PERSONNEL. OBSERVE ALL SAFETY PRECAUTIONS OF THE BATTERY MANUFACTURER WHEN HANDLING OR WORKING AROUND BATTERIES. WHEN CHARGING, BATTERIES PRODUCE HYDROGEN GAS, WHICH IS HIGHLY EXPLOSIVE.

  • Page 173: Go Power! Solar Charge Controller Maintenance

    WHAT IS HAPPENING? WHY? WHAT SHOULD BE DONE? This will happen when loads on the battery exceed the Low Battery SoC symbol charge current of the controller. If plugged into shower Low battery voltage (< with the text "LOW" is power, determine if the RV converter is functioning.

  • Page 174: Renogy Rover Solar Charge Controller, 20A Or 40A (If Equipped)

    Figure 100. Go Power! Solar Charge controller wiring interface (looking from the top of the controller.). The controller has been removed from the wall and rolled forward. 3. Gently rotate the unit to access the slotted screw clamps from the rear of the unit. Ensure all screws holding wires are tight.

  • Page 175: Item Description

    CONNECT BATTERY TERMINALS TO THE CHARGE CONTROLLER BEFORE CONNECTING THE SOLAR PANEL(S) TO THE CHARGE CONTROLLER. NEVER CONNECT SOLAR PANELS TO CHARGE CONTROLLER UNTIL THE BATTERY IS CONNECTED. Table 27. Renogy Rover front panel indicators, display, and controls. For LED indicator meanings, refer to Table 28. ITEM DESCRIPTION PV LED Indicator –...
  • Page 176 Figure 103. Display icons used on the Renogy Rover 20A, 30A, and 40A charge controllers. Table 28. Renogy Rover LED Indicator guide. PV INDICATOR (1) STATUS White Solid The PV system is charging the battery bank White Slow Flashing The Controller is undergoing boost stage White Single Flashing The Controller is undergoing float stage White Fast Flashing...

  • Page 177: Main Display Screens / Operating The Unit

    Main Display Screens / Operating the Unit The main display can cycle through the following screens using the operating keys. The LCD display description in Figure 103 will also help interpret the information shown on each screen. The interested reader is directed to the User Manual for additional examples and details. Screens Available (cycles from top to bottom, then back to top): •...

  • Page 178: Additional Components

    Additional Components Remote Temperature Sensor: This sensor measures the temperature at the battery and uses this data for very accurate temperature compensation. The sensor is supplied with a 9.8ft cable length that connects to the charge controller. Simply connect the cable and adhere the sensor on top or the side of the battery to record ambient temperature around the battery.

  • Page 179: Error Code

    Table 30. On screen error code descriptions. ERROR CODE DESCRIPTION (ON SCREEN) No error detected Battery over-discharged Battery over-voltage Battery under-voltage Load short circuit Load overloaded Controller over-temperature PV input over-current PV over-voltage Further troubleshooting information can be found on the Renogy Learning Center at the following links: •...
  • Page 180 CONNECT BATTERY TERMINALS TO THE CHARGE CONTROLLER BEFORE CONNECTING THE SOLAR PANEL(S) TO THE CHARGE CONTROLLER. NEVER CONNECT SOLAR PANELS TO CHARGE CONTROLLER UNTIL THE BATTERY IS CONNECTED. Table 31. Renogy Rover front panel indicators, display, and controls. For LED indicator meanings, refer to Table 32. ITEM DESCRIPTION PV LED Indicator –...
  • Page 181 Table 32. Renogy Rover LED Indicator guide. PV INDICATOR (1) STATUS White Solid The PV system is charging the battery bank White Slow Flashing The Controller is undergoing boost stage White Single Flashing The Controller is undergoing float stage White Fast Flashing The Controller is undergoing equalization stage The oversized PV system is charging the battery White Double Flashing...

  • Page 182: Main Display Screens / Operating The Unit

    Main Display Screens / Operating the Unit The main display can cycle through the following screens using UP and DOWN operating keys. The LCD display description in Figure 108 will also help interpret the information shown on each screen. For each screen, one can push the RIGHT ARROW key to find more details about that section/screen.

  • Page 183: Programming

    ICON STATE DESCRIPTION Steady on Load Terminal is on Steady on Load Terminal is off Overload or Short-circuit Fast Flashing protection Programming Programming and reprogramming the unit (in the case of battery upgrade or conversion) are beyond the scope of this manual and the interested reader is directed to the Renogy Rover User Manual. Renogy DC Home app (Bluetooth) The Renogy DC Home app is a mobile application designed to work with Renogy's range of solar energy products, providing users with real-time monitoring and control of their solar power systems.

  • Page 184: Renogy Rover 60A Troubleshooting

    Do not use this sensor when charging lithium batteries. Renogy Rover 60A Troubleshooting The LED indicators at the top of the face of the unit can be used as a first step in diagnosing problems. The following information can be used to see fault conditions. Table 34.
  • Page 185 2. Now press the DOWN ARROW button to see the Fault display. The table following the display explains the fault abbreviations. Figure 112. Step two to find error codes on the Renogy Rover 60A Table 35. Renogy Rover 60 on-screen error code descriptions. CODE DESCRIPTION BAT-LDV...
  • Page 186 Table 36. Further troubleshooting for the Renogy Rover 60A. WHAT IS WHAT SHOULD BE DONE? HAPPENING? This indicates the solar panel voltage may be too low or the panel cannot be detected by the charge controller. Follow the troubleshooting steps below: 1.
  • Page 187 WHAT IS WHAT SHOULD BE DONE? HAPPENING? 1. The charge controller is in the float charging stage, and the charging current will gradually drop until the battery is fully charged. 2. Inspect the solar panel and keep it away from the shade. 3.

  • Page 188: Renogy Rover 60A Maintenance

    Further troubleshooting information can be found on the Renogy Learning Center at the following links: • Charge Controller Troubleshooting Guide • Troubleshoot Renogy Rover 60A Charge Controller. Renogy Rover 60A Maintenance As per the Maintenance Schedule, please perform the following checks and adjustments: 1.

  • Page 189: Main Display Screens / Operating The Unit

    Figure 113. Renogy Rover Elite operating key use. Figure 114. Display icons used on the Renogy Rover Elite 20A and 40A charge controllers. Main Display Screens / Operating the Unit The main display can cycle through the following screens using the operating keys shown in Figure 113. The LCD display description in Figure 114 will also help interpret the information shown on each screen.

  • Page 190: Programming

    Programming Programming and reprogramming the unit (in the case of battery upgrade or conversion) are beyond the scope of this manual and the interested reader is directed to the Renogy Rover Elite User Manual. Renogy DC Home app (Bluetooth) The Renogy DC Home app is a mobile application designed to work with Renogy's range of solar energy products, providing users with real-time monitoring and control of their solar power systems.
  • Page 191 Table 37. Renogy Rover Elite error code meanings and suggested actions. Error Code WHY? WHAT SHOULD BE DONE? (on screen) System behaving normally, no action needed. When No Error this condition exists, the error code screen is not shown. Use a multi-meter to get a reading of the battery voltage in volts DC to validate error code.
  • Page 192 Table 38. Additional troubleshooting steps for the Renogy Rover Elite. WHAT IS WHAT SHOULD BE DONE? HAPPENING? Reverse Battery Polarity Protection The battery is The Rover Elite needs a correct battery connection to startup. This connected to the might mean that the battery cables are reversed. Use a multi-meter to controller, but the make sure your voltage reading has the correct polarity (Red to controller is not...

  • Page 193: Renogy Rover Elite Maintenance

    WHAT IS WHAT SHOULD BE DONE? HAPPENING? Open Battery Protection Mode Whether connecting the system for the first time or operating it for a while, you may experience an E01 error if the controller does not The charge controller actually detect a battery and assumes it to be under-discharged. This believes the battery is can happen in an accidental line break or failure to connect it correctly over-discharged, but...

  • Page 194: Identification

    Android, Windows (USB connection only with optional VE.Direct USB Interface,) Apple iOS (Bluetooth connection only,) and MacOs platforms. Normal operation of the device requires no user intervention, but there are times when the user may need to disconnect/connect solar panels or batteries or change programming of the solar charge controller when changing batteries or system configuration.

  • Page 195: Shutdown And Restart Procedure

    Figure 118. Victron MPPT charge controller interface identification. Table 39. Victron interface identification. See Figure 118. DESCRIPTION Ground screw Battery screw terminals PV (solar panel) screw terminals VE.Direct socket Operation/Fault LEDs Rotary switch (battery type quick programming) Shutdown and Restart Procedure The solar charger is always active when the PV and/or the battery terminals are powered.

  • Page 196: Monitoring Operation Via Led Indicators

    2. Disconnect the battery supply to the solar charger by switching the battery supply off. For Alliance trailers, this means first turning off the Battery Disconnect rotary switch, then disconnecting the negative battery lead. In the case of multiple batteries, disconnect the negative battery lead at the single point of connection to the 12 V bus bar.

  • Page 197: Fault Mode

    ABSORPTION OPERATION MODE BULK LED FLOAT LED Notes: 1. The bulk LED will blink briefly every 3 seconds when the system is powered but there is insufficient power to start charging. 2. The LED(s) might blink every 4 seconds indicating that the charger is receiving data from another device, this can be a GX device (ESS) or a VE.Smart Network link via Bluetooth.

  • Page 198: Victron Solar Charger Troubleshooting

    DO NOT CHANGE SOLAR CHARGER SETTINGS UNLESS YOU KNOW WHAT THEY ARE AND WHAT THE EFFECT OF CHANGING THESE SETTINGS CAN BE. INCORRECT SETTINGS MAY CAUSE SYSTEM PROBLEMS INCLUDING DAMAGE TO BATTERIES. WHEN IN DOUBT, SEEK ADVICE FROM AN EXPERIENCED VICTRON ENERGY INSTALLER, DEALER OR DISTRIBUTOR. Victron Solar Charger Troubleshooting If you suspect the solar charger is not performing correctly, or the LEDs on the front panel indicate a fault condition, use the VictronConnect app to review the status of the charger.

  • Page 199: Tv & Stereo

    The COAX wiring system is configured as shown in Figure 119. One component not shown in the diagram is the living room radio. It is connected to the antenna line between the Booster Switch and living room TV outlet. Figure 119. Alliance RV All TV COAX wiring system.

  • Page 200: Winegard Tv Antenna

    AV system, see the plumbing section regarding the Nautilus P3 Centralized Docking Station. Winegard TV Antenna Avenue trailers made prior to 2025 are equipped with a Winegard Air 360+. This unit provides signal amplification of television and radio signals and also is cellular internet ready and can be upgraded easily with the Winegard Gateway for 4G LTE &...

  • Page 201: Taoglas Tv Antenna

    Television & Stereo Setup and Operation Due to the large variety of models of televisions and stereos installed in Alliance RV units, please review the owner’s manual for your tv or stereo for operation. For a list of installed equipment along with links to their manuals can be found at Alliance Academy.
  • Page 202 Possible Issues: Loose COAX connection: Check all COAX connections. Damaged COAX cable: If all connections are tight, exchange the COAX cable from the problematic TV with the one from a working TV. If all channels are now found, discard the removed cable and replace.
  • Page 203 one will be for the room of interest (for example, the living room.) Using a Male/Male COAX connector, ensure the two desired cables are connected. 3. If the problem TV is the living room TV, remove the radio from its mounted position and gentle pull it out.

  • Page 204: Monitor Panel

    MONITOR PANEL This system allows monitoring of fresh water, gray water, black water and battery levels. All functions are controlled from computer grade tactile switches for easy operation. Power control of the water heater, water pump, tank heaters, some of the RVs lights, awnings and slide-outs are also done from the central monitor panel.

  • Page 205: Backup Camera

    Backup Camera The trailer has a pre-wired backup camera location at the top-rear of the trailer. The mounting location is covered and sealed with a circular black plastic cover. When mounting a camera, one removes the cover, and the +12 V and ground wires are attached to the cover. The Camera switch on the Monitor Panel controls power to this location- and must be ON for the camera to receive power.

  • Page 206: Awnings

    AWNINGS Your Alliance RV comes standard with a power awning and in some cases, depending on the floor plan, may have two power awnings installed from the factory. WYKW: Best Practices for Patio Awnings Use Solera 3000 Series 12V Power Awning Owner’s Manual Early model year Avenue Trailers were equipped with the Carefree of Colorado “Compass”...

  • Page 207: Extending The Awning

    Extending the Awning 1. First verify that the battery is fully charged and connected to the electrical system. 2. Press and hold the awning extend button in the monitor panel. Extension is considered complete when the fabric is completely unrolled, the valance sean is visible and a section of the awning tube is exposed.
  • Page 208 2. Choose the side of the awning for optimum shade or conenient water runoff. Pull down on the joint of the atriculating arm until desired pitch is set to allow for water runoff. Never push the jointes of the atriculating arms up. This will put tension on the gas strut, which can cause the strut to break.

  • Page 209: Awning Component Breakdown

    DURING INCIDENTS OF HIGH WIND, HEAVY RAIN OR EXTENDED TIME AWY FROM THE RV, BE SURE TO RETRACT THE AWNING COMPLETELDY TO PREVENT DAMAGE TO THE WAWNING AND THE RV. Awning Component Breakdown Figure 125. Awning components of interest. Awning Troubleshooting Solera Power Awning Troubleshooting and Service Manual Awning Maintenance Cleaning &...

  • Page 210: Awning Manual Override

    1. Extend the awning and clean it with mild soap and water, or approved awning cleaner. Allow awning to dry before closing. 2. While running the awning out and in, monitor the gas struts. If bouncing or rough operation is witnessed, open the awning fully, and wipe the exposed strut shafts with a small cloth dampened with silicone lubricant.

  • Page 211: Slide-Out Topper Prep

    (shown below) installed. For assistance with parts and or questions regarding the slide-out topper prep kits, please contact your Alliance Dealer or Alliance RV. Figure 128. Slide topper prep with cover. Note the cover may be black. Solera 1000 Series Slide Topper (Aftermarket Installation and Owner’s Manual) Slide-out Toppers (If Equipped) Late model Alliance RVs can be purchased with Solera Series 1000 Slide Toppers installed.

  • Page 212: Slide Topper Component Breakdown

    Slide Topper Component Breakdown Figure 129. Slide topper component identification.

  • Page 213: Heating, Cooling & Ventilation

    HEATING, COOLING & VENTILATION Furrion Single Zone Thermostat (IF Equipped) When equipped, and depending upon floorplan and options purchased, your Avenue trailer will have between one and three individual thermostats. Each thermostat controls a single rooftop air conditioning unit. The bedroom area thermostat will also be connected to your Surburban propane furnace to manage heating your RV.

  • Page 214: Modes Available

    Modes Available The following descriptions detail how the system will run in each of the available modes on the thermostat. Fan AUTO mode: In auto modes, the fan speed will change relative to the difference between the room temperature and the set-point temperature. When that difference is greater than three (3) degrees, it will run on HIGH.

  • Page 215: Furrion Single Zone Thermostat Troubleshooting

    Furrion Air Conditioners (If Equipped) Alliance RV main living quarters (Living Room and Kitchen) will utilize one or two “direct cool” air conditioners. These units are mounted on the exterior roof of the RV with a shroud mounted on the inside ceiling –...

  • Page 216: Furrion Ac Maintenance

    The ability of the air conditioner to maintain the desired inside temperature depends on the heat gain of the recreational vehicle. The size of the vehicle, amount of window area, amount of insulation, direct exposure to the sun, outside temperature, and the number of people in the recreational vehicle may increase the heat gain to such an extent that the capacity of the air conditioner is exceeded.

  • Page 217: Ac Coil Cleaning

    2. Remove the filters by pushing the tabs to release. 3. The filter can be washed with warm soapy water. Take care not to rip the fabric. 4. Replace the filters and decorative plate by reversing the above process. The filter must be completely dry before re-installation. AC Coil Cleaning As per the maintenance Schedule, one needs to remove the top shroud and clean the Evaporator Coils, Figure 132.
  • Page 218 Figure 133. Coleman (Airxcel) LCD Thermostat interface. The general modes of operation are as follows: Fan Hi/ Fan Low: In this mode, the system will turn the fan on high or low and will not attempt to cool the space regardless of the temperature setting. Cool Hi / Cool Low: In this mode the system will turn the fan on high or low, as selected.

  • Page 219: Digital Thermostat For Coleman Mach Air Conditioners (If Equipped)

    mode independently. Whenever a Cool mode is selected, it will use that temperature, and then automatically recall the Heat mode temperature when the mode is changed. Hold the mode button down for 5 seconds to change from Fahrenheit to Celsius. Operating your cooling system when the outdoor temp is below 50 deg Fahrenheit can cause damage to your cooling equipment.

  • Page 220: Coleman Mach Air Conditioners (If Equipped)

    Coleman Mach Air Conditioners (If Equipped) Alliance RV main living quarters (Living Room and Kitchen) will utilize one or two “direct cool” Coleman air conditioners. These units are mounted on the exterior roof of the RV with a combination shroud mounted on the inside ceiling of the RV.

  • Page 221: Coleman Mach Ac Maintenance

    Suburban Furnace Every Alliance RV will be heated with an SF-Q series Suburban furnace that provides 42,000 BTU’s. An exterior access door allows for ease of service. The furnace is operated with the thermostat that is tied to the main air conditioner unit in the center zone of the trailer.

  • Page 222: To Turn The Furnace On

    During initial firing of this furnace, a burn-off of excess paint and oils remaining from manufacturing process may cause foul odors and mild smoking for 5 – 10 minutes. This can also happen after several months with no operation due to dust build up. To Turn the Furnace On For the furnace to properly turn on, the propane gas valve must be fully open.

  • Page 223: Fireplace

    2. If soot is found, shut down the furnace immediately and contact a qualified service provider to address incomplete burning of the fuel. 3. Inspect the return air location (under the front stairs in most Alliance trailers) to assure no blockages exist.

  • Page 224: Remote Control

    • Flame Color – Press this button to change the flame color. The unit will beep – press once for orange, press twice for an orange’ish blue, press three times for blue • Flame Effect – Press this button to change the flame effect. The unit will beep. Press again to decrease the flame intensity.

  • Page 225: Ventilation

    If not, have a qualified RV Technician verify the plug function as well as checking the relay mounted in the bottom of the kitchen island. This relay diverts power to the dishwasher (if installed) or device(s) running on the provided dishwasher outlet. How to Fix/Troubleshoot Your Alliance RV Fireplace Ventilation Maxxfan MAXXAIR Maxxfan vent fans are located in the kitchen and master bathroom areas.

  • Page 226: Range Vent

    WYKW: Max Air Fan – Quick Tip Range Vent The microwave or microwave/convection oven (if equipped) situated above your stove has a built-in fan. This will be covered in the Appliances section to follow.

  • Page 227: Appliances

    Make sure the doors seal correctly (refer to the Maintenance Schedule for a method to check this.) Microwave or Microwave/Convection Combination (If Equipped) Oven Your Alliance RV comes equipped with either an Over the Range (OTR) Microwave, or combination Microwave/Convection Oven. Range Vent (Vent Hood) Your OTR (Over-the-Range) microwave is equipped with a vent fan and a light underneath the microwave.

  • Page 228: Plumbing And Utilities

    PLUMBING AND UTILITIES Centralized Docking Station Alliance RV uses the Nautilus P3 Water Management System for Avenue trailers. With this system you’ll have the ability to perform the following functions from a centralized and easy to access location: 1. Power fill your fresh water tank for dry camping.

  • Page 229: Docking Station Handle Position And Valve Routing

    Docking Station Handle Position and Valve Routing...

  • Page 230: Cable And Satellite Connection

    Cable and Satellite Connection Filling the Fresh Water Tank – Power Fill WYKW: Proper Water Pressure (PSI) WYKW: Properly Connecting Your Water Fill...

  • Page 231: Fill And/Or Sanitize The Fresh Water Tank With The Pump

    Fill and/or Sanitize the Fresh Water Tank with the Pump There is no gravity fill port for the fresh water tank. The water pump is used along with a short hose and buck or other means to provide the water or fluid to be put into the tank. WYKW: Winterizing Quick Tip –...
  • Page 232 For sanitizing, a solution of 1 gallon of water and one quarter cup of household bleach should be prepared for every fifteen gallons of holding tank capacity. A commercial sanitizing product may also be used.

  • Page 234: Using The Fresh Water Tank For Dry Camping

    Using the Fresh water Tank for Dry Camping Connecting to City Water WYKW: Proper Water Pressure (PSI)

  • Page 235: Winterizing

    Winterizing Winterizing Your Avenue RV WYKW: Winterizing Quick Tip – Pulling Antifreeze In...
  • Page 238 Nautilus Panel Winterizing Troubleshooting Using antifreeze fluid after blowing out with air: It’s often asked if this is needed. The answer is YES. Using an air blow technique alone can result in low points in the system retaining some pockets of water, and if the system has a tankless water heater it is very important to assure all water is out of the system.

  • Page 239: Rinsing Holding Tanks / Tank Flush

    Rinsing Holding Tanks / Tank Flush...

  • Page 240: Fresh Water System

    Fresh Water System The fresh water system is made up of two inputs, a portable fresh water holding tank with a pressure demand 12 volt water pump and a city water connection that provides water to the system and bypasses the fresh water holding tank and the water pump to supply your fresh water from an already pressurized source.
  • Page 241 the rv into storage, or if draining water to enable travel. Always be sure to Fresh Water drain your freshwater tank between Fresh Water Drain uses, and during storage in the winter, Overflow this will prevent any stagnation that can cause water to smell and/or taste bad.

  • Page 242: Waste Water System

    This will prevent damage from freezing. Every Alliance RV has low point drains as well as a fresh water drain (and overflow) in which the fresh water system can be evacuated.

  • Page 243: Plumbing System Throughout The Trailer

    DO NOT USE THE BLACK TANK FLUSH SYSTEM WITHOUT HAVING THE BLACK TANK VALVES OPEN. IF CLOSED, THE TANK COULD OVERFILL. • Gray tanks hold your sink, shower, and laundry waste water. Gray tanks require less maintenance due to the difference in waste produce making its way into the tank. It may be ideal to dump black tanks first and then your gray tanks, the gray tank running thru the main dump will help in keep the pipeline cleaner.

  • Page 244: Tankless Water Heater (If Equipped)

    Tankless Water Heater (If Equipped) Beginning model year 2025, Avenue trailers ship with a Suburban ST- 60 Tankless Water Heater. This unit provides a source of rapid hot water via a propane burner system. The unit will start when hot water is requested and the control panel, shown below, is turned Figure 144.

  • Page 245: Operation

    Figure 145. Control panel use for the ST-60 tankless water heater. Operation 1. On the control panel, turn the heater ON via the power button. 2. For best results, open hot water faucet fully until hot water arrives, then reduce flow and mix cold water as needed to achieve desired temperature.

  • Page 246: Tankless Water Heater Troubleshooting

    6. When the system is no longer needed (i.e. after a trip is over) simply turn OFF the water heater at the control panel. Also turn OFF the power button that is on the face of the water heater, and shut off the propane gas supply.
  • Page 247 The Blower motor will operate for approximately 20 seconds after the hot water faucet is turned OFF. 8. If the User Control Panel is left ON, no further action is required by the user. 9. If the water heater fails to light for any reason, a second Trial For Ignition (TFI) will automatically begin.

  • Page 248: Tankless Water Heater Maintenance

    Blower fan runs after the The blower fan is hot water is turned off Normal operation. removing exhaust gasses. and the burner shuts off. The water heater has built-in Freeze Protection and will cycle the burner for 5 The water heater turns on seconds when the water temperature has and runs for five (5) Freeze Protection...

  • Page 249: Draining And Storage

    As per the Maintenance Schedule: • Periodically inspect unit for soot. If soot is present anywhere on water heater, immediately shut unit down and contact your dealer or a qualified service person. Soot is a sign of incomplete combustion and must be corrected before operating water heater. •...
  • Page 250 Figure 146. The water heater power switches on the main Monitor Panel. The FLT light is highlighted on the left. These are also shown in Figure 122A and D. DO NOT TURN ON THE WATER HEATER WITHOUT HAVING WATER IN THE TANK. The water heater may use either LP Gas or 120 V electricity, or both at the same time.
  • Page 251 T & P Valve Gas Reset Electric Reset External Electric Anode Rod Power Switch Figure 147. Suburban SW12DEL tank water heater. It should be noted that heating water from cold/ambient temperature, with the water heater being cold itself, is a lengthy process with only electricity. This is because not only the water must heat up, but also the tank and inside surfaces of the insulation.

  • Page 252: Tank Water Heater Troubleshooting

    YOU MUST READ THE USERS MANUAL FOR THIS WATER HEATER. Tank Water Heater Troubleshooting There are times when the over-temp limit switch is activated (when water temp rises above 180°F) and the system will not heat water. If this happens, wait until the water is below 110°F and push the reset buttons indicated in the image above.

  • Page 253: Tank Water Heater Maintenance

    • You are at high altitude. At altitudes above 4,500 feet, the burner needs to be adjusted (derated) to run with the thinner air. • If neither of these cases apply, contact an RV service provider to determine the cause. Symptom: Water is weeping from the Pressure &...

  • Page 254: Storage

    Refer to the Centralized Docking Station section of this manual. Toilet Alliance RV uses the best in class 310 series Dometic RV toilet. Each toilet is 100% factory tested to assure watertight seal in the toilet bowl before it even leaves Dometic. After installation by Alliance RV, the entire waste system is flood tested for leaks by filling the system with water to the rim of the bowl.

  • Page 255: Dumping Your Waste Tanks

    How Do I Fix My Alliance RV Toilet? Dumping Your Waste Tanks Avenue trailers are equipped with manual cable termination valves. Most of these valves are going to be routed to the centralized docking station convenience center for ease of pulling. However, in some occasions, dictated by floor plan, you may find one or more gate valve pull handles located on the off- door side frame rail of the RV, either forward of or behind the wheels.

  • Page 256: Monitoring Your Water Systems

    Figure 148. Valterra manual waste tank valve assembly. Monitoring Your Water Systems The Monitor Panel shows the fill levels of the fresh water, grey water and black water tanks. You will also operate the heaters on the holding tanks here and as well as the power to the fresh water pump (you’ll also find a water pump switch in the exterior docking station) and the water heater.

  • Page 257: Tank Heaters

    Figure 149. The upper portion of the monitor panel showing tank and water controls. This figure has the same indicators as Figure 122. When an individual button is pressed (Figure 149C), the lights above the switch (Figure 149B) illuminate to reveal the level of the selection pushed. For the battery level indicator, the individual letters mean the following: •...

  • Page 258: Washer / Dryer Prep (If Equipped)

    You will find both hot and cold-water connection points. Should a washer and dryer be your desire, please consult with your dealership or Alliance RV for our installation recommendations. Otherwise you will find functional cabinet or closet space in that area.

  • Page 259: Interior

    (the fabric hangs down over the BACK of the roller tube) and the Set Point (AutoStop™ ) Adjustment is on the RIGHT end. How to fix/troubleshoot your roller shades in your Alliance RV (Alliance video) MCD video library – extensive selection of how-to videos Window Blind Maintenance Adjustments of the shade can be found in the Tech Tip referenced in the Troubleshooting section.

  • Page 260: Removing And Replacing A Roller Shade Assembly: Metal Clips

    Removing and Replacing a Roller Shade Assembly: Metal Clips Early model year Avenue trailers use shades with a metal clip which grabs the external ridges of the shade base. If one inspects the area between the shade assembly and the wall, you may see two or three (on longer shade assemblies) metal tabs visible between the shade and the wall.

  • Page 261: Furniture

    FURNITURE You’ll find a range of styles and sizes of furniture in your RV, below is some information on the different types of furniture you may see in your RV. MOVING PARTS CAN PINCH, CRUSH OR CUT. KEEP CLEAR AND USE CAUTION. Theatre Seating A modular seating system that features electric controls and smoothly operating recliners which is assembled and installed by the factory for ease of use.
  • Page 262 5. User back cushions as headrest or pillows Figure 152. Operating the fold-out sofa. A polyurethane fabric constructed and designed for all home furniture. Polyurethanes should be cleaned with a mild water based shampoo or soap. More stubborn stains can be cleaned with a mild, non- alcohol based cleaning fluid.

  • Page 263: Care & Maintenance

    CARE & MAINTENANCE An RV comes with a variety of surfaces that need to be cleaned and maintained both on the exterior and interior. Regular cleaning and maintenance of these different components is needed and will help keep the RV in the best possible condition both cosmetically and functionally. The rate of the breakdown and deterioration of the seals, sealants and gaskets on your RV is directly tied to the outside environment and the needed maintenance, cleaning and touch up of these crucial components may vary based on your specific experience.

  • Page 264: Harsh Environments

    Make sure to check the roof, slide-outs, the corner, termination and beltline trims and moldings on the exterior of the RV. For questions on required seals and sealants, please contact your dealer and Alliance RV. Slide-out Seals Inspection Your slide-outs utilize wipe, cap and bulb seals to protect the room from the outside elements.

  • Page 265: Conditioning

    When slide-outs are open- inside bulb seals: all three bulb seals (front, rear, and top) between the trim boards and interior wall should be in contact and compressed approximately 50%. If there are gaps or significant deviations, contact an rv repair center to have your slide open position adjusted, or refer to the section Hydraulic Slide-outs: Advanced Maintenance.

  • Page 266: Extended Recreational Use Of The Rv

    EXTENDED RECREATIONAL USE OF THE RV In some cases you may find yourself in the RV for extended periods of time. Whether that be full time living, a long weekend or an extended stay, you may run into some challenges. We have put together some helpful tips for battling some of these challenges.

  • Page 267: Maintenance Schedule

    MAINTENANCE SCHEDULE The following maintenance schedule will help keep your Alliance Avenue trailer operating at peak performance, and such maintenance is required to keep your warranty active. For items listed as “Before Use”: Most items are commonly quick inspections to assure a safe towing experience.
  • Page 268 Inspect Slide Seals: Ensure the rubber is not cracked or torn, and for proper compression. Refer to the section Slide- out Seals: Inspection Condition Slide Seals: Refer to the section Slide-out Seals: Conditioning Electric Through-Floor Slideouts: Actuate each one. Ensure one full cycle of retraction and extension is completed.
  • Page 269 ROOF Inspect the PVC Membrane & Attachment Points/Seams: Refer to the section Roof Maintenance & Inspection Wash the Roof: Refer to the section Roof Maintenance & Inspection FRAME & UNDERBELLY Inspect the Frame & Underbelly: Check for damage, loose wires, loose brake lines/wires, and debris. Repair any damage to underbelly material, wires, or brake lines as needed.
  • Page 270 Inspect CRE3000 Rubber Shear Spring and Bracket: Refer to the section Leaf Spring Suspension Maintenance: CRE 3000 Inspection Check Wet Bolt Torque: Refer to the section Leaf Spring Suspension Maintenance: Wet Bolt Torque Check Axle U-Bolt Torque: Refer to the section Leaf Spring Suspension Maintenance: Axle U-Bolt Torque Grease Wet Bolts: Refer to the section...
  • Page 271 Inspect and Perform a Torque Check for the Intellitronix EMS (if equipped): Refer to the section Intellitronix Maintenance: Inspection & Torque Check Inverter (if equipped) Perform an Inspection & Cleaning for the Inverter mounted in your trailer: Refer to the proper section for the particular Inverter mounted in your trailer.
  • Page 272 Check Fire Extinguisher Mounting and Charge: Make sure Fire Extinguisher is accessible, yet secure. Also verify the charge is still good using whatever method is printed on the label. Test Emergency Exit/Egress Windows: Open each Emergency Exit/Egress window and reclose. If any window will not open, contact an authorized service center.
  • Page 273 OTHER Clean & Inspect Awning: Refer to the section Awning Maintenance: Cleaning & Inspection Check Seals & Lubricate Refrigerator Doors: If your refrigerator has a dual door with central flap attached to a door, open the other door and make sure the flap fully closes flat.

  • Page 274: Vendor Warranty And Contact Information

    Some of this information may change without notice. Alliance RV will make all efforts to keep this manual as up to date as possible. This is a summary of the component manufacturer warranty only. For details on individual component warranties, see their warranty information.
  • Page 275 (574) 294‐2684 DC-DC Charger Renogy warranty@dehco.com Varies www.dehco.com (574) 537-8900 Entry Steps Lippert Components customerservice@lci1.com 1-Year Limited www.lci1.com (800) 348-7625 Fireplace LaVanture service@alliancerv.com 1-Year Limited www.lavanture.com (423) 775-2131 Furnace Suburban rvpsupport@airxcel.com 2-Year Limited www.airxcel.com (574) 537-8900 Furniture Lippert Components customerservice@lci1.com 1-Year Limited www.lci1.com (269) 781-4241...
  • Page 276 (574) 848-1118 Microwave Lusso warrantydept@collins-n-co.com 1-Year Limited https://www.collinssupport.com/ (877) 467-4289 Oven / Cooktops Insignia www.insigniaproducts.com/email-us 1-Year Limited www.insigniaproducts.com (574) 848-1118 Oven / Cooktops Lusso warrantydept@collins-n-co.com 1-Year Limited https://www.collinssupport.com/ (574) 971‐4490 Oven / Cooktops Greystone www.customerservice@wayinterglobal.com 1-Year Limited www.wayinterglobal.com (574) 537-8900 Pin Box(Rota-Flex) Lippert Components customerservice@lci1.com...
  • Page 277 (574) 537-8900 Slideout Systems Lippert Components customerservice@lci1.com 1-Year Limited (Electric) www.lci1.com (574) 294‐2684 Solar Charge Renogy warranty@dehco.com Varies Controller www.dehco.com (866) 247-6527 Solar Charge https://gopowersolar.com/contact-go- Go Power! 5-Year Limited Controller power/ https://gopowersolar.com/ (800) 442-7717 Stereo (JBL) Riverpark Inc Technicalsupport@riverparkinc.com 1-Year Limited www.riverparkinc.com (800) 688-3135 Stereo (Jensen)
  • Page 278 Product information is as accurate as possible as of the date of publication of this brochure. Alliance RV is commitment to continuous product improvement thus - floorplans, materials, components, features, measurements, specifications, options, etc. are subject to change at any time without notice or obligation.

Table of Contents

Save PDF
